Panasonic Monitor Bt Lh2550p Owners Manual
Here you can view all the pages of manual Panasonic Monitor Bt Lh2550p Owners Manual. The Panasonic manuals for Monitor are available online for free. You can easily download all the documents as PDF.
Page 41
41 Main Menu (continued) ■TWO WINDOW function The “TWO WINDOW” function displays two inputs selected from VIDEO, SDI1/2, YP BPR/RGB or DVI-D in two windows. Each press of the button ([FUNCTION1] to [FUNCTION5]) (page 32) to which the TWO WINDOW function has been assigned changes the display mode. (In the factory default setting, it is assigned to FUNCTION3.) Note: When the main window and sub-window input setting is “YP BPR/RGB” and “RGB-COMP,” the main window and sub-window are displayed in a single...
Page 42
42 Main Menu (continued) ■TWO WINDOW size The “TWO WINDOW SIZE” setting in the “DISPLAY SETUP” menu determines the size of the main window and sub-window. Main window (SD) and sub-window (SD) Main window (HD) and sub-window (HD) 1920 12806401280640960960 “TWO WINDOW SIZE” setting: L/S Display size: 4:3 or 5:4 “TWO WINDOW SIZE” setting: M/M “TWO WINDOW SIZE” setting: S/L 1920 12806401280640960960 “TWO WINDOW SIZE” setting: L/S Display size: 16:9 or 16:10 “TWO WINDOW SIZE” setting: M/M “TWO WINDOW SIZE”...
Page 43
43 Main Menu (continued) Main window (HD) and sub-window (SD) Main window (SD) and sub-window (HD) When the main window and sub-window display video from the same input line, TWO WINDOW SIZE is M/M. 1920 12806401280640960960 “TWO WINDOW SIZE” setting: L/S Display size of main window: 16:9 or 16:10 Display size of sub-window: 4:3 or 5:4 “TWO WINDOW SIZE” setting: M/M “TWO WINDOW SIZE” setting: S/L 1920 12806401280640960960 “TWO WINDOW SIZE” setting: L/S Display size of main window: 4:3 or 5:4 Display...
Page 44
44 Main Menu (continued) ■TWO WINDOW screen sync In single screen display, the TWO WINDOW screen is synchronized to the frame rate frequency of the input signal format. In split screen display, the screen used as a reference for synchronization changes with the input signal format and “TWO WINDOW SIZE” settings as shown in the following table. Screen synchronization and display in split-screen mode No screen is displayed when the screen is not synchronized to the reference sync or the reference sync is...
Page 45
45 Main Menu (continued) Underlined values indicate factory defaults. *1 The menu can be displayed when the lock is engaged. Only “CONTROL/LOCAL ENABLE” menu items are available when the lock is engaged. The picture/volume adjusting menu does not accept changes when the lock is engaged. The “LOCAL ENABLE” setting determines operations in lock mode. The key mark is displayed during lock engagement. *2 Only available when “REMOTE” is selected under “CONTROL.” *3 “XXXXXX” indicates the number of hours....
Page 46
46 Main Menu (continued) ■ List of setting restrictions ( : available, ×: not available) *1 This function is not available in the split-screen display of the “TWO WINDOW” function. *2 This function can be set in the split-screen display of the “TWO WINDOW” function. *3 Settings are reflected to the sub-window in the split-screen display of the “TWO WINDOW” function. *4 Settings are reflected to the main window and the sub-window in the split-screen display of the “TWO WINDOW” function. Input...
Page 47
47 Main Menu (continued) *2 This function can be set in the split-screen display of the “TWO WINDOW” function. *5 The VECTOR display appears only during SDI input. Input CHVIDEOSDI 1/2 YPBPRRGB-VIDEORGB-COMP.DV I - V I D E ODV I - C O M P.CH SD HD SD HD SD HD SD HD DISPLAY SETUP *2 TWO WINDOW SIZE ×× SUB INPUT SEL. WFM/VECTOR *5 *5 *5×× × ×× × POSITION ×× × ×× × VECTOR MODE ××××××××× VECTOR SCALE ×× ××××× ×× TIME CODE ×× ×× × × × ×× × POSITION ×× ×× × × × ×× × FONT SIZE ×× ×× × × × ×× × MODE SELECT ××...
Page 48
48 REMOTE Specifications This monitor permits remote operation via GPI/RS-232C terminal. GPI screen items correspond to the following terminals. Use the GPI menu to assign functions to each terminal (J page 35). Functions assigned to terminals are executed when GND (pin 5) is shor t-circuited (ON) or open (OFF). ■Operating conditions Level operation: Operates when GND is short-circuited. Edge operation: Operates when GND changes from open to short-circuited. When level operation is assigned to...
Page 49
49 REMOTE Specifications (continued) ■Priority of assigned functions When both “MARKER1” and “MARKER2” are activated at the same time, “MARKER1” has priority. However, when the display aspect ratio is 4:3, the “MARKER1” aspect ratio is 16:9 and the “MARKER2” aspect ratio is 4:3, “MARKER2” is displayed. In this case, the “MARKER2” background is controlled. When “MARKER BACK HALF” and “MARKER BACK BLACK” are activated at the same time, “MARKER BACK BLACK” has priority. During GPI edge operation and...
Page 50
50 REMOTE Specifications (continued) ■Setting command *1 This command is enabled in single screen display in “TWO WINDOW” mode and in the main window in split- screen display. *2 This command is enabled in single screen display in “TWO WINDOW” mode and in the main window and sub- window in split-screen display. *3 This command is enabled in the sub-window in single screen display in “TWO WINDOW” mode. No Command Description DataResponse 1 IIS *1Input switch 0: SDI1 1: SDI2 2: VIDEO 3: YP BPR/RGB...
