Panasonic Pt D9510u Projector User Manual

11
Name and function of each remote control part
〈
Remote control unit〉
STD (standard) button
This button is used to reset all of the projector adjustment values (BRIGHT,
CONTRAST, COLOR, TINT and SHARPNESS) to the default levels which were
set at the time of shipment from the factory. It is pressed after the respective
adjustment mode screen has been displayed.
SYSTEM SELECTOR button
This button is used to select RGB, RGB REALITY, or YP
BPR(YCbCr)
signal or switch between video and digital-serial signal...

12
Name and function of each remote control part (continued)
〈
Remote control unit〉
Transmitter
This emits the infrared signals which are
used to control the projector when the remote
control unit is being used as a wireless unit.
Wired remote control terminal
This terminal is used to connect the
accessory cable when the remote control
unit is being used as a wired unit.
MENU button
This button is used to make the MENU screen
and the respective adjustment screens appear
on the projection screen, and to...

13
Before using the remote control unit
Inserting the batteries
•Insert the AA batteries supplied with the remote control unit, making sure that the polarities are correct.
•The batteries also need to be inserted when the remote control unit is connected to the projector using the
remote control cable.
Attaching the strap
A strap is provided with the remote control unit. You can
use this strap to hang the remote control unit around your
neck for easy carrying. Attach the strap...

14
1
3
0
+&
$
5
0
3
#3*()5$0/5345
108&3*/165


*/165













45%
3(#
-&/4


/&951*$

.65&
*%4&-&$50/








4$3&&/
*%--
14
4
:4
5&
34&-&$503
*/165
&/
5
&3.
&
/
6

Accessory remote control cable
To REMOTE IN2
IN terminal
To remote control
cable terminal
[Projector]
[Remote control unit]
The remote control unit can be connected to
the projector using the accessory remote
control cable.
This cable should be connected to the
REMOTE IN2 IN terminal at the front of the
projector and to...

15
Turning the power ON and OFF
Always be sure to follow the procedure given below to turn the projector power on and off.
〈
Turning the power on 〉〈
Turning the power off 〉
• The projector will continue to draw approximately 13 W of power when it is in standby mode, even
after the cooling fan has stopped.
•The lamp cooling fan will continue to operate for approximately five minutes after the power is turned off.
At the same time, the self-diagnosis display “FC” will blink.
Do not disconnect the power...

16
The figure below shows on-screen displays for any desired setting, starting with the MAIN MENU, and ending with
its sub-menu.
Normal screen
-&/4
-&/4
0$64




17
The projection lenses and input modules which are available for use with this projector need to be purchased
separately  and must be installed to the projector before the projector can be used.
• Obtain the required projection lenses and input modules beforehand in accordance with the projection
distance and the system used.
• When installing an optional input module, refer to page 28 for details.
Install a projection lens (sold separately) which is appropriate for the projector setting-up...

18
Setting up the projector
Installing to the floor (Including the direct rear-mounting)
1. Installing drawing of the screen and the projector (unit : mm / inches)
L : Projection distance between the screen
and the center of the front foot of the
projector.
A: Distance between the center of the lens and
the top of the setting table (including the
height of a foot of the projector) , 288 mm –
313 mm (11.5- 12.5) (The height of each
foot is adjustable.)
C: Distance between the bottom of the foot and
the...

Installing to the ceiling (Including direct rear-projection)
19
• Using the projector by installing to the ceiling requires an optional ceiling mount bracket (ET-PKD95).
For the projection distance (L), refer to the chapter Projection distance for each projection lens (sold separately)
on pages  20 - 24.
For the procedures to install the ceiling mount bracket on the projector and mount the suspension bolts on the
ceiling surface, refer to the installation instructions supplied with ET-PKD95.
L:...

20
Projection distance for each projection lens
(sold separately)
L SH
Screen
The required projection distance depends on not only the target picture size but also the type of an optional
projection lens. Obtain the appropriate projection lens for the installation space by referring to the projection
distance for each projection lens shown in the table below and on the next page.
L    : Projection distance
SH : Effective height of
screen
Projection distance measurements for PT-D9510U (screen aspect...
