-19-
eSet G/L PHASE ON/OFF Switch of the multi hybrid con-
trol panel back to the OFF position.
·Subcarrier Phase Adjustment
qSet G/L PHASE ON/OFF Switch (15) of the multi hybrid
control panel to the ON position.
Note:When G/L PHASE ON/OFF Switch of the multi
hybrid control panel is set to the ON position, the
sync phase of the camera changes to the settings
of G/L PHASE H Control, G/L PHASE Coarse
Switch, and G/L PHASE SC Control.  Unless G/L
phase adjustment is necessary, do not set G/L
PHASE ON/OFF...

-20-
•Total Pedestal AdjustmentTotal pedestal adjustment is made to adjust the
pedestals of two or more cameras.  Using an oscillo-
scope or a waveform monitor, adjust the pedestals to 5
IRE (0.035 V) or 7.5 IRE (0.050 V) with T.PED Control of
the multi hybrid control panel.
T.PED
CABLE COMP
YC
T. PED Control
5 IRE (0.035V) or
7.5 IRE (0.050V)
3) Set the switches for gain, shutter, etc. as appropriate
to the conditions of using the camera.
4) Set the camera control switch on the multi hybrid con-
trol...

-21-
wPick up a white object (a white wall or white handker-
chief, for example) fully on the screen.  Be careful to
keep a shiny or bright object out of the screen.
eWhen AWC Switch of the multi hybrid control panel is
pressed, the auto Auto set Indicator flashes and the
white balance is automatically adjusted.  It goes out
when it has been properly adjusted.  If the adjustment
fails, Auto set Indicator remains lit.  In such a case,
change the brightness, iris, object, light source, etc.
and adjust it...

-22-
5. Camera and Pan/tilt Head Presetting1) Select a camera and pan/tilt head with the CONTROL
switch on the multi hybrid control panel.
2) Pick up a desired object with the camera using
PAN/TILT Lever ZOOM Lever and FOCUS Lever of the
multi hybrid control panel. Select a white balance con-
trol mode using AUTO/ATW ATW Switch AUTO/ATW A
Switch or AUTO/ATW B Switch.  To store iris data in the
memory, set IRIS AUTO/MANU Switch to the MANU
position and turn the iris control.  When IRIS
AUTO/MANU Switch is...

1
YC2
YC3
YC4
YC5
YC
CABLE  COMP1
YC2
YC3
YC4
YC5
YC
CABLE  COMP
1
YC2
YC3
YC4
YC5
YC
CABLE  COMP
-23-
RACK MOUNTINGTo mount the multiport hub in a rack, use the supplied rack
mounting brackets and screws (M4x10).
qPress the power switch to turn power off.
wRemove the 4 feet.
eWith the rack mounting brackets on both ends of the
multiport hub, fasten them with the supplied screws (4
pcs.)
rMount the multiport hub in the rack and fasten it with
the rack mounting screws (4 pcs.)
Notes:
• The rack mounting...

-24-
SPECIFICATIONSSource Voltage 12 V DC (4-pin cannon connector)
Power Consumption 12V, 2A
Video Input 1.0 V[p-p] composite/75½x 5 (BNC connector)
Genlock Input 1.0 V[p-p] black burst/75½(BNC connector)
Camera Control Intput Control signal (BNC connector)
Pan/tilt Control Intput Control signal (RJ-45 8P modular jack)
Video Output 1.0 V[p-p] composite/75½x 5 (BNC connector)
S-video Output Y: 0.714 V[p-p] (75 ½)
C: 0.286 V[p-p] burst level chrominance/75½x 5 (S-VIDEO connector)
Preview Video Output 1.0...

-25-
Operating temperature-10°C to +45°C (14°F to +113°F)
Dimensions 420 (W) x 88 (H) x 250 (D) mm [16-9/16 (W) x 3-7/16 (H) x9-13/16” (D)]
Weight 4 kg(8.8 lbs.)
Finish Cover: AV Ivory vinyl chloride steel
Panel: AV Ivory painting
Weight and dimensions indicated are approximate.
Specifications are subject to change without notice.ACCESSORIESRack mounting part ................................ 2
Mounting screws .................................... 4
