6.6 SENSOR DISPLAY/ADJUSTMENT
6.6.1  Sensor Display/Adjustment Operation Example

Power OFF   (1)  Power off state

        [FEED] [PAUSE] (2)  While holding the [FEED] and [PAUSE] keys
down, turn the power on.

< 1 > D I A G .       V 1 . 2 A
             (3)  The self-test menu is displayed.

        [FEED]
 (4)  Press the [FEED] key.
< 2 > P A R A M E T E R    S E T


 (5)  System mode menu display
 (Parameter setting)...


- 110 -

< 5 > S E N S O R    A D J .
[ T R A N S . ]       2 . 4 V
             (19)  Transmissive sensor value is display:
Remove a few labels and place the backing
paper so that sensor can detect backing paper.
        [RESTART] or
[FEED]
(20)  Hold down the [RESTART] or [FEED] key for 3
seconds or more.
< 5 > S E N S O R    A D J .
[ T R A N S . ]       4 . 1 V *(21)  “*” is displayed when the transmissive sensor
adjustment is completed.

        [PAUSE]...


- 111 - 6.6.2  Details of Sensor Adjustment Value Display
(1)  Sensor adjustment value display
[  H ] 2 0 ° C      [ A ] 2 2 ° C





[  R E F L E C T ]  3 . 8 V




[  T R A N S . ]    2 . 3 V



[  P E ] R 0 . 2 V  T 4 . 6 V





(2) Supplementary explanations
  •  During a sensor check, status of each sensor is monitored and displayed every 200 msec.
(The display changes in accordance with sensor status.)
  •  When the [FEED] and [RESTART] keys are pressed at the same time,...


- 112 -
6.7 RAM CLEAR
6.7.1  RAM Clear Operation Example

Power OFF   (1)  Power off state

        [FEED] [PAUSE] (2)  While holding the [FEED] and [PAUSE] keys
down, turn the power on.

< 1 > D I A G .       V 1 . 2 A
             (3)  The self-test menu is displayed.

        [FEED]
 (4)  Press the [FEED] key.
< 2 > P A R A M E T E R    S E T


 (5)  System mode menu display
 (Parameter setting)

        [FEED]
 (6)  Press the...


- 113 -

< 6 > R A M    C L E A R
P A R A M E T E R    C L E A R(19)  Parameter clear mode

        [PAUSE]
 (20)  Press the [PAUSE] key.
< 6 > R A M    C L E A R
* * *    Q M    T Y P E    * * *(21)  RAM clear for the QM type

        [FEED]
 (22)  Press the [FEED] key.
< 6 > R A M    C L E A R
* * *    J A    T Y P E    * * *(23)  RAM clear for the JA type

        [PAUSE]
 (24)  Press the [PAUSE] key.
< 6 > R A M    C L E A...


- 114 - 6.7.2  Details of RAM Clear
(1)  RAM clear mode

  •  NO RAM CLEAR
 • MAINTE.CNT CLEAR
 • PARAMETER CLEAR


(2) Destination type

  •  QM TYPE (for North/South America/Europe/Asia/China)
  •  JA TYPE (for Japan)



(3) Supplementary explanations
•  When the [FEED] and [RESTART] keys are pressed at the same time, the display shows
the system mode menu.
•  When “COMPLETE” is displayed after a RAM clear is complete, turn off the power.
• The total label distance covered,...


- 115 - (5)  Values after parameter clear
Parameter Value
Feed amount fine adjustment (PC)  0 mm
Cut (strip) position fine adjustment (PC)  0 mm
Reverse feed amount fine adjustment (PC)  0 mm
Print tone fine adjustment:
  Thermal transfer print mode (PC) 0
Print tone fine adjustment:
  Direct thermal print mode (PC) 0
Ribbon motor drive voltage fine adjustment
(Take-up) (PC) 0
Ribbon motor drive voltage fine adjustment
(Feed) (PC) 0
Feed amount fine adjustment (Key)  0 mm
Cut (strip)...


- 116 -
Parameter Value
Web printer function  OFF
Reset process when the nInit signal is ON  OFF
Ribbon near end detection    OFF
Expansion I/O operation mode  Normal
Plug-and-play operation mode  OFF
Label end/ribbon error process    The printer stops an issue operation.
Pre-strip process    OFF
Reverse feed speed    3 ips
MaxiCode specification    TYPE1
Keyboard I/F  OFF
Automatic calibration  OFF
LAN enable/disable  Enable
Status response  ON
Label pitch  76.2 mm
Effective print...


- 117 - Parameter Value
System mode password setting  OFF
Strip motor torque  R0
Print head applied current table setting  TYPE1
High speed cut issue  TYPE1
Multiple-label set issue  OFF
Z-Mode (C1.9A or later)  OFF
