5. Bereiten Sie einen geeigneten Behälter mit dem
neuen Öl vor.
ACHTUNG! Das Öl wird äußerst schnell in
das System gesaugt. Der Behälter muss stets
befüllt sein. Es darf keine Luft eingesaugt
werden.
6. Befüllen Sie den Ölbehälter mit dem neuen Öl.
7. Motor anlassen und im Leerlauf betreiben. Fül-
len Sie nachträglich Öl in den Behälter, bis der
Ölstand zur Markierung reicht.
8. Remontieren Sie den Öleinfülldeckel und
schließen Sie die Motorhaube.
9. Bringen Sie die...

62
DEUTSCHDE
• Bei der Demontage: Trennen Sie zuerst das
schwarze Kabel vom Batterieminuspol (-).
Trennen Sie danach das rote Kabel vom Batte-
riepluspol (+).
• Bei der Montage: Verbinden Sie zuerst das rote
Kabel mit dem Batteriepluspol (+). Verbinden
Sie danach das schwarze Kabel mit dem Batte-
rieminuspol (-).
Wenn die Kabel in der umgekehrten
Reihenfolge angeschlossen bzw. ge-
trennt werden, besteht das Risiko für
einen Kurzschluss sowie eine Beschädi-
gung der Batterie.
Durch das Vertauschen...

63
DEUTSCHDE
2.  Papierfilter und Vorfilter (Schaumstofffilter)
demontieren. Vorsichtig arbeiten, damit kein
Schmutz in den Vergaser gelangt. Das
Luftfiltergehäuse reinigen.
3. Den Vorfilter mit flüssigem Spülmittel und
Wasser auswaschen. Filter ausdrücken. Etwas
Öl auf den Filter gießen und einmassieren.
4.  Papierfilter folgendermaßen reinigen: Filter
leicht gegen eine ebene Fläche klopfen. Wenn
der Papierfilter sehr schmutzig ist, sollte er
ausgewechselt werden.
5.  Den Luftfilter in...

64
ENGLISHEN
1 GENERAL
This symbol indicates WARNING. Seri-
ous personal injury and/or damage to
property may result if the instructions
are not followed carefully.
You must read these instructions for use
and the accompanying pamphlet
“SAFETY INSTRUCTIONS” careful-
ly, before starting up the machine.
1.1 SYMBOLSThe following symbols appear on the machine.
They are there to remind you of the care and atten-
tion required during use and maintenance.
This is what the symbols mean:
Warning!
Read the...

65
ENGLISHEN
same pressure and can follow the contours of the
ground.
Use the floating position when carrying out work.
Lowering. The implement lowers re-
gardless of its weight.
Locking in the transport position. The
lever has returned to the neutral position
after raising and lowering. The imple-
ment is locked in the transport position.
Raising. Move the lever to the rear posi-
tion until the implement is in the highest
position (transport position). Then re-
lease the lever to lock in the...

66
ENGLISHEN
2.4.9 Ignition lock/headlight (4,5:I)
The ignition lock is used for starting and stopping
the engine. The ignition lock is also the switch for
the headlight.
Do not leave the machine with the key
in position 2 or 3. There is a fire risk,
fuel can run into the engine through the
carburettor, and there is a risk of the
battery being discharged and damaged.
Four positions:
1. Stop position – the engine is short-cir-
cuited. The key can be removed.
2. Operating position – headlight...

67
ENGLISHEN
3. Release the control lever (1:S) to lock the seat.
The seat is equipped with a safety switch that is
connected to the machine’s safety system. This
means that certain dangerous activities are not pos-
sible when there is nobody sitting on the seat. Also
see 4.3.2.
2.4.18 Engine casing (7:U)
In order to access the fuel cock, battery
and engine, the machine has an engine
casing that can be opened. The engine cas-
ing is locked with a rubber strap.
The engine casing is opened as...

68
ENGLISHEN
Environmental petrol can be used, i.e. alkylate
petrol. This type of petrol has a composition that is
less harmful for people and nature.
Petrol is highly inflammable. Always
store fuel in containers that are made
especially for this purpose.
Only fill or top up with petrol outdoors,
and never smoke when filling or top-
ping up. Fill up with fuel before starting
the engine. Never remove the filler cap
or fill with petrol while the engine is
running or still warm.
Never completely...

69
ENGLISHEN
4.4 Start1.  Open the fuel cock. See 14.
2.  Check that the spark plug cable(s) is/are in-
stalled on the spark plug(s).
3.  Check to make sure that the power take-off is
disengaged.
4.  Do not keep your foot on the drive pedal (3:F).
5. Put the throttle control at full throttle.
Starting cold engine – pull the choke control out
fully.
Starting warm engine – the choke control
should be pressed in.
6.  Depress the clutch-brake pedal (3:B) fully.
7.  Turn the ignition key and start the...

70
ENGLISHEN
5 MAINTENANCE
5.1 Service programmeIn order to keep the machine in good condition as
regards reliability and operational safety as well as
from an environmental perspective, STIGA’s Ser-
vice programme should be followed.
The contents of this programme can be found in
the attached service log.
Basic service
 must always be carried out by an au-
thorised workshop.
First service and intermediate service
 should be
carried out by an authorised workshop, but can
also be carried out by the...
