Panasonic Dmc Fz2500 Operating Instructions Manual

91
4. Focus, Brightness (Exposure) and Color tone Settings
Applicable modes:
This allows the focusing method that suits the positions and number of the subjects to be
selected.
Auto Focus Mode
([Face/Eye
Detection]) The camera automatically detects the person’s face
and eyes.
An eye closer to the camera will be in focus, while
the exposure will be optimized for the face.
(When [Metering Mode] is set to [ ])
• Up to 15 faces can be detected. Eyes that can be
detected are only those of the face that...

4. Focus, Brightness (Exposure) and Color tone Settings
92
∫Restrictions on Auto Focus Mode• The AF Mode is fixed to [Ø ] in the following cases.
– When using the Digital Zoom
– [Miniature Effect] (Creative Control Mode)
• The Auto Focus Mode is fixed to [ š] when [4K Live Cropping] is set.
• It cannot be set the Auto Focus Mode in the following cases. – When recording with the Post Focus function
– When [Pull Focus] in [Snap Movie] is set to [ON]
([Face/Eye Detection])
• It cannot be set to [ š] in the...

93
4. Focus, Brightness (Exposure) and Color tone Settings
When the camera detects a face, the AF area and the mark
indicating the eye to be in focus are displayed.
AThe eye to be in focus
Yellow:
When the shutter button is pressed halfway, the frame turns
green when the camera is focused.
White:
Displayed when more than one face is detected. Other faces
that are the same distance away as faces within the yellow AF a reas are also focused.
∫ Changing the eye to be in focus
Touch the eye to be in...

4. Focus, Brightness (Exposure) and Color tone Settings
94
Selecting from 49 AF areas, you can freely set the optimum shape of the AF area for the
subject.
1Press  2 ().
2Select a Custom Multi icon ([ ], etc.), and press 3.3Press  2/1  to select a setting.A The current shape of the AF area
4Press  4.
5Select AF areas.• The selected AF areas are displayed in yellow.
Setting the shape of the AF area ([Custom Multi])
([Horizontal
Pattern]) Horizontal line
This shape is
convenient for taking
panning...

95
4. Focus, Brightness (Exposure) and Color tone Settings
When selecting [ ]/[ ]/[ ]
When selecting [ ]/[ ]/[ ]
Drag your finger over the parts you want to set as AF
areas.
• If you touch one of the selected AF areas, the selection of the area will be canceled.
Press  3/4/2 /1  to select the AF area, and then press [MENU/SET] to set (repea t).• The setting is canceled when [MENU/SET] is pressed again.
• If you press [DISP.], all the selections will be canceled.
6Press [Fn5].
∫ Registering the set AF...

4. Focus, Brightness (Exposure) and Color tone Settings
96
Applicable modes:
When [š], [ ], [ Ø], or [ ] in Auto Focus Mode  is selected, you can change the
position and size of the AF area.
• Perform the operation after canceling the touch shutter functi on.
• You can also display the AF area setting screen by touching th e recording screen. (When
[Touch AF] of [Touch Settings] in the [Custom] menu is set to [ AF])
Position and size of the AF area can be changed.
1Press 2 ().
2Select [ š] or [Ø ] and...

97
4. Focus, Brightness (Exposure) and Color tone Settings
You can set the focus position by selecting the group of AF areas.
The 49 AF areas are divided into  groups, each consisting of
9 areas (on the edge of the screen, 6 or 4 areas).
1Press  2 ().2Select [ ] and press  4.3Press  3/4 /2 /1  to select an AF area group.
4Press [MENU/SET] to set.• Only [ i] display (center point of selected group) will remain on
the screen.
• Setting of the AF area frame is cleared when [MENU/SET] is  pressed or [ ] is...

4. Focus, Brightness (Exposure) and Color tone Settings
98
Applicable modes:
You can move the AF area displayed on the viewfinder by
touching the monitor.
• Press the shutter button halfway to determine the focus position.If you press [DISP.] before determining the focus position, the  AF area frame returns to the
center position.
• To cancel the AF area frame when the Auto Focus Mode  (P91) is set to [ š] ([Face/Eye
Detection]), [ ] ([Tracking]) or [ ] ([49-Area]), press [MENU/SET ].
Setting the AF...

99
4. Focus, Brightness (Exposure) and Color tone Settings
Applicable modes:
You can optimize the focus and brightness for the position you have touched.
1Select the menu. (P51)
2Touch the subject you want to optimize the
brightness for.
• The brightness optimization position is displayed on the
center of the AF area. The position follows the movement
of the AF area.
• [Metering Mode] is set to [ ] , which is used exclusively  for the Touch AE.
• Touching [Reset] returns the brightness optimization...

4. Focus, Brightness (Exposure) and Color tone Settings
100
Adjusting Focus Manually
Applicable modes:
Use this function when you want to fix the focus or when the distance between the lens
and the subject is determined and you do not want to activate A uto Focus.
1Set the focus mode lever to [MF].
2Press 2 ().
3Press 3/ 4/2/1 to adjust the focus position,
and press [MENU/SET].
• The assist screen is displayed, enlarging the area. (MF  Assist)
• You can also enlarge the area by rotating the focus ring...
