Page 61

11.
Lockthecartridgeadjustinglever .12.
Closetheimprinterdoor
 . 7.1InstallingtheImprinterUnitandInkCartridge
61

Page 62

7.2HowtoRemovetheInkCartridge
Removetheoldinkcartridgebeforeinstallinganewinkcartridge.
1. Pressandholdthepowerbuttonforonesecondormoretoturnof
ftheunit

Page 63

7.3Printing
Adjustingtheimprinterprintingposition
1. Movethecarriagetothedesiredprintingposition,andaligntheindicator( )withthe" "mark( ).

Page 64

7.4Cleaningtheinkcartridge
Ifprintingbecomesfaded,performthefollowings.

CleaningbyusingtheUserUtility
Clickthe[CleanImprinter@buttonontheUserUtilityprogram.
Thiswillhelpremovecloggingbyejectinginkfromtheprinthead.

Cleaningthedirtontheprinthead
Wipeandcleantheprintheadwithmoistenedtissuepaper
.
Donotuseanymaterialthatincludesalcohol.(Ex.:Rollercleaningpaper) Notice

Page 65

8Appendix
8.1T
roubleshooting
Ifaproblemoccurswhilethescannerisbeingused,checkthefollowingitemsandcheckthescannerstatus
inUserUtility.Iftheunitstillmalfunctions,turnitOFF,unplugthepowercordandcallforservice. Symptom PossibleCause Remedy
TheLED(Green)doesnot
lightwhentheunit

Page 66

Symptom
PossibleCause Remedy
Doublefeedingoccurs
frequently . Thepaperfeedroller,separation
roller

,ordoublefeedprevention
rollerisdirty. Cleanthepaperfeedroller,
separationroller
,ordoublefeed
preventionroller.(page48)
Thedoublefeeddetectorsaredirty. Cleanthedoublefeeddetectors.
(page47

)
Thepaperfeedroller,separation
roller
 ,ordoublefeedprevention
rollerhasbecomeworndown. Replacethepaperfeedroller
module,anddoublefeed
preventionroller...

Page 67

Symptom
PossibleCause Remedy
Thescanningdensityis
uneven. Thescanningglassesaredirty. Cleantheconveyorandscanning
glasses.(page
46)
Thecolorofthescanned
documentisextremely
dif
 ferentfromtheoriginal
document. Thesettingsofthecomputer
monitorarewrong.
Adjustthecomputermonitor
settings.
Dependingonthedocuments
scanned,thecolorofdocuments
maynotbescannedproperly
.For
example,thecolorofahighlighter
penmaybescannedlighterthanit
appears....

Page 68

8.2ErrorMessages
ErrorcodescorrespondingtothescannerstatusaredisplayedontheLCD.Also,whenthescanneris
connectedtoacomputer
,simplemessagesaredisplayedontheLCD.Fordetailsabouttheerrorcodesand
messages,checkinUserUtility.
ErrorCode Cause Remedy
U11 Thepaperhasjammedinthefeed
trayarea.
OpentheADFdoor,andremovethe
paper

.
Thesensorsaredirty. Cleanthesensors.
U12
U13
U14
U16 Apaperjamhasoccurredintheunit.
OpentheADFdoor,andremovethe...

Page 69

8.3UninstallingtheSoftware
Ifyouwanttoremovethesoftwarethatisinstalledonyourcomputer ,followtheprocedurebelowtouninstall
them.
1. In[ControlPanel@,open[Uninstallaprogram@.

Page 70

8.4RepackingInstructions
ItishighlyrecommendedthatyoukeeptheoriginalcartonandALLpackingmaterials.Ifyouneedto
transportorshipthescanner
,pleasefollowtheseinstructions.
Note
