Panasonic DmcFx7 Operating Instructions Manual

Playback (advanced)
71
Using the [PLAY] mode menu
You can rotate and display the recorded
pictures in increments of 90°.
This is a convenient function to play back
pictures on TV.
∫Example
When rotating clockwise ( )
Original
1Select [ROTATE].
2Select the picture to be rotated
and set it.
3Select the direction to rotate the
picture.
Rotating the Picture [ROTATE]
PLAY1/2
PROTECT
SLIDE SHOW
AUDIO DUB. ROTATE
DPOF PRINT
EXITMENUSELECT
MENU
The picture rotates clockwise in
increments of...

Playback (advanced)
72
 Still pictures can only be rotated in normal
playback. When playing back rotated
pictures in zoom playback or multi
playback, pictures appear in original
angle.
 Protected pictures cannot be rotated.
 When you play the picture on a PC, you
cannot play rotated pictures without an
OS or a software compatible with Exif.
 Exif is the file format for still pictures, to
which recording information and other can
be added, established by JEITA [Japan
Electronics and...

Playback (advanced)
73
∫Single setting
Select the picture and set the number of
prints.
 The number of prints can be set from 0 to
999.
 The number of prints icon [ ] appears.
 When the number of prints is set to “0”,
DPOF print setting is canceled.
∫ Multi setting
Select the pictures and set the number
of prints.
 Repeat the above procedure.
 The number of prints can be set from 0 to  999.
 The number of prints icon [ ] appears.
 When the number of prints is set to “0”,  DPOF print setting...

Playback (advanced)
74
 DPOF print setting is a convenient
function when you print pictures with
printers supporting DPOF printing. (P87)
 DPOF is the abbreviation for Digital Print
Order Format. This feature allows you to
write print information or other into the
images on the card and to use such
information on the DPOF-compliant
system.
 The setting of DPOF print will not be
applied to the DPOF setting of
Slide Show.
 If the file is not based on the DCF
standard, the DPOF print setting...

Playback (advanced)
75
 Close the menu by pressing the [MENU]
button 2 times after finishing the setting/
canceling.
∫Multi setting/To cancel all settings
Perform the same operation as in [Setting
the Picture to be Printed and the Number of
Prints [DPOF PRINT]]. (P72 – 73)
 If you want to delete protected pictures,
cancel the protect setting first.
 While this feature protects the pictures
from accidental erasure, formatting the
card will permanently delete all data.
(P80)
 The protect setting...

Playback (advanced)
76
 When the camera is connected to TV, the
audio of the pictures with audio can be
played back during Slide Show.
3Select [START].
4By pressing the [MENU] button,
the Slide Show stops.
∫SD Slide Show
If you insert a card including the SD
Slide Show edited with the [SD Viewer for
DSC] which is in the supplied CD-ROM,
and then turn the camera on in playback
mode, the confirmation screen appears.
Select [YES] and press 1 to start the SD
Slide Show. Select [NO] and press 1 to...

Playback (advanced)
77
You can record the audio after taking a
picture.
1Select [AUDIO DUB.].
2Select the picture and start audio
recording.
 When audio has already been
recorded, the confirmation screen
appears. Press 4 to select [YES], and
press 1 to start audio recording. (The
original audio is overwritten.)
 The audio dubbing cannot be used with
motion images and protected images.
3Stop audio recording.
 Even if you do not press 4, after about
10 seconds the audio recording stops...

Playback (advanced)
78
This function is useful if you want to reduce
the file size of the picture in cases when it
needs to be attached to an e-mail or
uploaded to a website.
1Select [RESIZE].
2Select the picture and set it.
 The following pictures cannot be resized.–Pictures equal to or smaller than
640k 480 pixels
–Pictures recorded after setting the  picture size to [HDTV]
–Motion images
–Flip animation
–Pictures with audio
–Rotated pictures (You can resize them
if you rotate them back to...

Playback (advanced)
79
Use this function when you trim
unnecessary parts of the recorded picture.
1Select [TRIMMING].
2Select the picture to trim and set
it.
 The following pictures cannot be
trimmed.
–Pictures smaller than 640k480 pixels
–Pictures recorded after setting the
picture size to [HDTV]
–Motion images
–Flip animation
–Pictures with audio
–Rotated pictures (You can trim them if
you rotate them back.)
3Enlarge or decrease the picture.
Trimming the Pictures [TRIMMING]
MENU
PLAY2/2...

Playback (advanced)
80
4Shift the picture and press the
shutter button fully to set.
5Select [YES] or [NO] and set it.
 When you select [YES], the picture is
overwritten.
 When the original picture is protected,
you cannot overwrite the resized
picture.
 It may not be possible to trim pictures
recorded with other equipment.
 The picture size of the trimmed pictures
may become smaller than that of the
original one depending on the cut size.
 The picture quality of the trimmed picture
may be...
