Panasonic Kx-Td816e, Kx-td1232e User Manual

5-60DECT Portable Station Features
5.5Troubleshooting
PROBLEMREMEDYORPROBLEMSOURCE
The PS does not work.
The PS does not operate.
The PS does not ring.
You cannot dial.
Static,sound cuts in/out,fades.
Interference from other electrical units.
“CS Busy”is displayed.
“PS NOT CONNECTED”is displayed.
You cannot store a phone number and
name in the directory.
The alarm sounds after pressing
(Redial).
“”flashes or beeps tones sound
every 5 seconds during a conversation.
You charged the batteries fully,...

DECT Portable Station Features5-61
5.5Troubleshooting
PROBLEMREMEDYORPROBLEMSOURCE
The PS stops working during operation.
Handover does not work.
The display does not show a strong
radio signal “”even though you are
near the CS.
The alarm sounds during a conversation
while receiving a weak radio signal
“.”•Turn the power switch OFF (m) and ON (l).  Then try
again.
•Re-insert the battery and try again.
•You moved to a busy CS or are out of range.
•You moved while not having a conversation (e.g.,while...

5-62DECT Portable Station Features
5.6Safety Instructions
Take special care to follow the safety suggestions
listed below.
Safety
1)Power Source:The charger should be connect-
ed to a power supply only of the type described
in the operating instructions or as marked on
the charger.
2) Non-use Periods:When the portable station
(PS) is not being used,turn the power off.
When left unused for a long period of time,the
charger should be unplugged from the house-
hold AC outlet.
Installation
Environment
1)...

DECT Portable Station Features5-63
5.6Safety Instructions
For Best Performance
Operating Range
1)The range of operation depends on the topo-
graphy of your office,weather or usage condi-
tions,because signals are transmitted between
the Cell Station (CS) and the portable station
(PS) by radio waves.
2)Normally,you will get greater range outdoors
than indoors.  If there are obstacles such as
walls,noise may interfere with your telephone
calls.  In particular,high metal shelves or rein-
forced concrete...

Section 6
DSS Console Features
Contents
6.1 Configuration .......................................................................
6-2
Location of Controls .............................................................6-3
Feature Buttons .....................................................................6-4
6.2 DSS Console Features .........................................................6-5
Station Programming ............................................................6-5
Direct Station Dialling...

6-2DSS Console Features
6.1Configuration
With a Directed Station Selection (DSS) Console,you can make or transfer calls and
access system features with the touch of a button.  The DSS Console must be connected
to the Panasonic Digital Super Hybrid System and paired with a DPT.  System
Programming is required to designate the jack numbers of the paired DSS Console and
DPT.  With a paired telephone,you can carry out the following operations using the DSS
Console:
•Direct access to an extension (Direct...

DSS Console Features6-3
6.1Configuration
Location of Controls
n KX-T7440
n KX-T7240n KX-T7441
PF (Programmable Feature)
Buttons (01 through 16) DSSButtons with
Busy Lamp Field (BLF)(01 through 32)
DSSButtons with
Busy Lamp Field (BLF)(01 through 48) DSSButtons with
Busy Lamp Field (BLF)(01 through 66)
ANSWERButtonRELEASEButton

6-4DSS Console Features
6.1Configuration
Feature Buttons
DSS Consoles have the following types of Feature Buttons:
DSS Buttons with Busy Lamp Field (BLF)
Used to access extensions.  The BLF indicates the busy or idle status of each extension in
the system.  These buttons can also be changed to other function buttons.
PF (Programmable Feature) Buttons
These buttons are provided with no default settings.  With a paired telephone,you can
program the buttons as other function buttons.
ANSWER Button
Used to...

DSS Console Features6-5
6.2DSS Console Features
Station Programming
PF buttons are provided with no default settings,while each DSS button has a default
setting as follows:
DSS 01 - 32 :extension numbers 201 - 232 (DSS 33 – 66:not stored).
To meet your various needs,DSS buttons can be changed to other function buttons.
Every DSS or PF button can be assigned to another extension number,telephone number
or feature number through Station Programming.
Extension Number Assignment
You can assign the desired...
