Panasonic Dmc G7 Owners Manual

51
2. Getting Started/Basic Operations
Press [DISP.] to switch the information displayed on the
screen.
•
You can select between [ ] (monitor style) and [ ] (viewfinder style) for each of the
monitor and the viewfinder display screen using [Monitor Disp. Style] and [LVF Disp.Style] in
the [Custom] menu.
([ ] monitor style)
•Screen will switch as follows:
(Example of monitor display)
¢ 1 Histograms are displayed when the [Histogram] of the [Custom]  menu is set to [ON].
It is also possible to display...

2. Getting Started/Basic Operations
52
([ ] viewfinder style)
•Screen will switch as follows:
(Example of display on viewfinder)
¢ Histograms are displayed when the [Histogram] of the [Custom] m enu is set to [ON]. (P53)
It is also possible to display the Exposure meter by setting th e [Expo.Meter] of the [Custom]
menu to [ON].  (P93)
•If approximately 1 minute elapses without an operation being per formed, the display will
disappear.
Press [DISP.] or touch the monitor to make the display reappear ....

53
2. Getting Started/Basic Operations
Displaying/not displaying the histogram
You can set the position by pressing 3/4/2 /1.•Direct touch operation is also possible from the recording scre en.
•A histogram is a graph that displays brightness along the
horizontal axis (black to white) and the number of pixels at each
brightness level on the vertical axis.
It allows you to easily check a picture’s exposure.
A dark
B bright
•When the recorded picture and the histogram do not match each o ther under the...

2. Getting Started/Basic Operations
54
∫About the tilt sensor display
With the tilt sensor displayed, it is easy to correct the tilt  of the camera etc.
1Press [DISP.] to display the tilt sensor.2Check the tilt of the camera.
AHorizontal direction:
Correcting tilt to the left
B Vertical direction:
Correcting downward tilt
•When the tilt of the camera is little, the indicator changes to  green.
•When recording with a vertical orientation, the display automat ically switches to a
vertically orientated...

55
2. Getting Started/Basic Operations
•Screen will switch as follows:
¢ 1 If approximately 1 minute elapses without an operation being pe rformed, the display will
disappear.
Press [DISP.] or touch the monitor to make the display reappear .
¢ 2 Not displayed while using the playback zoom or during motion p icture playback, sequential
playback, panorama playback or a slide show.
¢ 3 This is displayed if [Highlight]  (P56) in the [Custom] menu is set to [ON].
¢ 4 If no operation is performed for a...

2. Getting Started/Basic Operations
56
Displaying/not displaying white saturated areas>  [Custom]  > [Highlight]  > [ON]/[OFF]
When the Auto Review function is activated or when playing back , white saturated areas
appear blinking in black and white.
This does not affect the recorded image.
•
If there are any white saturated areas, we
recommend compensating the exposure towards
negative  (P173) referring to the histogram  (P53) and
then taking the picture again. It may result in a better
quality...

57
2. Getting Started/Basic Operations
Press [LVF] to switch between the Monitor and Viewfinder.A[LVF] button
B Eye sensor
Press [LVF].
•The monitor/viewfinder will switch as follows:
¢ If [Eye Sensor AF] in the [Custom] menu is set to [ON], the cam era automatically adjusts the
focus as the eye sensor is activated.  (P58)
∫Notes on automatic viewfinder/monitor switching
Automatic viewfinder/monitor switching enables the eye sensor t o switch the display to the
viewfinder automatically when y ou bring...

2. Getting Started/Basic Operations
58
Setting the eye sensor sensitivity and the automatic switching of the display
between the Monitor and Viewfinder
Adjusting/not adjusting the focus automatically when the eye se nsor is
activated >  [Custom]  > [Eye Sensor AF]  > [ON]/[OFF]
•
Beep sounds are not emitted when the focus is achieved in [Eye  Sensor AF].•[Eye Sensor AF] may not work in dimly lit conditions.
•The [Eye Sensor AF] feature is disabled in the following conditions:–With lenses that only...

59
2. Getting Started/Basic Operations
Touch screen of this unit is capacitive. Touch the panel directly with your bare finger.
∫ Touch
To touch and release the touch screen.
•
When selecting features using the touch screen, be sure
to touch the center of the desired icon.
∫ Drag
A movement without releasing the touch screen.
This can also be used to move to the next image during
playback, etc.
∫ Pinch (enlarge/reduce)
Pinch the touch screen apart (enlarge) or together
(reduce) with two fingers.
Touch...

2. Getting Started/Basic Operations
60
Enabling/disabling the touch operation
•
When set to [OFF], no corresponding touch tab or touch icon is  displayed on the screen.
•Touch the screen with the clean and dry finger.•If you use a commercially available monitor protection sheet, please follow the instructions that
accompany the sheet.
(Some monitor protection sheets may impair visibility or operab ility.)
•Do not press on the monitor with hard pointed tips, such as ball point pens.•Do not operate with...
