161
7. Recording Motion Pictures
When [MP4 (LPCM)], [MOV] is selected(± : Available, —: Not available)
¢ 1 4K motion picture
¢ 2 ALL-lntra:
“ALL-Intra” refers to a data compression method in which each f rame is compressed. The file
size of motion pictures recorded in this method becomes larger,  but this method can prevent
the loss of image quality because editing does not require re-encoding.
ItemSystem frequencySizeRecording  frame rateSensor  outputBit rate59.94Hz
(NTSC)50.00Hz (PAL)24.00Hz...

7. Recording Motion Pictures
162
∫About the compatibility of the recorded motion pictures
Even when a compatible device is  used, recorded motion pictures may be played back
with reduced picture and sound qua lity, or they may not be played back.
Also, recording information may not be displayed correctly. Use  this unit to playback in
such case.
• To play back motion pictures recorded with [FHD/28M/60p], [FHD /28M/50p], [FHD/24M/30p],
[FHD/24M/25p] or [FHD/24M/24p] in [AVCHD] with another device,  or...

163
7. Recording Motion Pictures
Applicable modes:
Focusing changes depending on the Focus Mode setting (P89) and the [Continuous AF]
setting in the [Motion Picture] menu.
¢ If Creative Video Mode is active, focusing is continuously perf ormed even when the camera
is in recording standby mode.
• When the focus mode is set to [AFS], [AFF] or [AFC], if you pr ess the shutter button halfway
while recording a motion picture, the camera will re-adjust the  focus.
• Depending on the recording conditions,...

7. Recording Motion Pictures
164
Applicable modes:
You can record still pictures while recording a motion picture. (Simultaneous recording)
∫ Setting the motion picture priority or still picture priority m ode
Applicable modes:
Select the menu.  (P51)
Recording still pictures while recording motion pictures
During motion picture recording, press the
shutter button fully to record a still picture.
• Simultaneous recording indicator is displayed while recording  still pictures.
• Recording with the...

165
7. Recording Motion Pictures
Applicable modes:
You can specify the recording time in advance and record motion pictures casually like you
take snapshots. The function also allows you to shift a focus at the start of recording and
add fade in/out effects in advance.
• The [Rec Quality] setting used f or recording is determined by the [System Frequency]  setting
as follows:
– With [59.94Hz(NTSC)] :  [FHD/20M/30p] in [MP4]
– With [50.00Hz(PAL)] :  [FHD/20M/25p] in [MP4]
• Using the smartphone/tablet...

7. Recording Motion Pictures
166
∫Changing the Snap Movie settings
Select the menu.  (P51)
>  [Motion Picture]  > [Snap Movie]  > [SET]
[Record time] Sets the recording time of motion pictures.
[Pull Focus]Allows dramatic imaging expression by shifting focus gradually
at the start
of recording.  (P167)
[Fade] Adds a fade-in (gradual appearance) effect to an image and audi
o as
recording starts or adds a fade-out (gradual disappearance) eff ect to them
as recording ends.
[WHITE-IN]/[WHITE-OUT]:
Adds a...

167
7. Recording Motion Pictures
Set the frames that specify the positions where the [Pull
Focus] starts (first position) and stops (second position).
1Press 2.2Press 3/4/2/1 to move the AF area frame, and
press [MENU/SET]. (First position)
• If you press [DISP.] before pressing [MENU/SET], the
frame will return to the center.
3Repeat step 2. (Second position)• If you press [MENU/SET], the frame settings will be canceled.
Touch a subject (first position), drag your finger to the desir ed location...

7. Recording Motion Pictures
168
Recording Motion Pictures Using Various
Effects and Advanced Settings
(Creative Video Mode)
Recording Mode:
∫Note on recording with the [Slow/Quick], [Dolly Zoom]  or [Varia ble Frame Rate]
function
• You can use the [Rec Format] and [Rec Quality]  settings below.
[Slow/Quick]  (P169)It is possible to switch to slow or quick motion during motion
recording.
[Dolly Zoom]  (P170)
Allows you to record images that only change the angle of view
in the background...

169
7. Recording Motion Pictures
1Set the mode dial to [ ].
2Select an item that supports [Variable Frame Rate]. (P168)
• [MP4] does not support [Variable Frame Rate].
• Items available for recording with a [Variable Frame Rate] are  indicated as [VFR
available] on the screen.
3Select the menu. (P51)
4Press the motion picture button (or shutter button) to start re cording.
5Press and hold [Fn1] to record the scene that you want to record in
quick motion, or press and hold [Fn2] to record the scene that...

7. Recording Motion Pictures
170
1Set the mode dial to [ ].
2Select an item that supports [Variable Frame Rate]. (P168)
• [MP4] does not support [Variable Frame Rate].
• Items available for recording with a [Variable Frame Rate] are  indicated as [VFR
available] on the screen.
3Select the menu. (P51)
4Align the subject’s position with the center
frame.
• The Auto Focus Mode will be set to Face/Eye Detection.
• Adjust so that the face detection frame and center frame  appear in the same size. When they...
