Panasonic Dmc Fz2500 Operating Instructions Manual

41
2. Getting Started/Basic Operations
• This owner’s manual describe operations of the front dial/rear dial as follows:
e.g.: When rotating the front dial to the left or right:
e.g.: When rotating the rear dial to the left or right:
Allows you to set the aperture, shutter speed, and other settin gs when in ///
modes.
• In [Dial Set.] in the [Custom] menu, you can change the operat ion methods of the front dial and
rear dial.  (P43)
Temporarily changing the items assigned to the front/rear dials...

2. Getting Started/Basic Operations
42
2Rotate the front/rear dials while the guide is
displayed.
• The settings of the items assigned to the dials will change.
3Press [MENU/SET] and set.• You can also complete this step by performing either of the operations below:
– Press the shutter button halfway
– Press [Fn3]
• Items that are temporarily assigned to the front/rear dials ca n be used only while the guide
(step
2) or setting screen (step3) is displayed.
• You can set the items to be assigned...

43
2. Getting Started/Basic Operations
∫Setting the operation methods of the front dial and rear dial
>  [Custom]  > [Dial Set.]
[Assign Dial (F/SS)] Assigns the operations of the aperture value and shutter speed
in Manual Exposure Mode.
[F SS]:
Assigns the aperture value to the front dial, and the shutter
speed to the rear dial.
[SS F]:
Assigns the shutter speed to the front dial, and the aperture
value to the rear dial.
[Rotation (F/SS)]
Changes the rotation direction of the dials for adjusting the...

2. Getting Started/Basic Operations
44
Using the [ND FILTER] switch, you can switch the built-in
optical ND filter setting. (The filter adjusts the amount of
light.)
• Use this function when recording a bright subject outdoors under a clear sky that causes the screen to look white.
[ND FILTER] switch (switching the ND filter setting)
[AUTO] Controls the ND filter automatically according to the recording  condition.
[1/4]Reduces the amount of light to 1/4.
[1/16] Reduces the amount of light to 1/16....

45
2. Getting Started/Basic Operations
Pressing the cursor button:
Selection of items or setting of values etc., is performed.
Pressing [MENU/SET]:
Confirmation of setting contents, etc., is performed.
• This owner’s manual expresses the up, down, left, and right of
the cursor button as  3/4/2 /1.
Press [DISP.] to switch the information displayed on the
screen.
• If the information on the screen is not displayed any longer
because no operation was performed for some time, press the
[DISP.] button or...

2. Getting Started/Basic Operations
46
∫[ ] Live View Finder style display layout  (Example of viewfinder style display)
∫ [ ] Monitor style display layout  (Example of monitor style display)
¢When the on-monitor recording information screen is displayed,  you can touch the desired
item and change its setting directly.
With information
(detailed
information) With information With information
(detailed
information
, tilt
sensor display) With information
(tilt sensor
display)
With information...

47
2. Getting Started/Basic Operations
∫About the tilt sensor display
With the tilt sensor displayed, it is easy to correct the tilt  of the camera etc.
• When the tilt of the camera is little, the indicator changes t o green.
¢ This is displayed if [Highlight]  (P225) in the [Custom] menu is set to [ON].
• Some of the screens cannot be displayed for certain files that  you play back, such as motion
pictures and 4K burst files.
A
Horizontal direction : Correcting tilt to the left
B Vertical direction :...

2. Getting Started/Basic Operations
48
Touch screen of this unit is capacitive. Touch the panel directly with your bare finger.
∫ Touch
To touch and release the touch screen.
∫ Drag
A movement without releasing the touch screen.
∫ Pinch (enlarge/reduce)
Pinch the touch screen apart (enlarge) or together
(reduce) with two fingers.
Touch screen (Touch operations)
• Touch the screen with the clean and dry finger.
• If you use a commercially available monitor protection sheet,  please follow the...

49
2. Getting Started/Basic Operations
Applicable modes:
Just by touching the subject you want as your point of focus, the camera will focus on the
subject and take the picture automatically.
∫ To cancel the Touch Shutter function
Touch [ ] .
Taking Pictures Using the Touch Function
Taking pictures using the Touch Shutter function
1Touch [ ].
2Touch [ ].
• Icon will change to [ ], and taking a picture with the  Touch Shutter function becomes possible.
3Touch the subject you wish to focus on, and
then...

2. Getting Started/Basic Operations
50
Applicable modes:
You can easily optimize the brightness for a touched position. When the face of the subject
appears dark, you can brighten the screen according to the brig htness of the face.
∫ Canceling the Touch AE function
Touch [ ] .
• [Metering Mode] returns to the original setting, and the brigh tness optimization position is
canceled.
Easily Optimizing the Brightness for a Specified Area (Touch AE )
1Touch [ ].
2Touch [ ].
• The setting screen for the...
