11
12.  Connecting to other equipment
Watching 4K motion pictures on a TV/
Saving 4K motion pictures on your PC or recorder ...............................................339
• Watching motion pictures in 4K ....................................................................339
• Storing 4K motion pictures ................................... ........................................340
Playing Back Pictures on a TV Screen ........................... ......................................341
• Using...

12
Contents by Function
RecordingRecording Mode ............................. P46
[Preview]....................................... P100
Panorama Shot Mode .................. P102
[Multi Exp.].................................... P210
[Silent Mode] ................................ P212
[3D Rec] ....................................... P357
Focus (AF/MF) [Focus Mode]................................ P149
[AF Mode] ..................................... P151
Adjusting the AF area position ..... P157
[Manual...

13
Motion PictureCreative Video Mode ................... P126
[Silent Operation] ......................... P127
[Rec Format] ................................ P246
[Rec Quality] ................................ P246
Motion pictures in 4K ................... P245
Recording still pictures while
recording motion pictures............. P249
[Snap Movie] ................................ P251
Image [Luminance Level] ........................ P254
Audio [Mic Level Adj.]............................. P255
[Mic Level...

14
Playback[Auto Review] ................................. P45
Picture playback........................... P257
Motion picture playback ............... P258
Playback Zoom ............................ P260
Multi Playback .............................. P260
[Delete]......................................... P264
Playback/display settings [Slide Show] ................................. P267
[Rotate]/[Rotate Disp.].................. P284Edit
[RAW Processing] ........................ P271
[Clear Retouch]...

15
1.  Before Use
Care of the camera
Do not subject to strong vibration, shock, or pressure.
•The lens, monitor, or external case may be damaged if used in t he
following conditions.
It may also malfunction or image may not be recorded if you:
–Drop or hit the camera.–Press hard on the lens or the monitor.
This camera is not dust/drip/water proof.
Avoid using the camera in places with a lot of dust, water, san d,
etc.
•
Liquid, sand and other foreign material may get into the space around
the lens,...

1. Before Use
16
Standard Accessories
Check that all the accessories are supplied before using the camera.
•
The accessories and their shape will differ depending on the country or area where the camera
was purchased.
For details on the accessories, refer to “Basic Owner’s Manual”.
•Battery Pack is indicated as battery pack or battery  in the text.•Battery Charger is indicated as  battery charger or charger  in the text.
•SD Memory Card, SDHC Memory Card and SDXC Memory Card are indicated as  card in...

17
1. Before Use
Names and Functions of Components
∫Camera body
6
4
20 19
23 2122 12 13
18
7
9
10 17
132
185
14
11
8
15
16
1Focus distance reference mark (P168)
2
Status indicator (P41)/
Wi-Fi® connection lamp  (P291)•The lamp lights green when the camera is
turned on, and lights blue when it is
connected to Wi-Fi.
3Camera ON/OFF switch  (P41)
4Motion picture button (P242)
5[ ] (Exposure Compensation) button
(P173)/[Fn1] button  (P70)
6Function button (Fn11) (P70)
7Rear dial (P47)
8Shutter button...

1. Before Use
18
0ê0ô0ð
0ç10Ô
2436
39
40
41
27 28
31
3233
30
29
45 42
44 43
37
38
35 34
2526
24Touch screen  (P59)/monitor (P365)
25[LVF] button (P57)/[Fn5] button  (P70)
26Flash open button (P230)•The flash opens, and recording with the flash
becomes possible.
27Eye sensor (P57)
28Viewfinder (P57)
29Eye Cup (P403)
30[Q.MENU] button  (P66)/[Fn2] button  (P70)
31[(] (Playback) button  (P257)
32
Speaker (P75)•Be careful not to cover the speaker with your
finger. Doing so may make sound difficult to...

19
1. Before Use
∫Lens
H-FS1442A 1 Lens surface
2Tele
3 Focus ring (P165)
4 Zoom ring  (P224)
5Wide
6 Contact point
7 Lens fitting mark  (P36)
8 [O.I.S.] switch  (P222)
H-FS45150
H-FS14140
345 6 712
34 6 7
15 2
13248567

1. Before Use
20
About the Lens
This unit can use the dedicated lenses compatible with
the Micro Four ThirdsTM System lens mount specification
(Micro Four Thirds mount).
You can also use a lens of any of the following
standards by attaching a mount adaptor.
•
For certain lenses, the actual distance at which the subject is  in focus may differ slightly from
the rated distance.
•When using a Leica lens mount adaptor, set [Shoot w/o Lens]  (P37) to [ON].
There are functions that cannot be used, or the...
