Panasonic Dmc G7 Owners Manual

291
11. Using the Wi-Fi function
Wi-Fi function
∫Before Use
•Set the date and time settings in advance.  (P41)•To use the Wi-Fi function on this unit, a wireless access point or a destination device equipped
with the wireless LAN function is required.
∫About the Wi-Fi connection lamp
∫ About the [Wi-Fi] button
In this owner’s manual, a function button to which [Wi-Fi] is assigned is
referred to as the [Wi-Fi] button. (At the time of purchase, [W i-Fi] is assigned to [Fn6].)
•
Refer to  P70 for details...

11. Using the Wi-Fi function
292
What you can do with the [Wi-Fi] button when connected to Wi-Fi
•Following items can be selected.
¢ 1 These items are not displayed when you press
4 to send the displayed image to a web
service  (P320) or when you change the settings for sending images or terminat e the
connection.
¢ 2 This is not displayed when the destination of [Remote Shooting  & View], [Playback on TV] or
[Send Images Stored in the Camera]  is set to [Printer] .
[Terminate the Connection]...

293
11. Using the Wi-Fi function
∫Describing method
When  “select [Select a destination from History]” , etc. is
described in a step, perform any of the following operations.
•
The camera cannot be used to connect to a public wireless LAN c onnection.•Use a IEEE802.11b, IEEE802.11g or IEEE802.11n compatible device  when using a wireless
access point.
•We strongly recommend that you set an encryption to maintain in formation security.•It is recommended to use a fully charged battery when sending...

11. Using the Wi-Fi function
294
Controlling with a Smartphone/Tablet
Using a smartphone, you can record images on the
camera and save them.
You need to install “ Panasonic Image App ” (referred to
as “ Image App ” from this point on )  on your
smartphone.
The “ Image App ” is an application provided by Panasonic.
•
OS
•Use the latest version.•Supported OSs are current as of May 2015 and are subject to change.•Read the [Help] in the “ Image App ” menu for further details on how to operate.
•The screen...

295
11. Using the Wi-Fi function
You can easily set up a direct connection to your smartphone without entering a password.When [Wi-Fi Password] is set to the default setting [OFF], third parties may intercept
Wi-Fi radio waves and collect the content of communications. To  set [Wi-Fi Password] to
[ON], refer to   P296.
1Select the menu on the camera.  (P63)
•
The information required for connecting the smartphone to
this unit (SSID) is displayed. A SSID
•You can also display the information by...

11. Using the Wi-Fi function
296
∫Using a password to set up a connection
When [Wi-Fi Password] is set to [ON], you scan a QR code or manually enter a password to
set up a connection. Taking either of these steps will improve your security.
•To scan a QR code with “ Image App ” on an iOS device, iOS 7.0 or  later is required.
1Select the menu on the camera. (P63)
•
The information required for connecting the smartphone to this  unit (QR code, SSID and
password) is displayed.
•You can also display the...

297
11. Using the Wi-Fi function
3Using “ Image App ”, scan the QR code displayed
on the screen of the camera.
•
If you press [MENU/SET] on the camera, the QR
code will be enlarged. When it is difficult to scan
the QR code, try enlarging it.
A SSID and password
B QR code
4Install the profile.
•A message will be displayed on the browser.
•If the smartphone is locked with a passcode, enter the passcode  to unlock the
smartphone.
5 Press the home button to close the browser.
6 Turn on the Wi-Fi function...

11. Using the Wi-Fi function
298
If you are using an Android device
When scanning the QR code to set up a connection
1Start “ Image App ”.  (P294)
2 Select [QR code].
•
When the smartphone is connected to a wireless access point, it  may tak e time to
display [QR code].
3 Using “ Image App ”, scan the QR code displayed
on the screen of the camera.
•
If you press [MENU/SET] on the camera, the QR
code will be enlarged. When it is difficult to scan
the QR code, try enlarging it.
When using an SSID and...

299
11. Using the Wi-Fi function
∫Changing the connection method
To change the connection method, follow the steps below:
(When the connection was made using [Wi-Fi] in the
[Setup] menu)
Press [DISP.]
(When the connection was made by pressing [Wi-Fi])
When connecting via a wireless access point ([Via Network]):
1Select [Via Network].
•Follow the connection procedure described on  P329 to connect the camera to a wireless
access point.
2Turn on the Wi-Fi function.3Connect the smartphone to the wireless...

11. Using the Wi-Fi function
300
∫Terminating the connection
After use, terminate the connection to the smartphone.
1Select the menu on the camera.  (P63)
•
You can also terminate the connection by pressing [Wi-Fi] on the camera.  (P292)
2On the smartphone, close “ Image App ”.
1Connect to a smartphone. (P295)2Operate the smartphone.
∫ Taking a picture while jumping
When you hold your smartphone and jump, the camera’s
shutter can be released automatically as the smartphone
detects the peak of the jump....
