Panasonic Kx-Td816e, Kx-td1232e User Manual

4.4Special Display Features
4-172DPT Features 1.Press the SHIFTbutton repeatedly until
the Jog Dial operation display appears.
2.Press the EXT(S2) button.
3.Rotate theJog Dialuntil the desired
name is at the arrow.
4.Press the CALL(S3) button or go off-hook.
Third Display
EXTFEAT
STA
Bob Jones
Carol
MENU CALL®
Initial Display
RINGBGM
CONT  1 Jan  3:00PM
or

To select Bob Jones
nKX-T7233
1.Press the Extension(F3) button or the
EXT(S2) button.
(The S2 button can be changed to “EXT”
by pressing the SHIFT...

4.4Special Display Features
DPT Features4-173
Conditions
•Before rotating the Jog Dial,you can press the corresponding alphabet key to select the
desired letter.
 Press 2 two times to display “B”items.
•The KX-T7436 user can press the Function button (F1 through F10) on the same line
of the desired item instead of the CALL (S3) button.
Programming References
•User Programming (Section 3) / System Programming (Installation Manual)
[003]Extension Number Set
[004]Extension Name Set

4.4Special Display Features
4-174DPT Features
Station Speed Dialling (KX-T7235 / KX-T7431 / KX-T7433 / KX-T7436 only)
You can make a call to a party stored in your telephone.
For the KX-T7235,you can switch the name and number display by pressing the NEXT
button.
For the KX-T7431,KX-T7433 and KX-T7436,items which have a name assigned are
displayed by priority in stored order.  If a name is not assigned,the number is displayed.
The displaying mode,name or number,can be assigned in System Programming....

4.4Special Display Features
DPT Features4-175
1.Press the SHIFTbutton repeatedly until
the Jog Dial operation display appears.
2.Press the STA(S1) button.
3.Rotate theJog Dialuntil the desired name
or number is at the arrow.
4.Press the CALL(S3) button or go off-hook.
Third Display
EXTFEAT
STA
Bob Jones
Carol
MENU CALL®
Initial Display
RINGBGM
CONT  1 Jan  3:00PM
or

To select Bob Jones
nKX-T7433
1.Press the STA Speed(F8) button or the
STA(S1) button.
(The S1 button can be changed to “STA”by
pressing...

4.4Special Display Features
4-176DPT Features1.
Press the MODEbutton repeatedly
until “System Speed”is displayed.
2.Rotate the Jog Dialuntil the
desired name is displayed.
3.Press the SELECTbutton or go
off-hook.
Second Display
   System Speed
Initial Display
   1 Jan  3:00PM
John Smith®
or
nKX-T7431
System Speed Dialling (KX-T7235 / KX-T7431 / KX-T7433 / KX-T7436 only)
You can make a call to a party stored in the system using the directory.  Only items
which have a name assigned are displayed in...

4.4Special Display Features
DPT Features4-177
1.Press the SHIFTbutton repeatedly until
the Jog Dial operation display appears.
2.Rotate the Jog Dialuntil the desired name
is at the arrow.
4.Press the CALL(S3) button or go off-hook.
Third Display
EXTFEAT
STA
Bob Jones
Carol
MENU CALL®
Initial Display
RINGBGM
CONT  1 Jan  3:00PM
or

To select Bob Jones
nKX-T7233
Conditions
•Before rotating the Jog Dial,you can press the corresponding alphabet key to select the
desired letter.   Press 2 two times to...

4.4Special Display Features
4-178DPT Features
System Feature Access Menu (KX-T7235 / KX-T7431 / KX-T7433 / KX-T7436 only)
The System Feature Access Menu provides a display of the system features which appear
in alphabetical order.  The available features are as follows:
Absent Message Capability
Background Music — External (operator only)
Call Park
Call Pickup,Group
Class of Service (COS) Switch (operator only)
Message Waiting
Night Service On / Off (operator only)
Paging — External
Paging — Group...

4.4Special Display Features
DPT Features4-179
Enter the extension number
Fifth Display
  Feature Access
Initial Display
   1 Jan  3:00PM
MSG On      ext®
If a parameter is required,
the feature name and
parameter will flash.
nKX-T7431
Initial Display
RINGBGM
CONT     1 Jan  3:00PM

Extension  STA Speed
Features   SYS Speed
Call Log
MENUPREVNEXT Absent MSG Off
Absent MSG On     (1-9)
C.Pickup Group
Call Park         (0-9)
COS Primary       (ext)
NEXT
MENU
Extrn BGM On/Off
Message Off...

4.4Special Display Features
4-180DPT Features
Enter the
extension
number.
Third Display
EXTFEAT
STA
Initial Display
RINGBGM
CONT     1 Jan  3:00PM

Extension  STA Speed
Features   SYS Speed
Call Log
NEXT
MENU
Extrn BGM On/Off
Message Off       (ext)
Message On        (ext)
Night On/Off      (1/0)
Page-Ext Answer   (1-4)
MENU
SEL
®
If a parameter is required,
the parameter will flash.
Enter the
extension
number.
Third Display
EXTFEAT
STA
MSG On      ext
Night Mode  1/0
MENU SEL®...

4.4Special Display Features
DPT Features4-181
Absent MSG Off
ABST MSG Off
Absent MSG On(1-9)
ABST MSG On1-9
C.Pickup Group
C.Pickup GRP
Call Park(0-9)
Call Park0-9
COS Primary(ext)
COS Primaryext
COS Secondary(ext)
COS Secondext
Extrn BGM On/Off
Ext-BGM On/Off
Message Off(ext)
MSG Offext
Message On(ext)
MSG Onext
Night On/Off(1/0)
Night Mode1/0
Page-Ext Answer(1-4)
Page-E ANS1-4
Page-GRP Answer
Page-GRP ANS
Paging External(0-4)
Page Extrn0-4Cancels the absent message.
— “Absent Message Capability”
Sets...
