Aaxa Projector P3 User Manual

Photo Menu
19
Viewing Pictures
The P3 Pico Projector allows you to view pictures individually or in a s\
lideshow.
To view individual photos, select the file you want to
view in the file menu for the particular storage device
on which the image file is stored.  You can press the
left and right arrow buttons on the directional pad or
remote to flip through the pictures you have in the present
folder.
Viewing Pictures in a Slideshow
To view your pictures in a slideshow, select a file and press the...

Music Player Menu
20
Pause
Rewind
FastFoward
Previous File
Next file
Stop
Repeat
Mute
Opening a file:
• Choose “Open File” option
• Select device file is stored on
• Select file from list

Pause
Rewind
FastFoward
Previous File
Next file
Stop
Repeat
Mute
Listening to music
-To play/pause a song, press the ok      button in the middle of the keypad or
remote control
-To rewind, press and hold the left arrow button
-To fast-forward, press and hold the right arrow button
-To jump forward to the next video, press the right arrow button
-To jump back to a prior video, press the left arrow button
-To adjust the volume, press the vol+ ( on the remote) to increase and vol- ( on
the remote) to...

Technical Details
22
Chapter 4
IMAGE IS BLURREDPossible CausesSolution
The Projector is not in focusAdjust the focus with the focus adjustment dial until the image comes into focus
The Projector is offset from plane / angle of operationMove the projector so that it is both 180 degrees and on an evern plane with the screen.
No Sync, No Signal
Troubleshooting
1. Be sure to setup the computer to enable a video signal output.  On some
laptops this is done by pressing and holding Function F5 key.  If using...

Technical Details
23
THE PROJECTOR DOES NOT TURN ONPossible CausesSolution
There is no powerCheck to ensure the power outlet or battery source is good.  check the power adapter to ensure a proper connection with the wall outlet as well as the proejctor.  Confirm that the unit is charged and has enough power
The power button was not held long enoughTo power on the projector, the power button needs to be depressed for a full 3 seconds.  Try holding the power button until the optical engine turns on
NO...

Specifications
24
Brightness
Native Resolution
Contrast Ratio
Projection Lens:
Image Size:
Lamp:
Video in:
Audio Output:
USB:
Dimensions
Weight
Supported File Formats
50 Lumens
1024x600(WSVGA)
500:1
Manual Focus
10~80 inches
15,000 hour RGB Triple LEDs
Composite A/V
VGA(mini-VGA)
HDMI
1.0 W stereo speakers
3.5 mm audio jack
USB OTG (On-the-Go)
(Memory Sticks)
USB Data Transfer
4.6”x 2.6”x1.2”
0.5 lbs
MPEG1,MPEG2,MPEG4,H264
RM,RMVB,MOV,MJPEG,VC1,
DivX, JPEG, BMP, PNG, TXT

Please direct all customer service inquiries to:
AAXA Technologies, Inc.
103A East Alton
Santa Ana, CA 92707
(714) 957-1999
[email protected]
