6.3ReplacingtheRollers
Asaroughguideline,werecommendtoreplacethepaperfeedrollermoduleanddoublefeedprevention
rollerafterscanning350,000sheetsofpaper
.("350,000sheets"isbasedonscanninghigh-qualitywoodfree
paper.Dependingonthetypeofpaperandotherfactors,theactuallifetimefortherollersmaybeshorter.)
InUserUtility,youcancheckthenumberofsheetsthathavebeenscanned.
1. Pressandholdthepowerbuttonforonesecondormoretoturnof ftheunit
Page 52
3. Movethelever( )ofthepaperfeedrollermoduleintheorderindicatedbythearrow( , ),andthen pulloutthemoduletowardsyou. 4. Openthe"Rollerexchangekit(KV -SS063)"(soldseparately)andtakeoutthenewpaperfeedroller module. 6.3ReplacingtheRollers 52 1 2 1
Page 53
5. Installthenewpaperfeedrollermodule.
Page 54
6. Usetheindents( )topullthedoublefeedpreventionrollercovertowardsyoutoopenit. 7. Whilepullingthetab( )inthedirectionindicatedbythearrow,liftthedoublefeedpreventionroller( ) inthedirectionofthearrow .Then,pullouttherightshaft(whenfacingit)fromthenotchintheroller mount. 8. Openthe"Rollerexchangekit(KV -SS063)"(soldseparately)andtakeoutthenewdoublefeed preventionroller. 6.3ReplacingtheRollers 54 1 1 2
Page 55
9. Installthenewdoublefeedpreventionroller .
Page 56
10. Insertthetab( )intothenotchasshownintheillustration,andthenpushthedoublefeedprevention rollercoveruntilitclicksintoplacetocloseit. Notice
Page 57
7OptionalImprinterUnit 7.1InstallingtheImprinterUnitandInkCartridge Theimprinterunitcanbeusedtoprintinformationsuchasaname,thedateandtime,oraserialnumberon therearsideofthedocumentafterscanning. Notice
Page 58
4. Slidethecarriagetooneend,andtheninserttheupperpinstotheguidesbymatchingthegloveswith theguides. 5. Insertthelowerpinstotheguidesuntiltheyarelocked. 7.1InstallingtheImprinterUnitandInkCartridge 581 2 2
Page 59
6. Connectthecables. 7. Insertthecablesintheclamper . 7.1InstallingtheImprinterUnitandInkCartridge 59
Page 60
8. Removetheprotectivesheet. 9. Movethecarriagetothecartridgeexchangeposition. 10. Inserttheinkcartridgeintothecarriage. 7.1InstallingtheImprinterUnitandInkCartridge 60
