Advanced (Recording pictures)
- 81 -
„„About [7] (AF Tracking)
When the subject is touched on the screen, the subject is
set as a target of AF tracking.
•

The AF area (AF tr
 acking frame) is displayed in yellow.
The camera continues to focus the subject and adjust the
exposure even if the subject moves afterwards.
•

T
 o reselect the subject, touch [T] and perform operation
again.
 Note
•

Depending on the recording condition or subject condition including the f ollo

wing cases,
the...

Advanced (Recording pictures)
- 82 -
[Exposure]
Refer to P58 for details.
[i.Exposure]
For details on [Rec] Mode menu settings, refer to P39.
Contrast and exposure will be adjusted automatically when there is a big difference in
brightness between the subject and background.
Applicable modes: 1 6
[ON] / [OFF]
 Note
•

Ev
 en when the [Sensitivity] is set to [ISO100], [Sensitivity] may be set higher than
[ISO100] if the picture is taken with [i.Exposure] set to valid.
•

Compensation eff
 ect may not...

Advanced (Recording pictures)
- 83 -
[Digital Zoom]
For details on [Rec] Mode menu settings, refer to P39.
This can enlarge subjects even more than the Optical Zoom, Extended Optical Zoom or
Intelligent Zoom.
Applicable modes: 1 < 5 /
[ON] / [OFF]
 Note
•

Ref
 er to P49 for details.
•

The setting is fix
 ed to [ON] in Macro Zoom Mode.
•

[Digital Zoom] cannot be set in Motion Picture Mode
 . Setting of other Recording Mode
will be reflected.
[Burst]
For details on [Rec] Mode menu settings, refer...

Advanced (Recording pictures)
- 84 -
 Note
•

Do not tur
 n the camera off or remove the card after recording until the access indication
lights off.
•

The Burst speed becomes slo
 wer halfway. The exact timing of this depends on the type
of card, the picture size and the quality.
•

The f
 ocus is fixed when the first picture is taken.
•

The e
 xposure and the White Balance are adjusted each time you take a picture.
•

When the self-timer is used, the n
 umber of recordable pictures in Burst...

Advanced (Recording pictures)
- 85 -
[AF Assist Lamp]
For details on [Rec] Mode menu settings, refer to P39.
Illuminating the subject makes it easier for the camera to focus when recording in low light
conditions that make focusing difficult.
Applicable modes: 1 < 5 /
[ON]:
When taking pictures in dar
 k places, the AF Assist Lamp lights while the shutter
button is pressed halfway. (Larger AF areas are now displayed.)
[OFF]:

The AF Assist Lamp does not tur
 n on.
 Note
•

The eff
 ective range of...

Advanced (Recording pictures)
- 86 -
[Stabilizer]
For details on [Rec] Mode menu settings, refer to P39.
This automatically detects jitter and corrects for it.
Applicable modes: 1 < 5 /
[ON] / [OFF]
 Note
•

The Stabiliz
 er function may not be effective in the following cases.
 – When there is a lot of jitter

, when the zoom magnification is high.
 – In Digital Zoom r

ange.
 – When taking pictures while f

ollowing a moving subject.
 – When the shutter speed becomes slo

wer to take pictures indoors...

Advanced (Recording pictures)
- 87 -
Entering Text
It is possible to enter babies’ and pets’ names and the names of travel destinations when
recording. (Only alphabetical characters and symbols can be entered.)
You can use the stylus pen (supplied) if it is hard to operate with your fingers.
 Display the entry screen.• You can display the entry screen via the following operations. – [Name] of [Baby1] / [Baby2] or [Pet] in Scene Mode. (P66)
 – [Location] in [T

ravel Date] (P72)
 Enter characters.• To...

Advanced (Playback)
- 88 -
You can play back the pictures you have taken in synchronization with music, and you can
do this in sequence while leaving a fixed interval between each of the pictures.
Furthermore, you can play back the pictures grouped together by category or play back
only those pictures you have set as favorites as a Slide Show.
This playback method is recommended when you have connected the camera to a TV to
view the pictures.
 Touch [w9] in Playback Mode.
 Touch [8].
 Touch the item.
•...

Advanced (Playback)
- 89 -
„„Operations performed during slide show
Display control panel by touching screen.
•

If there is no oper
 ation for approx. 2 seconds, the operation icon will disappear.
[q/h]:

Pla
 y/Pause
[g]:

Exit
[

i]:
F
 orward to next picture (While paused)
[u]:

Bac
 k to previous picture (While paused)
[:]:

The setting screen retur
 ns.
[4] [3]:

Adjust v
 olume
•

Y
 ou can also adjust the volume level by using the zoom lever.
„„Changing the Slide Show...

Advanced (Playback)
- 90 -
Selecting Pictures and Playing them Back
[Playback] Mode: 5
[Calendar]
You can display pictures by recording date.
 Touch [w9] in Playback Mode.
 Touch [0].• You can also move the zoom lever to [6] (W) several times to display the
calendar search display screen.
 Touch [e] / [r] to select the month to be played back.
• If there were no pictures recorded during a
month, the month is not displayed.
•

The m
 ulti playback screen will appear by
touching []]. (P32)
 Touch the...
