Advanced (Recording pictures)
- 71 -
[High Dynamic]
You can use this mode to easily record pictures in which bright and dark regions of the
scene are expressed with suitable brightness when looking into the sun, at night, or in
similar circumstances.„„Setting the effect
[STD.]

:
  Natural color effect
[ART]

:
  Eye-catching effect which emphasizes contrast and color
[B&W]

:
  Black and white effect
 Note
•

ISO sensitivity is fix
 ed to [ISO400].
•

Compensation eff
 ect may not be...

Advanced (Recording pictures)
- 72 -
Recording which Day of the Vacation You Take the Picture
For details on the [Setup] menu settings, refer to P39.
If you set the departure date or the travel destination of the vacation in advance, the
number of days that have passed since the departure date (which day of the vacation
it is) is recorded when you take the picture. You can display the number of days that
have passed when playing back the pictures and stamp it on the recorded pictures with
[Text...

Advanced (Recording pictures)
- 73 -
 Touch [SET].
 Enter the location.• For details on how to enter characters, refer to the “Entering Text” on P87.
• After setting, close the men u.
„„ Canceling the travel date
The travel date is automatically canceled if the current date is after the return date. If you
want to cancel the travel date before the end of the vacation, touch [OFF] on the screen
shown in step 3 or 7. If the [Travel Setup] is set to [OFF] in step 3, [Location] will be also
set...

Advanced (Recording pictures)
- 74 -
Recording Dates / Times at Overseas Travel Destinations (World Time)
For details on the [Setup] menu settings, refer to P39.
You can display the local times at the travel destinations and record them on the pictures
you take.
•
Select [Cloc
 k Set] to set the current date and time in advance. (P18)
 Select [World Time] from the [Setup] menu.• When first using the camer a after purchasing it, the [Please set the home area]
message appears. Set the home area on the...

Advanced (Recording pictures)
- 75 -
 Touch [Destination].• Depending on the setting, the time at the travel destination area or the home area
is displayed.
C
D
 Touch [w] or [q] to select the area that the  travel destination is in, and touch [Set].
C	 Current time of the destination area
D	 Time difference
•

If da
 ylight saving time [z] is used at the travel
destination, touch [z]. (The time advances
by one hour.) Touch [z] again to return to the
original time.
•

After setting, close the men...

Advanced (Recording pictures)
- 76 -
[Flash]
Refer to P51 for details.
[Selftimer]
Refer to P57 for details.
[Picture Size]
For details on [Rec] Mode menu settings, refer to P39.
Set the number of pixels and aspect ratio of the pictures. The higher the number of pixels,
the finer the detail of the pictures will appear even when they are printed onto large
sheets.
Applicable modes: 4 1 < 5 /
[4:3 16M] (DMC-FP7)4608   ×   3456
[4:3 14
M] (DMC-FP5) 4320   ×   3240
[4:3 10
M P]3648 × 2736
[4:3 5
M P] 2560...

Advanced (Recording pictures)
- 77 -
[Rec Quality]
Refer to P34 for details.
[Sensitivity]
For details on [Rec] Mode menu settings, refer to P39.
This allows the sensitivity to light (ISO sensitivity) to be set. Setting to a higher number
enables pictures to be taken even in dark places without the resulting pictures coming out
dark.
Applicable modes: 1
[,] / [100] / [200] / [400] / [800] / [1600]
ISO sensitivity100    1600
Recording location
(recommended) When it is light (outdoors) When it is dark...

Advanced (Recording pictures)
- 78 -
[White Balance]
For details on [Rec] Mode menu settings, refer to P39.
In sunlight, under incandescent lights or in other such conditions where the color of white
takes on a reddish or bluish tinge, this item adjusts to the color of white which is closest to
what is seen by the eye in accordance with the light source.
Applicable modes: 1 < 5 / 6
[AWB] (Automatic adjustment) / [l] (Outdoors under a clear sky) / [x] (Outdoors
under a cloudy sky) / [c] (Outdoors in...

Advanced (Recording pictures)
- 79 -
Auto White Balance
Depending on the conditions when pictures are taken, the pictures may take on a reddish
or bluish tinge. Furthermore, when a multiple number of light sources are being used or
there is nothing with a color close to white, Auto White Balance may not function properly.
In this case, set the White Balance to a mode other than [AWB].
1)
10000 K9000 K
8000 K
7000 K
6000 K
5000 K
4000 K
3000 K
2000 K
1000 K2)
4)
6)
7)
8)
9)
10)3) 5)1 Auto white balance...

Advanced (Recording pictures)
- 80 -
„„About [3] (Face Detection)
The following AF area frames are displayed when the camera
detects the faces.
Yellow:
When the shutter button is pressed halfway, the frame turns
green when the camera is focused.
White:
Displayed when more than one face are detected. Other
faces that are the same distance away as faces within the yellow AF areas are also
focused.
•

Under cer
 tain picture-taking conditions including the following cases, the Face Detection...
