Panasonic Multiport Hub Aw Hb505 Operating Instructions

Multiport Hub
AW-HB505
Before attempting to connect or operate this product,
please read these instructions completely.
â

Warning:
This equipment generates and uses radio frequency ener-
gy and if not installed and used properly, i.e., in strict
accordance with the instruction manual, may cause harmful
interference to radio communications.    It has been tested
and found to comply with the limits for a Class A computing
device pursuant to Subpart J of Part 15 of FCC Rules,
which are designed to provide reasonable protection
against such interference when operated in a commercial
environment.
This digital apparatus does not...

-1-
CONTENTS
FEATURES .................................................................................................................................................................................. 2
PRECAUTIONS ........................................................................................................................................................................... 3
MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS...

-2-
FEATURES• The Multiport Hub AW-HB505 is combined with the
Multi-Hybrid Control Panel (AW-RP505) to control up to
five Pan/tilt Heads (AW-PH300) and Color Video
Cameras (AW-E560).  When the Multiport Hub AW-
HB505 is connected to the Multi-Hybrid Control Panel
with three coaxial cables (5C-2V) and a single
10BASE-T Straight cable (UTP category 5), and the
Multiport Hub connected to each camera and pan/tilt
head with three coaxial cables (5C-2V) and a single
10BASE-T Straight cable (UTP category 5),...

-3-
• Use only with AC Adaptor, Model AW-PS505.
• Handle the control panel with care.
Dropping the control panel or subjecting it to a strong
shock can cause a failure or an accident.
• Operating temperature range –10°C to +45°C
Avoid using it in a cold place below –10°C or a hot
place above +45°C because low or high temperature
will adversely affect the parts inside.
• Switch power off before power cable connection or
disconnection.
Be sure to switch power off before connecting or dis-
connecting the...

-4-
MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS
POWER
1
YC2
YC3
YC4
YC5
YC
OFF ON
CABLE  COMP
Multl  Port  Hub  AW-H8505
n FRONT PANELqPower Indicator [POWER]
Lights red when Power ON/OFF Switch wis in the ON
position, and goes out when the same switch is set to
the OFF position.
wPower ON/OFF Switch [POWER ON/OFF]
The camera and pan/tilt head are switched on when
this switch is set to the ON position.  (The POWER indi-cator lights.)  The camera and pan/tilt head are partial-
ly switched off when this...

-5-
eCable Compensation Luminance Control
[CABLE COMP Y]
Used to adjust the Y (luminance) signal level of video
output signals as appropriate to the length of the cable
between the pan/tilt head and the Multiport Hub.  First,
select a camera with the Control Switch on the Multi-
Hybrid Control Panel, and set the Camera Control
Switch to the ON position.  Set the MODE Switch on the
Multi-Hybrid Control Panel to BAR, then output color
bar signals from the camera, and connect a waveform
monitor or...

-6-CAMERA
CONTROL OUTCAMERA
CONTROL IN VIDEO OUTPAM/TILT
CONTROL OUTPAM/TILT
CONTROL IN
S-VIDEO OUT VIDEO
IN
G/L
OUTG/L
IN
CAMERA
CONTROL OUTVIDEO OUTPAM/TILT
CONTROL OUT
S-VIDEO OUT VIDEO
IN
G/L
OUT
CAMERA
CONTROL OUTVIDEO OUTPAM/TILT
CONTROL OUT
S-VIDEO OUT VIDEO
IN
G/L
OUT
CAMERA
CONTROL OUTVIDEO OUTPAM/TILT
CONTROL OUT
S-VIDEO OUT VIDEO
IN
G/L
OUT
CAMERA
CONTROL OUTVIDEO OUTPAM/TILT
CONTROL OUT
S-VIDEO OUT VIDEO
IN
G/L
OUT
4
3
2
1 5
DC12V  IN
TO CAMERA PAM/TILT HEAD
TO CONTROL PANELPREVIEW OUT
SEE...

-7-
oCamera Control Input Connector [TO CONTROL
PANEL, CAMERA CONTROL IN]
Connect it to Camera Control Input Connector [CAM-
ERA CONTROL OUT] on the multi hybrid control panel
with a coaxial straight cable (5C-2V or equivalent),
which may be extended up to 10 meters.
!0Pan/tilt Control Output Connector [TO CAMERA
PAN/TILT HEAD, PAN/TILT CONTOROL OUT] (RJ-
45 8-pin Modular Jack)
Connect one of [1] to [5] Pan/tilt Control Output
Connectors to Pan/tilt Control Input Connector [P/T
CONTROL IN] on the...

-8-
• Install the pan/tilt head after carefully reading the
Operating Instructions for Pan/tilt Head.
• Have four hex bolts (M6 x 4) ready for mounting the
pan/title head.  Select bolts of a length appropriate to
the material and structure of the mounting base and the
overall weight applied to it.  Fasten the bolts securely
with plain washers, spring washers, and hex nuts.  If
the bolts are not securely tightened, the pan/tilt head
might fall to cause injuries or accidents.  In case of sus-
pending the...
