Panasonic DmcFx7 Operating Instructions Manual

Recording pictures (advanced)
61
∫Setting the White Balance manually
(White set )
Use this mode when you want to set the
white balance manually.
1Set to [ ] (White set) and then
press 1.
2Aim the camera at a sheet of white paper
or a similar white object so that the frame
on the center of the screen turns white
and then press 1.
∫Finely Adjusting the White Balance
(White Balance Fine Adjustment )
When you cannot acquire the desired hue
by setting the white balance, you can adjust
the white...

Recording pictures (advanced)
62
ISO sensitivity represents the sensitivity to
light in values. If you set the ISO sensitivity
higher, the camera becomes more suitable
for recording in dark places.
 When setting to [AUTO], the ISO
sensitivity is automatically adjusted in the
range described below according to the
brightness.
[ISO 80] – [ISO 200]
(It can be adjusted from [ISO100] to
[ISO400] when using the flash. However, it
is fixed to [ISO100] when the flash mode
is set to Slow sync./Red-eye...

Recording pictures (advanced)
63
You can select 2 types of quality
(compression rate) according to the usage
of the picture.
 Pictures may have a mosaic-like
appearance depending on the subject or
the recording condition.
 The number of recordable pictures
depends on the subject.
 The number of remaining pictures may not
correspond with recorded frames.
 Refer to P17 for the number of recordable
pictures.You can take a picture with audio.
 When you set [AUDIO REC.] to [ON],
[ ] appears on...

Recording pictures (advanced)
64
 When setting to 3-area-focusing, pictures may become still while being focused on,
however, this is not a malfunction.
 In the digital zoom or when you take  pictures in dark places, the AF area is
displayed on the center of the screen with
a size wider than usual.
 When multiple AF areas (max. 9 areas)  light at the same time, the camera is
focusing on all the AF areas.
The focus position is not predetermined
because it is set to the position the
camera...

Recording pictures (advanced)
65
Illuminating the subject with
the AF assist lamp allows
the camera to focus on the
subject in low light
conditions. When you press
the shutter button halfway in
dark places or other situations, an AF area
wider than usual appears and the AF assist
lamp 1 turns on.
 Be sure of the following points when the
AF assist lamp is in use.
– Do not look at the AF assist lamp
closely.
– Do not cover the AF assist lamp with
your fingers.
 In simple mode [ ], the setting...

Recording pictures (advanced)
66
It is possible to further magnify a subject
already magnified 3 times with the optical
zoom by 4 more times with the digital
zoom, thereby reaching a maximum of
12 times.
∫Entering the digital zoom range
When you rotate the zoom lever to the
extreme Tele position, the on-screen zoom
indication may momentarily pause. This is
not a malfunction.
You can enter the digital zoom range to
continuously rotate the zoom lever to Tele
or to release the zoom lever once and...

Recording pictures (advanced)
67
This camera allows you to create motion
picture files up to 20 seconds long by
connecting images recorded in flip
animation mode.
Example:
When capturing images of the subject in
sequence moving the camera little by little
and aligning the images, the subject looks
as if it is moving.
 You can play back created flip animations
with the same method used to play back
motion images. (P70)
1Select [FLIP ANIM.].
 A motion image file is created by putting
images...

Recording pictures (advanced)
68
3Capture images for flip animation.
 You can check the recorded image with
4 and the previous or following image
with 2/1.
 Delete unnecessary images with [ ]
button.
 You can record up to 100 pictures. The
number of recordable pictures
displayed is an approximation.
4Select [CREATE MOTION IMAGE].
5Select [FRAME RATE] and set the
number of frames.
6Select [CREATE MOTION IMAGE]
and create a flip animation.
 The file number appears after creating
a flip...

Recording pictures (advanced)
69
∫Deleting all still images used to create
flip animation
When selecting [DELETE STILL IMAGES]
in [FLIP ANIM.] menu, a confirmation
screen appears. Select [YES] with 4 and
then press 1.
 You cannot use the audio recording
function, burst mode and auto bracket.
 The images in each frame do not appear
in normal review. (P35)
 If you execute [CREATE MOTION
IMAGE], flip animation is made from all
pictures recorded for flip animation.
Delete unnecessary pictures.
...

Playback (advanced)
70
Playback (advanced)
Playing Back Pictures with Audio/Motion Images
∫Pictures with audio
Select the picture with audio icon [ ]
and
play back the audio.
∫ Motion images
Select the picture with the motion image
icon [ ] and play back the motion
images.
 The cursor displayed during  playback corresponds to  3/4 /
2/ 1.
 Motion image playback stops and the  normal playback is restored by pressing
4. ∫
Fast forwarding/Fast rewinding
During motion image playback, keep
pressing...
