Panasonic DmcFx7 Operating Instructions Manual

Others
91
Others
Screen Display
∫In recording
1 Recording mode
2 Flash (P37)
3Burst (P44)
: Audio recording (P51, 63)
4 White balance (P60)
5 ISO sensitivity (P62)
6 Focus indication (P28)
7 Picture size (P62)
8 Quality (P63)
: Jitter alert indication (P30)
9 Battery indication (P13)
10 Color effect (P66)
11 Picture/Time remain
In Motion image mode: e.g. 11S
12 Card access indication (P16)
13 Recording indication
14 Histogram (P26)
15 Shutter speed indication (P28)
16 Aperture value indication (P28)
17...

Others
92
∫Recording in simple mode
1 Flash (P37)
2 Focus indication (P28)
3 Picture mode (P32)
: Jitter alert indication (P30)
4 Battery indication (P13)
5 Picture remain
6 Recording indication
7 Card access indication (P16)
8 AF area (P28)
9 Backlight compensation indication
(P34)
10 Current date and time (
P18)
 This is displayed for about 5 seconds
when turning the camera on, setting
the clock and after switching from the
playback mode to the simple mode.
11 Compensating backlight ON indication...

Others
93
∫In playback
1 Playback mode
2 DPOF (P72)
 (White):
DPOF setting for printing
 (Green):
DPOF setting for Slide Show
 (Green with number of prints):
DPOF setting for printing and
Slide Show
3 Protected picture (P74)
4 Picture with audio (P70)
5 Picture size (P62)
: In Motion image mode (P70)
6 Quality (P63)
/ : In Motion image mode (P51)
Simple mode (P32):
:ENLARGE
:4qk6q/10k15cm
:E-MAIL
7 Battery indication (P13)
8 Folder/File number
9 Page number/Total pictures
10 Histogram (P26)11...

Others
94
Cautions for Use
∫Optimal Use of the Camera
When carrying this camera, take care
not to drop or hit it.
 The outer case may be destroyed by the
strong shock, and it may cause
malfunction of this camera.
Keep the camera away from magnetized
equipment (such as a microwave oven,
TV, video game equipment, etc.).
 If you use the camera on or near a TV,
pictures and sounds may be disrupted
due to electromagnetic wave radiation.
 Do not use the camera near a cell phone
because doing so may...

Others
95
∫Battery
The battery is a rechargeable lithium ion
battery. Its ability to generate power is
based upon the chemical reaction that
takes place inside it. This reaction is
susceptible to the surrounding temperature
and humidity, and, if the temperature is too
high or too low, the operating time of the
battery will be shorter.
Be sure to remove the battery after use.
Store the removed battery in the battery
carrying case.
When you go out, bring charged spare
batteries.
 Be aware that...

Others
96
∫Card
While the card access indication
appears (the card is accessed), do not
open the Card/Battery Door to remove
the card, do not turn the camera off or
do not shake or cause impact to the
camera.
Do not leave the card in places where
there is high temperature or direct
sunlight, or where electromagnetic
waves or static electricity are easily
generated.
Do not bend or drop the card.
 The card may be damaged or the
recorded content may be damaged or
erased.
After use, be sure to...

Others
97
Message Display
[NO MEMORY CARD]
Insert the card.
[THIS MEMORY CARD IS PROTECTED]
Cancel the card lock.
[NO VALID IMAGE TO PLAY]
Play back after recording or after inserting
a card with a recorded picture.
[MEMORY CARD FULL /
NOT ENOUGH MEMORY IN THE CARD]
Insert a new card or delete the
unnecessary data.
[MODE DIAL IS NOT IN THE PROPER
POSITION]
This message appears when you turn the
camera on with the mode dial in the wrong
position.
Rotate the mode dial to the proper position.
[PLEASE...

Others
98
Troubleshooting
If you put the menu back to the settings at the time of purchase, the conditions may be
improved. Carry out the [RESET] in the setup menu. (P23)
ConditionsCauses
The camera will not turn
on.Is the battery inserted correctly? Check the direction of the
battery.
Is the battery sufficiently charged?
Use a battery that has been sufficiently charged.
The picture is not
displayed on the LCD
monitor.Is the power save mode (P21) or economy mode (P22)
activated? Press the shutter...

Others
99
ConditionsCauses
The recorded picture is
blurred.When taking a picture in shaded areas or indoors, the shutter
speed becomes slow and the optical Image Stabilizer
function may not work properly. In this case, we recommend
holding the camera with both hands firmly to take pictures
(P27). When the slow shutter (P65) is set, we recommend
using a tripod.
When the shutter button
is pressed halfway, a red
lamp turns on
sometimes.In dark places, the AF assist lamp (P65) lights red to make it...

Others
100
ConditionsCauses
Some pixels are inactive
or always lit on the LCD
monitor.This is not a malfunction.
These pixels do not affect the recorded pictures.
Noise appears on the
LCD monitor.In dark places, noise may appear to maintain the brightness
of the LCD monitor. This does not affect the pictures you are
recording.
A vertical red spectrum
appears on the LCD
monitor.This is called smear. It is specific to CCD, not a malfunction.
It appears when the subject has a bright part. It is...
