Panasonic Dmc Fp5 Owners Manual

Others
- 131 -
The folder number and the file number are displayed as [—] and the screen turns
black.
•

Is this a non-standard picture
 , a picture which has been edited using a PC or a picture
which was taken by another maker of digital camera?
•

Did y
 ou remove the battery immediately after picture-taking or did you take the picture
using a battery with a low remaining charge?
 p F

ormat the data to delete the pictures mentioned above. (P45)
(Other pictures will be deleted as well and it will...

Others
- 132 -
TV, PC and printer
The picture does not appear on the television.
•

Is the camer
 a connected to the TV correctly?
 pSet the

TV input to External Input Mode.
The display areas on the TV screen and the camera’s LCD Monitor are different.
•

Depending on the
 TV model, the pictures may be extended horizontally or vertically or
they may be displayed with their edges cut off.
The motion pictures cannot be played back on a TV.
•

Are y
 ou trying to play back the motion pictures by...

Others
- 133 -
The picture cannot be printed when the camera is connected to a printer.
•

Pictures cannot be pr
 inted using a printer which does not support PictBridge.
•

Set to [PictBr
 idge(PTP)] in [USB Mode]. (P111)
The ends of the pictures are cut at printing.
 pWhen using a pr

inter with a cropping or borderless printing function, cancel this
function before printing. (For details, refer to the operating instructions for the printer.)
 p When y

ou order photo studios to print pictures, ask...

Others
- 134 -
When pictures are taken using the zoom, they are slightly distorted and the areas
around the subject contain colors which are not actually present.
•

It is possib
 le that the subject may be warped slightly, or the borders get colored,
depending on the zoom magnification, due to the characteristics of the lens, but this is
not a malfunction.
Zooming stops instantaneously.
•

When using the Extended Optical Zoom or Intelligent Zoom, the z
 ooming action will
stop temporarily. This is...

Others
- 135 -
• The number of recordable pictures and the available recording time are an approximation. (These vary depending on the recording conditions and the type of card.)
•

The n
 umber of recordable pictures and the available recording time varies depending on
the subjects.
„„ Number of recordable pictures
• When the n umber of recordable pictures exceeds 99999, it
is displayed as “+99999” on the screen.
Picture size Built-in Memory
(Approx. 70 MB) Card
2 GB 4 GB 16 GB
16 M (4:3)...

Others
- 136 -
„„Available recording time (when recording motion pictures)
Recording quality
setting Built-in Memory
(Approx. 70 MB) Card
2 GB 4 GB 16 GB
a –
10 min 10 s 20 min 30 s 1 h 23 min
x –
21 min 40 s 43 min 10 s 2 h 56 min
y 2 min 30 s 1 h 2 min 2 h 4 min 8 h 28 min
•

Motion pictures can be recorded contin
 uously up to 2 GB.
The maximum available recording time for up to 2 GB only is displayed on the screen.
 Note
•
 The n umber of recordable pictures and the available recording...

Others
- 137 -
• SDXC Logo is a trademark of SD-3C, LLC.
•  Quic kTime and the QuickTime logo are trademarks or registered
trademarks of Apple Inc., used under license therefrom.
•

Y
 ouTube is a trademark of Google Inc.
•

This product uses
 “DynaFont” from DynaComware Corporation.
DynaFont is a registered trademark of DynaComware Taiwan Inc.
•

Other names
 , company names, and product names printed in these
instructions are trademarks or registered trademarks of the companies
concerned.
