231
9. Using Menu Functions
[Monitor Display]/
[Viewfinder]Brightness, color, or red or blue tint of the Monitor/
viewfinder is adjusted.
1Select the settings by pressing
3/4, and
adjust with  2/1 .
• Adjusting can also be performed by rotating the rear
dial.
2Press [MENU/SET] to set.
• It will adjust the monitor when the monitor is in use, and the viewfinder when the viewfinder is in use.
• Some subjects may appear differently from actuality on
the monitor. However, this does not affect the recorded...

9. Using Menu Functions
232
[Economy]
[Sleep Mode]:The camera is automatically turned off if the camera has
not been used for the time selected on the setting.
[Sleep Mode(Wi-Fi)]:The camera is automatically turned off if it is not connected
to a Wi-Fi network and has not been used for 15 minutes
(approx.).
[Auto LVF/Monitor Off]:The monitor/viewfinder is automatically turned off if the
camera has not been used for the time selected on the
setting.
• To cancel [Sleep Mode] or [Sleep Mode(Wi-Fi)] ,...

233
9. Using Menu Functions
[TV Connection]
[HDMI Mode (Play)]:Sets the image output format.
[AUTO]:
The output resolution is automatically set based on
the information from the connected TV.
[C4K]:
The progressive method with 2160 available scan
lines is used for output. The output size is set to
4096
k2160.
[4K]:
The progressive method with 2160 available scan
lines and an output resolution of 3840 k2160 are
used for output.
[1080p]:
The progressive method with 1080 available scan
lines is used...

9. Using Menu Functions
234
[TV Connection]
(continued)
[VIERA Link]:If you select [ON], operations of the camera and the VIERA
Link compatible equipment connected to the camera with
an HDMI micro cable are automatically linked, enabling
you to control the camera with the remote control of the
VIERA Link compatible equipment.P302
[m/ft]
Select how distance is displayed, in Ft or M. s
[Menu Resume]Stores the location of the last-used menu item for each
menu. s
[Menu Background]
Set the background...

235
9. Using Menu Functions
[Reset]
The following settings are reset to the default:– Recording settings (Except for [Face Recog.] and [Profile Setup] settings)
– Recording settings ([Face Recog.] and [Profile Setup]  settings)
– Setup/custom settings
• When the setup/custom settings are reset, the following  settings are also reset.
– The [World Time] setting
– The settings of [Travel Date] (departure date, return  date, location)
– The settings of [Rotate Disp.], [Picture Sort] and [Delete...

9. Using Menu Functions
236
[System Frequency]You can change the system frequency of the motion
pictures you record and play back.
[59.94 Hz (NTSC)]:
For regions where the TV broadcasting system is NTSC.
[50.00 Hz (PAL)]:
For regions where the TV broadcasting system is PAL.
[24.00 Hz (CINEMA)]:
This system frequency is for creating films.
• After changing the setting, turn the camera off and on.
• By default, the system frequency is set to the
broadcasting system of your purchase region , [59.94 Hz...

237
9. Using Menu Functions
[Activate]Use an Upgrade Software Key (DMW-SFU1: optional) to
enable the extended functions of the camera.
[Export Serial Code]/[Import Activation Code]/
[Activation List] s
[Demo Mode]
You can try focusing, peaking, etc. in [Post Focus]
(P129),
with the image picture. s
[Format]
The card is formatted. P28
:[Playback] menu
• [Slide Show] (P239)
• [Playback Mode]  (P240)
• [Location Logging]  (P241)
• [RAW Processing]  (P242)
• [4K PHOTO Bulk Saving]  (P244)
• [Light...

9. Using Menu Functions
238
∫How to select an image(s) after selecting [Single] or [Multi] • When [Single] and [Multi] are not available, select an image i n the same way as when [Single]
is selected.
[Single] setting1Press  2/1  to select the picture.2Press [MENU/SET].• If [Set/Cancel] is displayed at the right bottom of the
screen, the setting is canceled when [MENU/SET] is
pressed again.
[Multi] setting
When a screen similar to the one on the right is displayed:
1Press  3/4/ 2/1 to select the...

239
9. Using Menu Functions
You can play back the pictures you have taken in synchronization with music, and you can
do this in sequence while leaving a fixed interval between each of the pictures.
You can also put together a slide show composed of only still p ictures, only motion
pictures, etc.
We recommend this feature when you view your pictures by connecting the camera to a
TV.
>  [Playback]  > [Slide Show]
1Select the group to play back by pressing  3/4, and then press [MENU/SET].• If you select...

9. Using Menu Functions
240
∫Changing the slide show settings
You can change the settings for slide show playback by selectin g [Effect] or [Setup] on the
slide show menu screen.
• Even if [Effect] is set, it does not work during a slide show  of 4K burst files, Images recorded
with [Post Focus], or Group Pictures.
• When playing back the following pictures, the [Duration] setti ng is disabled.
– Motion pictures
– 4K burst files
– Images recorded with [Post Focus]
– Panorama pictures
– Group Pictures...
