Panasonic DmcFx7 Operating Instructions Manual

Preparation
21
You can control the following items on [SETUP] Menu.
MenuFunctions
MONITOR  Adjust the brightness of the LCD monitor in 7 steps.
AUTO REVIEW[OFF]:The recorded picture does not automatically appear.
[1SEC.]:The recorded picture automatically appears on the
screen for about 1 second.
[3SEC.]:The recorded picture automatically appears on the
screen for about 3 seconds.
[ZOOM]:The recorded picture automatically appears on the
screen for about 1 second. Then it is enlarged 4 times
and...

Preparation
22
MenuFunctions
ECONOMY
(works in modes
except playback
mode and simple
mode)The battery life is saved by turning the LCD monitor off
automatically.
(Press any button to recover from the economy mode.)
[OFF]:Economy mode cannot be activated.
[LEVEL1]:The LCD monitor turns off and the status indicator
turns on if you do not use the camera for about 15
seconds.
[LEVEL2]:The LCD monitor turns off and the status indicator
turns on if you do not use the camera for about 15
seconds or...

Preparation
23
 The settings on [BEEP LEVEL], [BEEP TONE], [NO.RESET] and [LANGUAGE] are also
reflected in simple mode [ ].
MenuFunctions
RESET The settings on the recording or the [SETUP] menu are reset to
the initial settings. However, the folder number and the clock
setting are not changed.
USB MODE Set the USB communication system. Set before connecting to a
PC or a printer. (P83)
VIDEO OUT
(Playback mode
only)[NTSC]:Video output is set to NTSC system.
[PAL]:Video output is set to PAL system....

Preparation
24
About the LCD Monitor
∫Selecting the screen to be used
ALCD monitor (LCD)
Press the [DISPLAY/PWR LCD] button to
switch to the screen to be used.
 When the menu screen appears, the
[DISPLAY/PWR LCD] button is not
activated. During 9 pictures multi playback
(P46) or playback zoom (P47), the
indications on the screen can be turned
on and off.
In simple mode [ ] (P32)
BDisplay
CNon-displayIn recording mode (P27)
DDisplay
EDisplay with histogram
FNon-display (Recording guide line)...

Preparation
25
∫To view the LCD monitor outdoors on
a bright sunny day (Power LCD
function)
When you press and hold the [DISPLAY/
PWR LCD] button for 1 second, the power
LCD function is activated, the LCD monitor
becomes brighter than usual and easier to
see outdoors.
 This function does not affect recorded
pictures.
 When you take pictures, the LCD monitor
automatically reverts back to the normal
brightness 30 seconds after the
[DISPLAY/PWR LCD] button is pressed. If
you press any button,...

Preparation
26
∫Histogram
 A histogram is a graph that displays  brightness along the horizontal axis (black
to white) and the number of pixels at each
brightness level on the vertical axis.
 It allows the camera  user to easily check
the way a picture is being exposed.
 It is very useful if manual adjustments of  the lens aperture and shutter speed are
available, especially in those situations
where automatic exposure may be difficult
due to uneven lighting. Using the
histogram feature will...

Recording pictures (basic)
27
Recording pictures (basic)
Taking Pictures
∫The Mode Dial
This camera has a mode dial to suit for recording of many kinds of scenes.
Select the desired mode and enjoy the variety of recording.
Rotate the mode dial slowly and match icon with mode dial indicator 1.
: Normal picture mode (P28)
Use this mode for usual recording.
: Simple mode (P32)
This is the recommended mode for
beginners.
: Macro mode (P50)
This mode allows you to take a picture
extremely close to the...

Recording pictures (basic)
28
∫Taking pictures
The camera automatically sets the shutter
speed and the aperture value according to
the brightness of the subject.
 Insert the charged battery. (P14)
 Insert the card. (P15)
1 1 Turn the camera on.
2 Set the mode dial to Normal
picture mode [ ].
2Aim the AF area  1 to the point
you want to focus and then press
the shutter button halfway  A.
 The focus indication 2 is lit and then
the aperture value  3 and the shutter
speed  4 are displayed.
3Take...

Recording pictures (basic)
29
∫AF/AE Lock (AF: Auto Focus/
AE: Auto Exposure)
When recording a picture of people with a
composition as the above picture, you
cannot focus on the subject because it is
out of AF area in usual operation.
In this case,
1Aim the AF area at the subject.
2Press the shutter button halfway to fix
the focus and the exposure.
3When the subject is focused, the focus
indication lights.
4Keeping the focus and the exposure
fixed, move the camera as you compose
the picture....

Recording pictures (basic)
30
∫Focusing
 The focus range is 1.64 feet (50 cm) – ¶
(Wide), 1.64 feet (50 cm) – ¶ (Tele).
 If you press the shutter button fully without  prefocusing, pictures may be blurry or
unfocused.
 When the focus indication is blinking, the  subject is not focused. Press the shutter
button halfway and focus on the subject
again.
 If the camera will not focus after a few  tries, turn it off and on and try again.
 In the following cases, the camera cannot  focus on subjects...
