    Page 1 Multi Hybrid Control Panel AW-RP505 Before attempting to connect or operate this product, please read these instructions completely. â
    Page 2 Warning: Do not install this product near any object that burns easily. In case of using a halogen lamp, installation of it near such an object could cause a fire due to the heat generated by the lamp. This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOIS TURE. The...
    Page 3 -1- CONTENTS FEATURES .......................................................................................................................................................................................... 2 PRECAUTIONS ................................................................................................................................................................................... 3 MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS...
    Page 4 -2- FEATURES• The Multi Hybrid Control Panel AW-RP505 is combined with the Multiport Hub (AW-HB505) to control up to five Pan/tilt Heads (AW-PH300) and Color Video Cameras (AW-E560). With the Control Panel AW-RP505 con- nected to the multiport hub with three coaxial cables (5C-2V) and a single 10BASE-T straight cable (UTP category 5), and with the Multiport Hub connected to each camera and pan/tilt head with three coaxial cables (5C-2V) and a single 10BASE-T straight cable (UTP category 5), the Control...
