- 91 -
Recording
Bracket setting is performed based on the adjustment values for the white balance fine
adjustment, and 3 pictures with different colors  are automatically recorded when the shutter
button is pressed once.
1Press [DISP.] in step 2 of the “Finely adjusting the White
Balance” procedure, and press  3/4/2 /1  to set the bracket.
2 /1 : Horizontal (A to B)
3 /4 : Vertical (G i to M j)
2Press [MENU/SET].
Note
•
[ ] is displayed on the screen when it is set.•The White Balance Bracket setting...

- 92 -
Recording
Taking Pictures with Auto Focus
Applicable modes:
This allows the focusing method that suits the positions and number of the subjects to be
selected.
1Set the camera to Auto Focus.
2Select [AF Mode] on the [Rec] menu and then press 1.
(DMC-FZ200)
Set the focus selector switch to [AF].(DMC-FZ60)
1
Press [AF/AF #/MF] to display the
focus setting screen.
2 Press  3/4 to select [AF] and then
press [MENU/SET].
(DMC-FZ200)
•
Auto Focus Mode setting screen can also be
displayed by...

- 93 -
Recording
3Press 3/4 to select the Auto Focus Mode and then press [MENU/SET].
Note
•It will be fixed to [ š] when the [Face Recog.] is set to [ON].
•It is not possible to set [ š] in the following cases.–[Panorama Shot]/[Panning]/[Night Scenery]/[Handheld Night Shot]/[Food] (Scene Mode)–[Soft Focus] (Creative Control Mode)
•It is not possible to set [ ] in the following cases.–[Panorama Shot] (Scene Mode)–[Sepia]/[Dynamic Monochrome]/[High Dynamic]/[Toy Effect]/[Soft Focus] (Creative Control...

- 94 -
Recording
∫About [ š] ([Face Detection])
The following AF area frames are displayed when the camera detects the
faces.
Yellow:
When the shutter button is pressed halfway, the frame turns green when
the camera is focused.
White:
Displayed when more than one face is detected. Ot her faces that are the same distance away
as faces within the yellow AF areas are also focused.
Note
•
When [Metering Mode] is set to multiple [ C], the camera will adjust the exposure to suit the person’s
face.
•Under...

- 95 -
Recording
∫Setting up [ ] ([AF Tracking])
Bring the subject to the AF tracking frame, and press [AF/AE
LOCK] to lock the subject.
A AF tracking frame
•AF area will be displayed in yellow when a subject is recognized, and
exposure and focus will automatically adjust continuously following the
subject’s movement (Dynamic tracking).
•AF tracking is canceled when [AF/AE LOCK] is pressed again.
Note
•When the AF lock fails, the Tracking AF frame will turn red and then disappear. Redo the AF lock.•In...

- 96 -
Recording
∫Changing position and size of the AF area (Only when [ Ø] is selected)
If you performing any of the following operations, the screen will switch to the settings menu.
•
When [ Ø] is selected, press [FOCUS].•From the menu screen, select [ Ø], and press 1.
1Press  3/4 /2/ 1 to move the AF area.
•You can set to arbitrary position of the screen. (It cannot be set to
edge of the screen)
•After moving the AF area, press [DISP.] to return it to the center.
2Rotate the rear dial to change the...

- 97 -
Recording
Taking Close-up Pictures
Applicable modes:
This mode allows you to take close-up pictures of a subject, e.g. when taking pictures of
flowers. You can take pictures of a subject as close as 1 cm (0.033 feet) from the lens by
rotating the zoom lever upmost to Wide (1k ).
Use this setting to get close to the subject and then further enlarge when taking the picture.
You can take a picture with the Digital Zoom up to 3k  while maintaining the distance to the
subject for the extreme Wide...

- 98 -
Recording
Note
•We recommend using a tripod and the Self-timer.•We recommend setting the flash to [Œ ] (close the flash) when you take pictures at close range.•If the distance between the camera and the subject is beyond the focus range of the camera, the
picture may not be properly focused even if the focus indication lights.
•When a subject is close to the camera, the effective focus range is significantly narrowed. Therefore,
if the distance between the camera and the subject is changed after...

- 99 -
Recording
Taking Pictures with Manual Focus
Applicable modes:
Use this function when you want to fix the focus or when the distance between the lens and the
subject is determined and you do not want to activate Auto Focus.
1Set the Manual Focus.
•When shooting in Manual Focus, [MF] is displayed on the screen.
2Press the rear dial to set [MF] to a selected
state.
•Enabled operation will switch every time the rear dial is
pressed.
3Rotate the rear dial to display focus range on the screen....

- 100 -
Recording
∫MF Assist
If [MF Assist]  (P62) in the [Setup] menu is set to [ON], when focus is achieved, the MF area
(locations that are in focus) is enlarged.
•
If you press [MENU/SET] while MF Assist is displayed, the MF area can be moved using
3/ 4/2 /1. Pressing [MENU/SET] again returns the camera to MF Assist.
•Performing the following operation returns the MF area to the center.–Changing the picture size or aspect.
–Turning the camera off (including Sleep Mode).
(DMC-FZ200)
∫ Focus setting...
