Panasonic High Speed Color Scanner Kv S5055 Operating Manual

Safety Information (For
United Kingdom only)
This appliance is supplied with a moulded three pin
mains plug for your safety and convenience.
A 5 amp fuse is fitted in this plug. Should the fuse need
to be replaced, please ensure that the replacement fuse
has a rating of 5 amps and that it is approved by ASTA
or BSI to BS1362. Check for the ASTA mark
 or the
BSI mark
 on the body of the fuse. If the plug contains
a removable fuse cover, you must ensure that it is
refitted when the fuse is replaced. If...

Precautions
Installation
• Do not place the unit in direct sunlight, in a cold
draft, or near heating apparatus.
• Do not place the unit near apparatus which
generate electronic or magnetic noise.
• Protect the unit from static electricity.
• Do not move the unit immediately from a cold place
to a warm place. It may cause dew.
CD-ROM
• Do not write or stick paper on the front and/or back
of CD-ROM.
• Do not touch the data side of the CD-ROM. When
handling the CD-ROM, be careful not to leave
fingerprints...

Illegal DuplicationIt is unlawful to make duplication of certain
documents.
Duplicating certain documents may be illegal in
your country/area.
Penalties of fines and/or imprisonment may be
imposed on those found guilty. The following are
examples of items that may be illegal to duplicate
in your country/area.
• Currency
• Bank notes and checks
• Bank and government bonds, and securities
• Passports, licenses, official or private
documents, identification cards, and the like
• Copyright materials, or...

Main UnitFront
Document guides
ADF door release
Hopper extension tray
Document guides selector
Exit sub guide
Exit tray
Exit stopper
Extension sub tray
ADF door
Manual feed selector
Switches the scanning method between continuous scanning (Auto) and manual scanning (Manual).
Hopper
Control Panel
For details, refer to "Control Panel and Status Indicators" (page 16).
Power switch
Ready indicator / Error indicator
For details, refer to "Control Panel and Status Indicators" (page 16)....

Rear
Imprinter door
You open this door when installing an imprinter unit (sold separately) or ink cartridge. For details on
installing an imprinter, refer to "Installing the Imprinter Unit" (page 74).
Fan exhaust vent
AC inlet
Power cord
Plugs may vary in shape depending on country/area.
USB connector
Operating Manual15Location of Controls1
2
3
54

Control Panel and Status IndicatorsADouble Feed Skip key (DFS)
If you press this key when a double feed occurs, the sheet that was detected as a double feed will
be scanned, and scanning will continue.BStart/Stop key (Start/Stop)
• If you set [Wait Key] for "Manual Feed Mode" *1
 in your application software, pushing this key
starts scanning.
• During scanning, pushing this key stops scanning.
• If you press this key when a double feed occurs, the sheet that was detected as a double feed
will be...

The status of the scanner is displayed by the ready indicator (C) and the error indicator ( D), as shown
in the table below:C  Ready indicator
(Green)D Error indicator
(Red)StatusONOFFReadyONBlink (Slow)Caution *1OFFONError*1Blink (Slow)OFFSleepBlink (Slow)Blink (Slow)Caution *1
 / SleepBlink (Fast)OFFWarming upBlink (2 times consecutively)OFFDouble Feed Skip mode
*1 Check the status of the scanner using User Utility.
Operating Manual17Location of Controls

Turning on the Scanner Power1.Set the power switch ( A) of the scanner to "
" (ON).
• The ready indicator ( B) lights green.
18Operating ManualO
p
e
r
a
t
i
o
nOperation 1
2

Preparing Documents
Acceptable Documents The acceptable documents for this scanner are as follows.
Document sizePaper thickness: 20 – 157  g/m² (5 – 42 lbs.)
• You can place up to 200 sheets of fresh, 75  g/m²
(20 lbs.) paper on the hopper at one time.
Note
•When you set a document, make sure that its height
does not exceed the limit mark on the document guides.
Recommended paper: Plain paper
Document types
• Plain paper•Recycled paper•Bond paper•OCR paper•Newspaper•Bank checks•Carbonless copy...

For documents with mixed page sizes and thicknessesDocument thicknessThe ratio of page thickness between the thickest and thinnest
pages must be less than 1.5.
Document size
The ratio of width and height between the largest page and smallest
page must be less than 1.5.
Example: If the smallest page is A4 size, then the largest page can
be up to A3 size, and if the smallest page is A6, then the largest
can be A5.20Operating ManualOperation
