Panasonic DmcFx7 Operating Instructions Manual

Preparation
11
Quick Guide
This is the overview of the procedure to
record pictures with this camera. For each
operation, be sure to refer to the
corresponding pages.
1Charge the battery. (P12)
 When the camera is shipped, the
battery is not charged. Charge the
battery before use.
2Insert the battery and the card.
(P14, 15)
3Turn the camera on to take
pictures.
 Set the clock. (P18)
1Set the mode dial to [ ].
2Press the shutter button to take
pictures. (P28)
4Play back the pictures.
1Set...

Preparation
12
Charging the Battery with the Charger
When the camera is shipped, the battery is
not charged. Charge the battery before
use.
1Attach the battery with attention
to the direction of the battery.
2Connect the charger to the
electrical outlet.
 When the [CHARGE] indicator A lights
in green, charging starts.
 When the [CHARGE] indicator A turns
off (in about 120 minutes), charging is
completed.
3Detach the battery.
 After charging is completed, be sure to
disconnect the charger...

Preparation
13
About the Battery
∫Battery indication
The remaining battery power appears on
the screen. [It does not appear when you
use the camera along with the AC adaptor
(DMW-CAC2; optional).]
> > >
The indication turns red and blinks:
Recharge or replace the battery.
When the LCD monitor is set to off by the
economy mode, the status indicator blinks.
∫The lifetime of the battery
The number of recordable pictures by
CIPA standards
 CIPA is an abbreviation of [Camera &
Imaging Products...

Preparation
14
Inserting/Removing the Battery
 Check that the camera is turned off and
that the lens is retracted.
1Slide the card/battery door to
open it.
 Please be sure to use genuine
Panasonic batteries (CGA-S004A).
2Insert:
Insert the charged battery until it
clicks paying attention to the
direction of the battery.
Remove:
Slide the lock 1 to remove the
battery.
31Close the card/battery door.
2Slide the card/battery door to
the end and then close it firmly.
 If you will not be using the...

Preparation
15
Inserting /Removing the Card
 Check that the camera is turned off and
that the lens is retracted.
1Slide the card/battery door to
open it.
 The card and the data may be
damaged if it is inserted or removed
while the camera is on.
 We recommend using Panasonic’s SD
Memory Card. (Use only the genuine
SD card with SD Logo.)
2Insert:
Insert the card with the label side
facing the back of the camera
until it clicks.
Remove:
Push the card until it clicks, then
pull the card out...

Preparation
16
About the Card
∫Access to the card
While the card is being accessed
(Recognizing/Recording/Reading/
Deleting), the card access indication 1
lights.
When the card access indication 1 lights,
do not:
 turn the camera off.
 remove the battery or the card.
 shake or impact the camera.
The card and the data may be damaged
and the camera may not operate normally.
∫About handling a card
Store precious data to your PC (P85). The
data on the card may be damaged or lost
due to...

Preparation
17
Approximate number of recordable pictures and
the size
 If you select a larger picture size, you can print pictures clearly. When you select a
smaller picture size, you can store more pictures on a card though the picture quality is
deteriorated.
 The numbers are approximations. (If you mix Fine and Standard quality, the number of
recordable pictures changes.)
 The number of recordable pictures may vary depending on subjects.
 The remaining number of recordable pictures displayed...

Preparation
18
Setting Date/Time (Clock Set)
∫Initial setting
The clock is not set when the camera is
shipped. When you turn the camera on, the
following screen appears.
 Press the [MENU] button, the screen
shown in step 2 appears.
 The screen disappears in about
5 seconds. To access clock set menu,
start from step 1.
1Select [CLOCK SET] from the
[SETUP] menu. (P20)
2Set date and time.
2/1: Select the desired item.
3/4: Set date and time.
3Select [M/D/Y], [D/M/Y] or [Y/M/D].
 Close the...

Preparation
19
 When a fully charged battery has been
inserted for more than 24 hours, the clock
setting is stored (in the camera) for at
least 3 months even if the battery is
removed. (The storing time may be
shorter if the battery is not charged
sufficiently.)
If more than 3 months has passed, the
clock setting will be lost. In this case, set
the clock again.
 You can set the year from 2000 to 2099.
The 24-hour system is used.
 If you do not set the date, the date cannot
be printed when...

Preparation
20
Setup Menu
1Turn the camera on.
2Press the [MENU] button.
 The menu items depend on the mode
selected with the mode dial. In this
page, the items in normal picture mode
[ ] are indicated.
 The menu screen in simple mode [ ]
is different from the above screen.
(P32)
3Select the [SETUP] Menu.
 When rotating the zoom lever A toward
T, the page of the menu screen can be
forwarded. (vice versa)
4Select the desired item.
5Set the desired value.
 Close the menu by pressing the...
