Here you can view all the pages of manual Stiga Lawn Mower PARK 4WD, PRO 25, PRO 20, PRO 16 PRESTIGE Instructions Manual. The Stiga manuals for Lawn Mower are available online for free. You can easily download all the documents as PDF.
Page 61
61 ENGLISHEN 1 GENERAL This symbol indicates WARNING. Seri- ous personal injury and/or damage to property may result if the instructions are not followed carefully. You must read these instructions for use and the accompanying pamphlet “SAFETY INSTRUCTIONS” careful- ly, before starting up the machine. 1.1 SYMBOLSThe following symbols appear on the machine. They are there to remind you of the care and atten- tion required during use and maintenance. This is what the symbols mean: Warning! Read the...
Page 62
62 ENGLISHEN •Lifting. Press the rear part of the switch until the implement is in its highest position (trans- port position). Then release the switch and the height is locked in transport position. •Locking in transport position. The switch has reverted to neutral position after lifting. The im- plement is locked in transport position. NOTE! The hydraulic implement lifter must be in floating position in order for the power take- off to be engaged. NOTE! The power take-off cannot be engaged when...
Page 63
63 ENGLISHEN 2.4.9 Choke control (5, 6:H) (Pro16, Pro20, Pro25) A pull-type control to choke the engine when start- ing from cold. 1. Control fully pulled out – choke valve in carburettor closed. For starting cold en- gine. 2. Control pushed in – choke valve open. For starting warm engine and when oper- ating the machine. Never operate the machine with the choke pulled out when the engine is warm. 2.4.10 Ignition lock/headlight (4, 5, 6:I) The ignition lock is used for starting and stopping the...
Page 64
64 ENGLISHEN 2.4.18 Engine casing (9:U) In order to access the fuel cock, battery and engine, the machine has an engine casing that can be opened. The engine cas- ing is locked with a rubber strap. The engine casing is opened as follows: 1. Undo the rubber strap (9:V) at the front edge of the casing. 2. Carefully lift the engine casing back. Close in the reverse order. The machine may not be operated un- less the engine casing is closed and locked. Risk of burns and crushing in- juries. 3 AREAS OF...
Page 65
65 ENGLISHEN 4.3 Safety checksCheck that the results of the safety checks below are achieved when testing the machine in question. The safety checks must always be car- ried out every time before use. If any of the results below is not achieved, the machine must not be used! Take the machine to a service workshop for repair. 4.3.1 General safety check 4.3.2 Electrical safety check The operation of the safety system should always be checked every time before use. 4.4 Start1. Open the fuel cock. See...
Page 66
66 ENGLISHEN 4.6 Operating tipsAlways check that there is the correct volume of oil in the engine. This is particularly important when operating on slopes. See 4.2. Be careful when driving on slopes. No sudden starting or stopping when driv- ing up or down a slope. Never drive across a slope. Move from the top down or from the bottom to the top. The machine may not be driven on slopes greater than 10º in any direction. Reduce the speed on slopes and when making sharp turns in order to retain...
Page 67
67 ENGLISHEN 5.4 Changing engine oil, filter (Pro16, Pro20) Change engine oil for the first time after 5 hours of operation, and subsequently after every 50 hours of operation or once a season. Change the oil more often (after 25 hours of oper- ation or at least once a season) if the engine has to operate under demanding conditions or if the am- bient temperature is high. The oil filter must be replaced after 100 hours of operation. 5.4.1 Engine oil Use synthetic oil of service grade SF or higher in...
Page 68
68 ENGLISHEN Oil quantity: 8. Start the engine and check for oil leaks. 9. Stop the engine. Wait a few minutes until all the oil has run back into the crankcase. 10.Check the oil level in accordance with 4.2. 5.5.2 Oil filter The oil filter must be replaced during every second oil change, i.e. after 200 hours of operation. First drain the engine oil and install the oil drainage plug as described above. Then replace the oil filter as follows: 1. Clean the area around the filter and dismantle the...
Page 69
69 ENGLISHEN 5.7.4 Filling 1. Check that the gaskets on the 4 drainage plugs are intact. See fig. 22. Reinstall the plugs. Tight- ening torque: 15-17 Nm. 2. Roll the machine down so that the right rear wheel is level with the other wheels. 3. Only applies to Pro20 and Pro25: Moisten the new filter’s gasket with oil and in- stall the filter. See fig. 18:A. 4. Fill the oil reservoir with the new oil. 5. Check that the clutch release lever (7:R) is in the outer position (drive position). If the engine is...
Page 70
70 ENGLISHEN 5.10.3 Removal/Installation The battery is placed under the tank. To access the battery, first dismantle the fuel tank as follows: 1. Open the engine casing. 2. Close the fuel cock, see 15. 3. Unscrew the two wing nuts (18:B) and remove the clamps. 4. Carefully lift up the petrol tank. During removal/installation of the battery, the fol- lowing applies regarding connection of the cables: • During removal. First disconnect the black ca- ble from the battery’s negative terminal (-). Then...
