Stiga Lawn Mower PARK Diesel, Diesel 4WD Instruction Manual

61
ENGLISHEN
2.4.18 Engine casing (8:U)
In order to access the fuel cock, battery
and engine, the machine has an engine
casing that can be opened. The engine cas-
ing is locked with a rubber strap.
The engine casing is opened as follows:
1. Undo the rubber strap (8:V) at the front edge of
the casing.
2. Carefully lift the engine casing back.
Close in the reverse order.
The machine may not be operated un-
less the engine casing is closed and
locked. Risk of burns and crushing in-
juries.
3 AREAS OF...

62
ENGLISHEN
4.2 BleedingThe engine’s fuel system must be bled in the fol-
lowing instances:
• If the fuel tank has been run dry and air has been
drawn into the fuel system.
• After replacing the filter.
Bleed as follows:
1. Fill the tank with fuel.
2. Pump using the hand pump (10:Y) until all air
has been pumped out.
4.3 Level check, engine oil
On delivery, the crankcase is filled with SAE 10W-
40 oil.
Always check the oil level before use to ensure it
is correct. The machine should be standing on...

63
ENGLISHEN
5. When starting from cold, do not make the ma-
chine work under load immediately, but let the
engine run for a few minutes first. This will al-
low the oil to warm up.
When in use, always operate the engine at full
throttle.
4.7 Power assisted steering (4WD)Power assisted steering means that power from the
machine’s hydraulic system is supplied to the
steering wheel movements. This makes the ma-
chine very easy to steer when the engine is operat-
ing at working revs (full throttle)....

64
ENGLISHEN
5.3 Tyre pressureAdjust the air pressure in the tyres as follows:
Front: 0.6 bar (9 psi).
Rear: 0.4 bar (6 psi).
5.4 Changing engine oilThe engine oil must be changed for the first time
after 25 hours of operation and then every 250
hours of operation.
Use the following oil specifications:
ACEA-B2-E2 or API-CF-CG or SHPD.
Select the oil grade according to the table below.
Use oil without any additives.
Do not overfill with oil. This can cause the engine
to overheat.
Change oil when the...

65
ENGLISHEN
6. Dispose of the drained fluid according to local
regulations.
5.8 Transmission, oil - filter (4WD)The oil and filter in the hydraulic power transmis-
sion must be checked/adjusted and changed at the
intervals given in the table below.
The type of oil is dependent on the hours of opera-
tion according to the table below:
Oil quantity when changing: approximately 3.5 li-
tres.
5.8.1 Check – adjustment
1. Place the machine on a flat surface.
2. Read off the oil level in the reservoir. See...

66
ENGLISHEN
5.10 SteeringThe steering must be checked/adjusted after 5
hours of operation and thereafter after 100 hours of
operation.
5.10.1Checks
Briefly turn the steering wheel back and forth.
There must be no mechanical clearance in the
steering chains.
5.10.2Adjustment
Adjust the steering chains if required as follows:
1. Put the machine in the straight-ahead position.
2. Adjust the steering chains with the two nuts, lo-
cated under the central point. See fig. 22.
3. Adjust both nuts by the...

67
ENGLISHEN
Never direct the flow of compressed air
towards the body. The penetration of
air into the blood stream can be fatal.
5. Clean off any dry dirt on the filter by blowing
compressed air in and out of the filter. The pres-
sure must not exceed 5 bar.
Check for cracks or other damage after clean-
ing. This can be visually checked against a light
source.
Check that the filter’s mating surfaces are free
of faults.
If the filter is damaged, it must be replaced.
If the filter is contaminated by...

68
FRANÇAISFR
1 GÉNÉRALITÉS
Ce symbole est un AVERTISSEMENT.
Risque de blessure ou de dégât matériel
en cas de non-respect des instructions.
Avant de démarrer la machine, lire at-
tentivement les instructions ainsi que
les consignes contenues dans le fascicule
« RÈGLES DE SÉCURITÉ » ci-joint.
1.1 SymbolesLes symboles suivants figurent sur la machine. Ils
attirent votre attention sur les dangers et les mesu-
res à respecter lors de l’utilisation et de la mainte-
nance.
Explication des symboles :...

69
FRANÇAISFR
2.4.2 Dispositif hydraulique de levage des
accessoires (4:M) (4WD)
Le dispositif hydraulique de levage ne
fonctionne que lorsque le moteur tourne
; il est commandé par le commutateur
(4:M).
Le commutateur se règle dans trois positions :
•Flottement. Enfoncer l’avant du commutateur.
Il se bloque en position enfoncée et le dispositif
de levage s’abaisse jusqu’à atteindre la position
de flottement.
Dans cette position, l’accessoire repose tou-
jours avec la même pression sur le sol...

70
FRANÇAISFR
2.4.8 Phare avant (4, 5:H)
Manette à tirer pour allumer et éteindre les phares
avant.
2.4.9 Démarreur (4, 5:I)
Le blocage de l’allumage permet de démarrer et
d’arrêter le moteur. Trois positions sont possibles :
1. Arrêt – le moteur est court-circuité. La
clé peut être retirée.
2. Position en cours de fonctionnement
3. Démarrage – le démarreur électrique est
activé lorsque la clé est tournée à fond
dans la position de démarrage. Lorsque le
moteur tourne, la clé revient en position de...
