Panasonic Dmc G7 Owners Manual

71
2. Getting Started/Basic Operations
¢Function button settings at the time of purchase.
∫Configuring the function button settings from the on-monitor recording
information screen
Touching [Fn] on the on-monitor recording information screen  (P51) also allows you to
display the screen in step
2.
∫ Using function buttons with touch operations
[Fn6], [Fn7], [Fn8], [Fn9], and [Fn10] are used by touching function buttons.
1Touch [ ].
2Touch [Fn6], [Fn7], [Fn8], [Fn9] or [Fn10].
•The assigned function will...

2. Getting Started/Basic Operations
72
•Some functions cannot be used depending on the mode or displayed screen.
•When using [Ex. Tele Conv.] (still pictures), check that [Picture Size] is set to [M] or [S].•When set to [Focus Area Set], it is possible to display the pos ition setting screen of either AF
area or MF Assist.
•Operations of the cursor button and [MENU/SET] are disabled whe n [Cursor Button Lock] is
set. Press the function button again to enable them.
•When [Restore to Default] is set,...

73
2. Getting Started/Basic Operations
Configuring basic settings of this unit
(Setup Menu)
For details on how to select the [Setup] menu settings, refer to P63 .
[Clock Set] and [Economy] are important items.
Check their settings before using the camera.
•
Refer to P41  for details.
•Press 3 if you are using Daylight Savings [ ]. (The time will move forw ard by 1 hour.)
Press  3 once more to return to the normal time.
•If you cannot find the travel destination in the areas displaye d on the screen, set...

2. Getting Started/Basic Operations
74
•The number of days that have passed since the departure date can be printed out using the
“ PHOTOfunSTUDIO ” bundled software on the DVD (supplied).
•The travel date is calculated using the date in the clock setti ng and the departure date you set.
If you set [World Time] to the travel destination, the travel d ate is calculated using the date in
the clock setting and the travel destination setting.
•The [Travel Date] feature is dis abled when recording [AVCHD]...

75
2. Getting Started/Basic Operations
•When [Silent Mode] is set to [ON], [Beep Volume] and [E-Shutter Vol] is set to [OFF].
•When [Live View Mode] is set to [30fps] the image quality on the recording screen may be
worse than when it is set to [60fps], but this does not affect  the recorded image.
•In a dark environment, the frame rate may become slower.
•The viewfinder is fixed to [60fps].•When using the AC adaptor (optional), [Live View Mode] is fixed  to [60fps].•[Live View Mode] is disabled while...

2. Getting Started/Basic Operations
76
•It will adjust the monitor when the monitor is in use, and the viewfinder when the viewfinder is in
use.
•Some subjects may appear differently from actuality on the moni tor. However, this does not
affect the recorded pictures.
•The brightness of pictures displayed on the monitor is enhanced , so some subjects on the
monitor may appear different from the actual subjects. However, this enhancement does not
affect recorded pictures.
•The monitor automatically...

77
2. Getting Started/Basic Operations
•Press the shutter button halfway or turn the camera off and on to cancel [Sleep Mode].
•To turn the monitor/viewfinder on again, press any button or touch the monitor.•When the monitor/viewfinder automatic switching (P57) is activated, [Auto LVF/Monitor Off] is
canceled.
•[Economy] does not work in the following cases.–When connecting to a PC or a printer–When recording or playing back motion pictures
–During a slide show–When recording with [ ] ([4K Pre-Burst])...

2. Getting Started/Basic Operations
78
[TV Connection]
This sets how the unit connects to a television etc.
[TV Aspect]:
Set to match the type of TV.[16:9]:
When connecting to a 16:9 screen TV.
[4:3]:
When connecting to a 4:3 screen TV.
•
This will work when the AV cable (optional) is connected.
[HDMI Mode (Play)]:
Set the format for the HDMI output when playing back on the
HDMI compatible high-definition TV connected with this unit usi ng
the HDMI micro cable. [AUTO]:
The output resolution is...

79
2. Getting Started/Basic Operations
•Set the background color for the menu screen.
[TV Connection]
[HDMI Info Display (Rec)]:
Set whether or not to display information when recording an
image on the camera while monitoring it on a TV.
[ON]:The camera display is output as is.
[OFF]: Only images are output.
•
This will work when the HDMI micro cable is connected.•When the camera is connected to a TV, lower the volume of the T V.
[3D Playback]:
Set the output method for 3D pictures.
[]: Set when...

2. Getting Started/Basic Operations
80
•If you set a different language by mistake, select [~] from the menu icons to set the desired
language.
•This enables the firmware versions of the camera and lens to be  checked.•Press [MENU/SET] on the version display screen to display infor mation about the software on
the unit.
•The folder number is updated and the file number starts from 00 01.•A folder number between 100 and 999 can be assigned.
The folder number should be reset before it reaches 999. We rec...
