Panasonic Dmc Fp5 Owners Manual

Advanced (Playback)
- 101 -
[Print Set]
DPOF “Digital Print Order Format” is a system that allows the user to select which
pictures to print, how many copies of each picture to print and whether or not to print the
recording date on the pictures when using a DPOF compatible photo printer or photo
printing store.
For details, ask at your photo printing store.
When you want to use a photo printing store to print pictures recorded on the built-in
memory, copy them to a card (P104) and then set the print...

Advanced (Playback)
- 102 -
„„To print the date
After setting the number of prints, set/cancel printing with the recording date by touching
[Date].
•

Depending on the photo pr
 inting store or the printer, the date may not be printed even if
you set to print the date. For further information, ask at your photo printing store or refer
to the operating instructions for the printer.
•

The date cannot be pr
 inted on pictures stamped with text or date.
 Note
•

The n
 umber of prints can be...

Advanced (Playback)
- 103 -
[Protect]
You can set protection for pictures you do not want to delete by mistake.
 Select [Protect] on the [Playback] Mode menu. (P39)
 Touch [S (Single)] or [M (Multi)].
 Select the picture .[Single][Single] setting
Drag the screen horizontally to select an image,
and then touch [Set].
•

F
 or how to select a picture, see P31.
•

Setting is canceled b
 y touching [Cancel].
[Multi][Multi] setting
Touch the picture you wish to protect.
•
F
 or how to select a picture,...

Advanced (Playback)
- 104 -
[Copy] Copying pictures from the built-in memory to a card
You can copy the data of the pictures you have taken from the built-in memory to a card
or from a card to the built-in memory.
 Select [Copy] on the [Playback] Mode menu. (P39)
 Touch the copy destination.
N: All the picture data in the b uilt-in memory are copied onto the card at one
time. " step 4.
M:
 One picture at a time is copied from the card to the b

uilt-in memory. " step
3.
 Drag the screen...

Connecting to other equipment
- 105 -
Playing back pictures using the AV cable (supplied)
Preparations:  Set the [Output]. (P44)
Turn this unit and the TV off.
1	 Yellow: To the video input socket
2	 White: To the audio input socket
A	 Align the marks, and insert straight. (Cannot insert in the opposite direction.)
B	 AV cable (supplied)
•

Chec
 k the directions of the connectors, and plug them straight in or unplug them straight
out. (Otherwise the connectors may be bent out of shape which may cause...

Connecting to other equipment
- 106 -
 Note
•

Depending on the aspect r
 atio, black bands may be displayed on the top and bottom or
the left and right of the pictures.
•

Do not use an
 y other AV cables except the supplied one.
•

Read the oper
 ating instructions for the TV.
•

When y
 ou play back a picture vertically, it may be blurry.
•

Y

ou can view pictures on TVs in other countries (regions) which use the NTSC or PAL
system when you set [Video Out] in the [Setup] menu. (PAL video out...

Connecting to other equipment
- 107 -
You can acquire recorded pictures to a PC by connecting the camera and the PC.
• Some PCs can read directly from the card remo ved from the camera. For details, refer
to the operating instructions of the PC.
•

Y
 ou can easily print out or e-mail the pictures you have imported. Use of the
“PHOTOfunSTUDIO” bundled software on the CD-ROM (supplied) is a convenient way
of doing this.
•

Read the separ
 ate operating instructions for the supplied software for more...

Connecting to other equipment
- 108 -
 Connect the camera to the PC using the USB connection cable A.• Do not use any other USB connection cables except the supplied one.
Use of cables other than the supplied USB connection cable may cause a
malfunction.
 Touch [PC].• When the camer a has been connected to the PC with
[USB Mode] set to [PictBridge(PTP)], a message may
appear on the PC’s screen. Select [Cancel] to close the
screen, and disconnect the camera from the PC. Then
set [USB Mode] to [PC]...

Connecting to other equipment
- 109 -
„„Viewing the contents of the built-in memory or card using the PC (folder
composition)
1	Folder number
2	 File number
3	 JPG:
 Pictures MO

V:
 Motion Pictures
MISC:


DPOF pr
 int
Favorite
AD

_LUMIX:
  For Upload Set
LUMIXUP.EXE:

Upload Set tool

(LUMIX Image Uploader)
• Built-in
memor y
•

Card
A ne

w folder is created when pictures are taken in the following situations:
•

When a card containing a f
 older with the same folder number...

Connecting to other equipment
- 110 -
Uploading pictures to the image sharing sites
Using the upload tool (LUMIX Image Uploader), you can upload pictures or motion
pictures to the image sharing sites (Facebook, YouTube).
You do not need to import pictures to the computer or to install software. Only with
the computer that can be connected to the Internet, you can upload pictures. This is
convenient when immediately publicizing pictures taken while traveling.
•
Set pictures to upload with [Upload Set]...
