• Changing Switch Settings on Pan/tilt Head
qRemove the cover from the pan/tilt head.
* Be careful of the Tally Indicator wire.
wShift the mounting direction switches (SW1, SW2) on
the pan/tilt head depending on whether the head is
suspended from the ceiling or mounted on the floor.
They are originally set for suspended installation.ePlace the cover back on the pan/tilt head.
* Be sure not to trap the wires.
• If the pan/tilt head is connected to the control panel
with a cable longer than 300...

-10-
ON
OFF
• Shifting Cable Compensation Switch on Pan/tilt
Head
If the distance from the control panel to the pan/tilt
head is longer than 300 meters, set the cable compen-
sation switch to the ON position by observing the fol-
lowing procedure.
qRemove the controller connection panel from the
pan/tilt head.
* Be careful of the wires.
wShift the cable compensation switch on the inner side
of the controller connection panel of the pan/tilt head to
the ON position.
ePlace the controller connection panel...

-11-
CONNECTION• Before making any connection, switch off all the com-
ponents of the system.
• Use the Control Panel AC Adaptor AW-PS301 (optional)
and Pan/tilt Head AC Adaptor AW-PS300 (optional).
• Use the Pan/tilt Head AW-PH300 and the Color Video
Camera WV-E550 or AW-E560.  (The color Video
Camera WV-E550 cannot used.) To connect the pan/tilt
head to the camera, the Camera Cable AW-CA20T15
(optional) is necessary.
• Locally purchase a DC cable with a nominal cross sec-
tion of 1.25 mm
2or larger...

-12-
ITEM(AWC) UP(ABC)PAGEDOWN
  (BAR)IRIS
G/L  INVIDEO  OUT
ZOOM/FOCUS
REMOTEVD
VIDEO/RGB VBS/HD
    75ON
OFF
CONTROL
EXT DC INSEE MANUALCAUTION
• Connect the iris control cable of the motor-driven zoom
lens to the camera and the remote (zoom/focus control)
cable to the pan/tilt head.  If the remote (zoom/focus
control) cable of the motor-driven zoom lens is con-
nected to the camera, the lens cannot be controlled.
To Lens Interface ConnectorTo Iris Connector Iris Control Cable Remote (Zoom/Focus...

-13-
CAMERA
CONTROL OUTCAMERA
CONTROL IN VIDEO OUTPAM/TILT
CONTROL OUTPAM/TILT
CONTROL IN
S-VIDEO OUT VIDEO
IN
G/L
OUTG/L
IN
CAMERA
CONTROL OUTVIDEO OUTPAM/TILT
CONTROL OUT
S-VIDEO OUT VIDEO
IN
G/L
OUT
CAMERA
CONTROL OUTVIDEO OUTPAM/TILT
CONTROL OUT
S-VIDEO OUT VIDEO
IN
G/L
OUT
CAMERA
CONTROL OUTVIDEO OUTPAM/TILT
CONTROL OUT
S-VIDEO OUT VIDEO
IN
G/L
OUT
CAMERA
CONTROL OUTVIDEO OUTPAM/TILT
CONTROL OUT
S-VIDEO OUT VIDEO
IN
G/L
OUT
4
3
2
1 5
DC12V  IN
TO CAMERA PAM/TILT HEAD
TO CONTROL PANELPREVIEW OUT
SEE...

-14-
S-VIDEO VIDEO
PREVIEW
VIDEO
VIDEO
CONTACT PAN/TILT
CONTROL
PAN/TILT
CONTROL CAMERA CONTROL
CAMERA CONTROL SYSTEM
TALLY
G/L
G/L  DC-15V
OPTION
SWITCH
CONTROL
PREVIEW
VIDEO
G/L
ONPOWER
OFFPOWER
O    I
FUSE(POWER)
3.15AFUSEFUSE
Option UnitSEG, Switcher etc.
POWERON
OFF
Color  Monitor  WV-CM   1470
PUSH
POWERON
OFF
Color  Monitor  WV-CM   1470
PUSH
ZOOM/FOCUS CONTROL
IRIS CONTROL
LAMPCONTROL
SPEED FOUCUS PA N  /  T I LT
ZOOMTELE
WIDEFA R
LEFT RIGHTUP
DOWN
NEAR
DEFON
OFF ON
OFF
POWEROPERATE
IRISCAM...

MEMORY
PRESET
2 1345
678910
-15-
OPERATION1. Power
Set the power switches on the pan/tilt head AC adapter
and the multiport hub AC adapter to the ON position,
then set Power control Switch on the multi control panel
to the ON position.
2. Pan/tilt Limiter Setting for Pan/tilt Head
If there are obstacles around the pan/tilt heads, set the
limiters to limit the operating range (pan left and right
ends, tilt up and down ends) of the pan/tilt head.
Note:The switches on the pan/tilt head have been pre-
set...

-16-
eRight Panning Limiter
Turn the pan/tilt head to the desired right panning limit
with PAN/TILT Lever of the multi hybrid control panel,
keep MEMORY Switch depressed, and simultaneously
press buttons [4] and [9] of PRESET Switch for 5 sec-
onds or more.  When the desired limit has been set,
button [5] of PRESET Switch lights.
To reset the limit, keep the MEMORY Switch
depressed, and simultaneously press buttons [4] and
[9] of PRESET Switch again for 5 seconds or more.
When the set limit is reset,...

-17-
2) Adjust the cable compensation, genlock, and total
pedestal of the selected camera.
• Cable Compensation
Signal degradation due to cable length between the con-
trol panel and the pan/tilt head can be compensated for.
qIf the cable length from the pan/tilt head to the control
panel is longer than 300 meters, set the cable com-
pensation switch on the pan/tilt head to the ON posi-
tion.  For details, refer to INSTALLATION OF PAN/TILT
HEAD at page 8 or the Operating Instructions for
Pan/tilt Head....

-18-
GRAY
YELLOW
CYAN
GREEN
MAGENTA
RED
BLUE
100
  90
  80
  70
  60
  50
  40
  30
  20
  10
    0
 -10
 -20
 -30
 -40+69 +77
+56
+48
+38
+12
+7
-5
-16 -16+15 +28 +36
+20
-20 +20
-20+100+100
+89
+77
+72
+46 IRE
75%
100%
1V[p-p]
+100
+27
+27
-20
-13 -13
100
  90
  80
  70
  60
  50
  40
  30
  20
  10
    0
 -10
 -20
 -30
 -40IRE
75%
100%
+20
-20+20
-20 +7.5 +7.5
- I  WHITE  +Q       BLACK
1V[p-p]
Color Monitor
Color MonitorWaveform Monitor
Waveform Monitor
• Genlock AdjustmentTo use the camera in...
