Connecting to other equipment
- 111 -
If you connect the camera to a printer supporting PictBridge, you can select the pictures
to be printed out and instruct that printing be started on the camera’s LCD Monitor.
•
 Some pr
inters can print directly from the card removed from the camera. For details,
refer to the operating instructions of the printer.
Preparations:
 T

urn on the camera and the printer.
Remove the card before printing the pictures in the built-in memory.
Perform the print quality...

Connecting to other equipment
- 112 -
 Note
•

Do not use an
 y other USB connection cables except the supplied one.
Use of cables other than the supplied USB connection cable may cause malfunction.
•

T

urn the camera off before connecting or disconnecting the AC adaptor (optional).
•

Bef
 ore inserting or removing a card, turn the camera off, and disconnect the USB
connection cable.
•

Motion pictures recorded cannot be pr
 inted out.
 Drag the screen horizontally to select image, and then...

Connecting to other equipment
- 113 -
ItemDescription of settings
[Multi Select] Multiple pictures are printed at one time.
•

S
 witch the screen by touching [e] / [r] if these are displayed on
the slide bar.
•

Touch the pictures and [
 2] appears on the pictures to be
printed. (When the selected picture is touched again, the setting
is canceled.)
•

After the pictures ha
 ve been selected, touch [Set].
[Select All] Prints all the stored pictures.
[Print Set (DPOF)]Prints the pictures set in...

Connecting to other equipment
- 114 -
[Print with Date]
ItemDescription of settings
[ON] Date is printed.
[OFF] Date is not printed.
•

If the pr
 inter does not support date printing, the date cannot be printed on the picture.
•

Since the pr
 inter’s settings may take precedence over the Print With Date setting, check
the printer’s Print With Date setting as well.
•

When pr
 inting pictures with characters or dates stamped, if you specify the date print,
the date will be overlapped and printed....

Connecting to other equipment
- 115 -
[Page Layout] (Layouts for printing that can be set with this unit)
ItemDescription of settings
h Settings on the printer are prioritized
3 1 picture with no frame on 1 page
4 1 picture with a frame on 1 page
5 2 pictures on 1 page
6 4 pictures on 1 page
•

An item cannot be selected if the pr
 inter does not support the page layout.
„„ Layout printing
When printing a picture several times on 1 sheet of paper
For example, if you want to print the same...

Others
- 116 -
„„In recording
Recording in Normal Picture Mode [1] (Initial setting)
1 Recording Mode
2  Picture siz e (P76)
Recording quality (P34)
Flash Mode (P51)
Optical Image Stabilizer (P86)
Jitter alert (P28): 0
3

F
 ocus (P27)
4

AF area
 (P27)
5

AF Macro
 (P55)
Macro Zoom (P56)
AF mode (P79)
6

Batter
 y indication (P12)
7

Built-in memor
 y (P16)
Access indication (P17): 2, 3
Number of recordable pictures (P135)
(When the number of recordable pictures exceeds 99999, it is...

Others
- 117 -
„„In recording (after settings)
15 Exposure Compensation  (P58)
16  White Balance  (P78)
Color Mode (P84)
17

Burst
 (P83)
18

Intelligent Exposure
 (P82): -
AF Assist Lamp (P85): W
19

Shor
 tcut area (P41)
20

Elapsed recording time
 (P34):
00h00m00s
1
21 Zoom / Extended Optical Zoom  (P48)   /
Intelligent Zoom  (P49) / Digital Zoom  (P49,
83)
22 Current date and time / w: Travel destination setting2 (P74) / Age3 (P66) / Name3
(P66) / Location2 (P72) / Number...

Others
- 118 -
„„In playback
1 Playback Mode (P31)
2 Recording quality (P34)
Color Mode (P84)
Protected picture (P103)
F
avorites (P100)
Stamped with text indication (P96)
Picture Size (P76)
3
 Motion picture pla

yback (P36)
4
 Picture n

umber / Total pictures
Elapsed playback time (P36):
00h00m00s

5 Battery indication (P12)
6 Beauty retouched indication (P93)
Number of pr
ints (P114)
LCD mode (P43)
7
 Built-in memor

y (P16)
Cable disconnection warning icon (P111): 1
Folder / File number...

Others
- 119 -
Keep this unit as far away as possible from electromagnetic equipment (such as
microwave ovens, TVs, video games etc.).
•
If y
 ou use this unit on top of or near a TV, the pictures and/or sound on this unit may be
disrupted by electromagnetic wave radiation.
•

Do not use this unit near cell phones because doing so ma
 y result in noise adversely
affecting the pictures and/or sound.
•

Recorded data ma
 y be damaged, or pictures may be distorted, by strong magnetic
fields created...

Others
- 120 -
Cleaning
Before cleaning the camera, remove the battery or the DC coupler (optional), or
disconnect the power plug from the outlet. Then wipe the camera with a dry soft
cloth.
•

When the camer

a is very dirty, it can be cleaned by wiping the dirt off with a wrung wet
cloth, and then with a dry cloth.
•

Do not use solv

ents, such as: benzine, thinner, alcohol, kitchen detergents, etc., to clean
the camera, as it may deteriorate the external case or the coating may peel off.
•...
