3.
Set the exit tray.
a.Pull out the exit tray. b.
Open the feed extension tray. c.
Open the exit stopper. Operating Manual 21 Installation

4.
Connect the AC adaptor ( A) and the power cord (B).
• Connect the power cord to the AC adaptor.
• Connect the AC adaptor to the scanner.
• Plug into the AC outlet. AC adaptor
Power cord
To AC outlet
Notice
•Use only with the power cord and the AC adaptor enclosed with the unit.
• When
the unit is not used over an extended period of time, turn the unit off, and unplug the power cord.
The scanner consumes approximately 0.3 W of electricity even when the main unit is turned off. 22 Operating...

Installing Software
Software Installation and Connection
The software on the enclosed Software / Manual DVD
-ROM can be installed on your computer.
You can select from the 3 installation methods below, depending on your needs.
a. Complete: Install all the drivers, applications, utilities and Operation Manual.
b. All Drivers & Utilities: Install the drivers, utilities and Operation Manual.
c. Custom: Install one of the drivers or Operation Manual. Note
•Normally, it is recommended to select [Complete]....

5.
Select the desired installation methods from the  "Software" list on the left side of the screen.
• If you selected [Complete] or [All Drivers & Utilities], continue to step  7.
If you selected [Custom], continue to step 6.
6. If you selected [Custom] for the installation type in step 5, select the item that you want to install. 7.
Follow the instructions on the screen.
8. Connect the scanner and computer using the USB cable ( A).USB cable
To computer
Notice
•Be sure to use the USB cable...

9.
Press the power button ( A) to turn ON the scanner power.•
The LED   (green) will flash and then turn on.
• If the device driver is installed, follow the hardware wizard
’s on-screen instructions to complete
installation. If you are using Windows Vista or Windows 7, this will be performed automatically. Note
•Continue with the installation even if a window appears with the message

"Digital Signature Not
Found" or "has not passed Windows Logo testing...". Operating Manual 25...

Viewing Operation Manual and Help Installed
If the manuals and software that were included on the Software / Manual DVD -ROM have been installed on
your computer, you can use the following procedure to view the Operation Manual and the software ’s help.
To view the Operation Manual 1.On the [Start] menu, point to [All Programs], then [Panasonic], and select [Scanner Manuals].
2. Select the desired manual.
•The selected manual will open.
To view the help For Image Capture Plus
1.On the [Start] menu, point...

Starting Up Scanner Applications Automatically
Single Touch Scan Settings
You can configure settings so that the application starts up automatically
"when a document is placed on the
scanner’s feed tray" ("place to scan") and "when a single touch scan button (1-3) is pressed".
Setting the application to start up Set whether an application will automatically start up and select under which conditions it will start up in the
Scan Button Setting Tool.
1.Double click the ( ) icon in...

5.
Check that the "Disable device events " checkbox is unchecked.
• If the checkbox is checked, uncheck it. 6.
Click [OK].
7. Restart the computer. 28 Operating ManualInstallation

Deleting Installed Software
If you want to remove the software that is installed on your computer, follow the procedure below to uninstall
them.
1.In [Control Panel], open [Uninstall a program].
•In Windows  XP, select [Add or Remove Programs].
2. Select the item that you want to uninstall.
•The software is displayed with the program names below:
Software Program Name
Device driver Panasonic Document Device Driver X.XX *1
TWAIN KV-S1026C KV-S1015C TWAIN Driver
ISIS KV-S1026C ISIS Driver
Image Capture...

Preparing Documents
Acceptable Documents
The acceptable documents for this scanner are as follows.Document size: Paper thickness for Feeding:
KV-S1026C: 20
–209 g/m²
KV-S1015C: 40–209 g/m² •The height of all the documents on the tray should be less than 5 mm.
This compares to 50 sheets (80  g/m² or 20 lb.) of new paper.
• With the exception of ISO format cards, the minimum guaranteed feeding length is 70 mm (2.8 in.).
• Single paper feeding is recommended for papers exceeding the legal size length....
