Panasonic Dmc Fz2500 Operating Instructions Manual
Here you can view all the pages of manual Panasonic Dmc Fz2500 Operating Instructions Manual. The Panasonic manuals for Digital Camera are available online for free. You can easily download all the documents as PDF.
Page 221
![Page 221
221
9. Using Menu Functions
[Quick AF]As long as the camera is held steady, the camera will
automatically adjust the focu
s and focus adjustment will
then be quicker when the shutter is pressed.• The battery will be consumed faster than usual.
• This function is not available in the following cases: – In Preview Mode
– In low light situations s
[Eye Sensor AF]
The camera automatically adjusts the focus when the eye
sensor is active.
• [Eye Sensor AF] may not work in dimly lit conditions. s
[Pinpoint...](http://img.usermanuals.tech/thumb/58/65483/w300_dmc-fz2500_en_adv_om_d-220.png "Page 221
221
9. Using Menu Functions
[Quick AF]As long as the camera is held steady, the camera will
automatically adjust the focu
s and focus adjustment will
then be quicker when the shutter is pressed.• The battery will be consumed faster than usual.
• This function is not available in the following cases: – In Preview Mode
– In low light situations s
[Eye Sensor AF]
The camera automatically adjusts the focus when the eye
sensor is active.
• [Eye Sensor AF] may not work in dimly lit conditions. s
[Pinpoint...")
221 9. Using Menu Functions [Quick AF]As long as the camera is held steady, the camera will automatically adjust the focu s and focus adjustment will then be quicker when the shutter is pressed.• The battery will be consumed faster than usual. • This function is not available in the following cases: – In Preview Mode – In low light situations s [Eye Sensor AF] The camera automatically adjusts the focus when the eye sensor is active. • [Eye Sensor AF] may not work in dimly lit conditions. s [Pinpoint...
Page 222
![Page 222
9. Using Menu Functions
222
[Direct Focus Area]Moves the AF area or MF assist using the cursor button
when recording.
• When [
š], [ ], [ ], or [ Ø] is selected, the AF area
can be moved; when [ ] is selected, the enlarged
position can be moved.
• To set the items that use the cursor buttons like [White Balance] or [Sensitivity], use the Quick Menu (P53)
instead.
• [Direct Focus Area] is fixed to [OFF] in the following cases:
– [Glistening Water] (Scene Guide Mode)
– Creative Control Mode
– When...](http://img.usermanuals.tech/thumb/58/65483/w300_dmc-fz2500_en_adv_om_d-221.png "Page 222
9. Using Menu Functions
222
[Direct Focus Area]Moves the AF area or MF assist using the cursor button
when recording.
• When [
š], [ ], [ ], or [ Ø] is selected, the AF area
can be moved; when [ ] is selected, the enlarged
position can be moved.
• To set the items that use the cursor buttons like [White Balance] or [Sensitivity], use the Quick Menu (P53)
instead.
• [Direct Focus Area] is fixed to [OFF] in the following cases:
– [Glistening Water] (Scene Guide Mode)
– Creative Control Mode
– When...")
9. Using Menu Functions 222 [Direct Focus Area]Moves the AF area or MF assist using the cursor button when recording. • When [ š], [ ], [ ], or [ Ø] is selected, the AF area can be moved; when [ ] is selected, the enlarged position can be moved. • To set the items that use the cursor buttons like [White Balance] or [Sensitivity], use the Quick Menu (P53) instead. • [Direct Focus Area] is fixed to [OFF] in the following cases: – [Glistening Water] (Scene Guide Mode) – Creative Control Mode – When...
Page 223
![Page 223
223
9. Using Menu Functions
[MF Guide]When you set the focus
manually, an MF guide that
allows you to check the
direction to achieve focus is
displayed.
A
Indicator for ¶ (infinity) s
[Peaking]In-focus portions (portions on the screen with clear
outlines) are highlighted when focus is being adjusted
manually.
• When [Detect Level] in [SET]
is set to [HIGH], portions to
be highlighted are reduced, allowing you to achieve a
more precise focus.
• Changing the [Detect Level] setting also changes...](http://img.usermanuals.tech/thumb/58/65483/w300_dmc-fz2500_en_adv_om_d-222.png "Page 223
223
9. Using Menu Functions
[MF Guide]When you set the focus
manually, an MF guide that
allows you to check the
direction to achieve focus is
displayed.
A
Indicator for ¶ (infinity) s
[Peaking]In-focus portions (portions on the screen with clear
outlines) are highlighted when focus is being adjusted
manually.
• When [Detect Level] in [SET]
is set to [HIGH], portions to
be highlighted are reduced, allowing you to achieve a
more precise focus.
• Changing the [Detect Level] setting also changes...")
223 9. Using Menu Functions [MF Guide]When you set the focus manually, an MF guide that allows you to check the direction to achieve focus is displayed. A Indicator for ¶ (infinity) s [Peaking]In-focus portions (portions on the screen with clear outlines) are highlighted when focus is being adjusted manually. • When [Detect Level] in [SET] is set to [HIGH], portions to be highlighted are reduced, allowing you to achieve a more precise focus. • Changing the [Detect Level] setting also changes...
Page 224
![Page 224
9. Using Menu Functions
224
[Histogram]This allows you to set either to display or not display the
histogram.
You can set the position by pressing
3/4/ 2/1.
• Direct touch operation is also possible from the recording screen.
• A histogram is a graph that displays brightness along the
horizontal axis (black to white)
and the number of pixels at each
brightness level on the vertical
axis.
It allows you to easily check a picture’s exposure.
A dark
B bright
• When the recorded picture and the...](http://img.usermanuals.tech/thumb/58/65483/w300_dmc-fz2500_en_adv_om_d-223.png "Page 224
9. Using Menu Functions
224
[Histogram]This allows you to set either to display or not display the
histogram.
You can set the position by pressing
3/4/ 2/1.
• Direct touch operation is also possible from the recording screen.
• A histogram is a graph that displays brightness along the
horizontal axis (black to white)
and the number of pixels at each
brightness level on the vertical
axis.
It allows you to easily check a picture’s exposure.
A dark
B bright
• When the recorded picture and the...")
9. Using Menu Functions 224 [Histogram]This allows you to set either to display or not display the histogram. You can set the position by pressing 3/4/ 2/1. • Direct touch operation is also possible from the recording screen. • A histogram is a graph that displays brightness along the horizontal axis (black to white) and the number of pixels at each brightness level on the vertical axis. It allows you to easily check a picture’s exposure. A dark B bright • When the recorded picture and the...
Page 225
![Page 225
225
9. Using Menu Functions
[Highlight]When the Auto Review function is
activated or when playing back, white
saturated areas appear blinking in
black and white.
• If there are any white saturated
areas, we recommend compensating the exposure
towards negative (P103) referring to the histogram (P224)
and then taking the picture again. It may result in a better
quality picture.
• This function is disabled during 4K photo playback,
playback of pictures taken with Post Focus, Multi
Playback,...](http://img.usermanuals.tech/thumb/58/65483/w300_dmc-fz2500_en_adv_om_d-224.png "Page 225
225
9. Using Menu Functions
[Highlight]When the Auto Review function is
activated or when playing back, white
saturated areas appear blinking in
black and white.
• If there are any white saturated
areas, we recommend compensating the exposure
towards negative (P103) referring to the histogram (P224)
and then taking the picture again. It may result in a better
quality picture.
• This function is disabled during 4K photo playback,
playback of pictures taken with Post Focus, Multi
Playback,...")
225 9. Using Menu Functions [Highlight]When the Auto Review function is activated or when playing back, white saturated areas appear blinking in black and white. • If there are any white saturated areas, we recommend compensating the exposure towards negative (P103) referring to the histogram (P224) and then taking the picture again. It may result in a better quality picture. • This function is disabled during 4K photo playback, playback of pictures taken with Post Focus, Multi Playback,...
Page 226
![Page 226
9. Using Menu Functions
226
[Monochrome Live
View]You can display the recording screen in black and white.
This function is convenient when a black and white screen
will make it easier to set focus with Manual Focus.
• Even if you use the HDMI output during recording, this
function will not work for the connected device.
• Recorded images will not be affected. s
[Constant Preview]
You can check the effects of the chosen aperture and
shutter speed on the recording screen in Manual Exposure
Mode.
•...](http://img.usermanuals.tech/thumb/58/65483/w300_dmc-fz2500_en_adv_om_d-225.png "Page 226
9. Using Menu Functions
226
[Monochrome Live
View]You can display the recording screen in black and white.
This function is convenient when a black and white screen
will make it easier to set focus with Manual Focus.
• Even if you use the HDMI output during recording, this
function will not work for the connected device.
• Recorded images will not be affected. s
[Constant Preview]
You can check the effects of the chosen aperture and
shutter speed on the recording screen in Manual Exposure
Mode.
•...")
9. Using Menu Functions 226 [Monochrome Live View]You can display the recording screen in black and white. This function is convenient when a black and white screen will make it easier to set focus with Manual Focus. • Even if you use the HDMI output during recording, this function will not work for the connected device. • Recorded images will not be affected. s [Constant Preview] You can check the effects of the chosen aperture and shutter speed on the recording screen in Manual Exposure Mode. •...
Page 227
![Page 227
227
9. Using Menu Functions
[Video-Priority Display]Switches screens to those suitable for motion picture
recording.
• The exposure compensation value display will be
switched within the available range for motion pictures.
When adjusting the exposure compensation, the range
available only for pictures will be indicated as [ ].
• The icons for functions that are not available for motion
pictures, such as the ones for the flash or the number of
pixels, will not be displayed. s
[Auto Review]Displays...](http://img.usermanuals.tech/thumb/58/65483/w300_dmc-fz2500_en_adv_om_d-226.png "Page 227
227
9. Using Menu Functions
[Video-Priority Display]Switches screens to those suitable for motion picture
recording.
• The exposure compensation value display will be
switched within the available range for motion pictures.
When adjusting the exposure compensation, the range
available only for pictures will be indicated as [ ].
• The icons for functions that are not available for motion
pictures, such as the ones for the flash or the number of
pixels, will not be displayed. s
[Auto Review]Displays...")
227 9. Using Menu Functions [Video-Priority Display]Switches screens to those suitable for motion picture recording. • The exposure compensation value display will be switched within the available range for motion pictures. When adjusting the exposure compensation, the range available only for pictures will be indicated as [ ]. • The icons for functions that are not available for motion pictures, such as the ones for the flash or the number of pixels, will not be displayed. s [Auto Review]Displays...
Page 228
![Page 228
9. Using Menu Functions
228
[Lens Position Resume]Remember the zoom position and focus position when the
camera is turned off.
s
[Lens Retraction]Retracts the lens barrel a little while after the playback
screen appears. s
[Q.MENU]If you select [CUSTOM], you can customize the Quick
Menu settings. P54
[Dial Set.]
Changes the operation methods of the front dial and rear
dial. P43
[Video Button]
Enables/disables the motion picture button. s
[Eye Sensor]Setting the eye sensor sensitivity and the method...](http://img.usermanuals.tech/thumb/58/65483/w300_dmc-fz2500_en_adv_om_d-227.png "Page 228
9. Using Menu Functions
228
[Lens Position Resume]Remember the zoom position and focus position when the
camera is turned off.
s
[Lens Retraction]Retracts the lens barrel a little while after the playback
screen appears. s
[Q.MENU]If you select [CUSTOM], you can customize the Quick
Menu settings. P54
[Dial Set.]
Changes the operation methods of the front dial and rear
dial. P43
[Video Button]
Enables/disables the motion picture button. s
[Eye Sensor]Setting the eye sensor sensitivity and the method...")
9. Using Menu Functions 228 [Lens Position Resume]Remember the zoom position and focus position when the camera is turned off. s [Lens Retraction]Retracts the lens barrel a little while after the playback screen appears. s [Q.MENU]If you select [CUSTOM], you can customize the Quick Menu settings. P54 [Dial Set.] Changes the operation methods of the front dial and rear dial. P43 [Video Button] Enables/disables the motion picture button. s [Eye Sensor]Setting the eye sensor sensitivity and the method...
Page 229
![Page 229
229
9. Using Menu Functions
: [Setup] menu
> [Setup]
[Online Manual][URL display]/[QR Code display]s
[Clock Set] Setting Date/Time. P33
[World Time]Sets the times for the region where you live and your
holiday destination.
• [Destination] can be set after setting up [Home].
After selecting [Destination] or [Home], press
2/1
to select an area, and press [MENU/SET] to set.
“ [Destination]:
Travel destination area
A Current time of the
destination area
B Time difference from
home area
– [Home]:
Your...](http://img.usermanuals.tech/thumb/58/65483/w300_dmc-fz2500_en_adv_om_d-228.png "Page 229
229
9. Using Menu Functions
: [Setup] menu
> [Setup]
[Online Manual][URL display]/[QR Code display]s
[Clock Set] Setting Date/Time. P33
[World Time]Sets the times for the region where you live and your
holiday destination.
• [Destination] can be set after setting up [Home].
After selecting [Destination] or [Home], press
2/1
to select an area, and press [MENU/SET] to set.
“ [Destination]:
Travel destination area
A Current time of the
destination area
B Time difference from
home area
– [Home]:
Your...")
229 9. Using Menu Functions : [Setup] menu > [Setup] [Online Manual][URL display]/[QR Code display]s [Clock Set] Setting Date/Time. P33 [World Time]Sets the times for the region where you live and your holiday destination. • [Destination] can be set after setting up [Home]. After selecting [Destination] or [Home], press 2/1 to select an area, and press [MENU/SET] to set. “ [Destination]: Travel destination area A Current time of the destination area B Time difference from home area – [Home]: Your...
Page 230
![Page 230
9. Using Menu Functions
230
[Travel Date]
(continued)• You can display the elapsed days and travel destination
during playback or stamp them on recorded pictures in
[Text Stamp] (P249) .
• The number of days that have passed since the departure date can be printed out using the software
“ PHOTOfunSTUDIO ”
(P304).
• The travel date is calculated using the date in the clock setting and the departure date you set. If you set [World
Time] to the travel destination, the travel date is
calculated using...](http://img.usermanuals.tech/thumb/58/65483/w300_dmc-fz2500_en_adv_om_d-229.png "Page 230
9. Using Menu Functions
230
[Travel Date]
(continued)• You can display the elapsed days and travel destination
during playback or stamp them on recorded pictures in
[Text Stamp] (P249) .
• The number of days that have passed since the departure date can be printed out using the software
“ PHOTOfunSTUDIO ”
(P304).
• The travel date is calculated using the date in the clock setting and the departure date you set. If you set [World
Time] to the travel destination, the travel date is
calculated using...")
9. Using Menu Functions 230 [Travel Date] (continued)• You can display the elapsed days and travel destination during playback or stamp them on recorded pictures in [Text Stamp] (P249) . • The number of days that have passed since the departure date can be printed out using the software “ PHOTOfunSTUDIO ” (P304). • The travel date is calculated using the date in the clock setting and the departure date you set. If you set [World Time] to the travel destination, the travel date is calculated using...
