Stiga Lawn Mower ROYAL, COMFORT, ELITE Instructions Manual

57
ENGLISHEN
Royal:Put the throttle control at full throttle.
Starting cold engine – pull the choke control out
fully.
Starting warm engine – the choke control
should be pressed in.
6.  Depress the clutch-brake pedal fully.
7.  Turn the ignition key and start the engine.
8 Comfort, Elite:
Once the engine has started, move the throttle
control gradually to full throttle (approx. 2 cm
behind the choke position) if the choke has been
used.
Royal:
Once the engine has started, push the choke
control...

58
ENGLISHEN
At each basic service and intermediate service car-
ried out at an authorised workshop, the service log
is stamped. A service log presenting these services
is a valuable document that improves the ma-
chine’s second-hand value.
5.2 PreparationAll service and all maintenance must be carried out
on a stationary machine with the engine switched
off.
Prevent the machine from rolling by al-
ways applying the parking brake.
Prevent unintentional starting of the
engine by disconnecting the...

59
ENGLISHEN
2. Moisten the new filter’s gasket with oil.
3. Install the filter. First screw in the filter so that
the gasket comes into contact with the engine.
4. Comfort, Elite
: Screw in the filter a further 1/2-
3/4 turn.
Royal
: Tighten the filter to 1.2 Nm.
5. Continue with point 4 in accordance with 5.4.1
above.
5.5 Fuel filter (17:S)Replace the fuel filter every season. Check for fuel
leaks once the new filter has been installed.
5.6 Belt transmissionsAfter 5 hours of operation, check that...

60
ENGLISHEN
5.8.4 Cleaning
If the battery terminals are coated with oxide, they
should be cleaned. Clean the battery terminals with
a wire brush and lubricate them with terminal
grease.
5.9 Air filter (Comfort, Elite)The pre-filter (foam filter) must be cleaned/re-
placed after 25 hours of operation.
The air filter (paper filter) must be cleaned/re-
placed after 100 hours of operation.
NOTE! The filters should be cleaned/replaced
more often if the machine operates on dusty
ground.
Remove/install...

61
ENGLISHEN
5.14 FusesIf any of the faults listed below occurs, replace the
relevant fuse. The fuse(s) is located together with
the battery under the engine casing..
6 PATENT - DESIGN REGISTRA-TION
This machine or parts thereof is covered by the fol-
lowing patent and design registration:
9900627-2 (SE), SE00/00250 (PCT), 9901091-0
(SE), SE00/00577 (PCT), 9901730-3 (SE), SE00/
00895 (PCT), 9401745-6 (SE), SE95/00525
(PCT), 595 7497 (US), 95920332.4 (EPC).
99 1095 (SE), 499 11 740.9 (DE), M1990...

www.stiga.com
GGP Sweden AB · Box 1006 · SE-573 28 TRANÅS
