Inside of the Scanner
Note•Clean the scanner at least once a week or when 20,000 sheets have been scanned, whichever comes
first.
• Clean the rollers and sensors if paper jamming or double feeding occurs frequently.
• If double feed detection does not function properly, clean the double feed detectors.
• Clean the scanning glass when black or white lines appear on the scanned images.
• If the documents you are scanning are dirty, then the scanner parts will also become dirty. To maintain
proper scanning,...

How to use the blowerRemove the brush tip from the blower ( A), place it on the area that you want to clean ( B), and then blow away
any dirt, as shown in the following figure.
• If dirt has accumulated, first remove the dirt with the brush tip of the blower, and then remove the brush tip
and blow away the remaining dirt.52Operating ManualCare and Maintenance

Cleaning the Conveyor
CAUTION•The scanning glass may be very hot after scanning a lot of documents.
Clean the scanning glass after the temperature has cooled.
Note
•Clean the conveyor before cleaning the rollers.
1. Set the power switch of the scanner to "
" (OFF).
2. Pull the ADF door release ( A) towards you, and open the ADF door ( B).
3. With a dry cloth, wipe off any dirt on the conveyor ( A).
Operating Manual53Care and Maintenance 12 1

4.With the included blower, blow away any dirt that has accumulated on the self-cleaning brushes ( A).
• Rotate the reference plates ( B, C ) in the direction indicated by the arrow so that you can see the
brush.
• After cleaning, rotate the reference plates ( B, C ) in the directions indicated by the arrows to return
the plates to the original background color.
Notice
•After cleaning, make sure that the
 mark on the outside of the reference plate and the  mark
on the reference plate are aligned (page...

5.With the included blower, blow away any dirt that has accumulated on the ion outlets ( A).
Notice
•When cleaning the ion outlets, be sure to remove the brush tip from the blower. Using the blower
with the brush tip still on might damage the ionizer.
6. Close the ADF door.
• Push both sides of the ADF door down slowly until it clicks into place.
7.Set the power switch of the scanner to "" (ON).
Operating Manual55Care and Maintenance1

Cleaning the Rollers
CAUTION•The scanning glass may be very hot after scanning a lot of documents.
Clean the scanning glass after the temperature has cooled.
1. Set the power switch of the scanner to "
" (OFF).
2. Pull the ADF door release ( A) towards you, and open the ADF door ( B).
56Operating ManualCare and Maintenance 12

3.Use the roller cleaning paper (page 51) to remove the dirt from the surfaces of all rollers.
Direction to wipe rollersDouble feed prevention roller, Separation rollerOther rollers
Notice •After removing the double feed prevention roller, gently wipe dirt from the surface of the roller in
the direction indicated by the arrows in the illustration. If you wipe too hard, you may damage or
misalign the roller.
For instructions on how to remove the double feed prevention roller, see "Replacing the...

Location of RollersAPaper feed rollerBSeparation rollerCFree rollersDDouble feed prevention rollerEDrive rollers58Operating ManualCare and Maintenance3
4
12 5

4.Close the ADF door.
• Push both sides of the ADF door down slowly until it clicks into place.
5.Set the power switch of the scanner to "" (ON).
6. Reset the roller cleaning counter in User Utility to 0.
• Start User Utility, and in the window, click the [Clear Counter] button for "After Clean Roller" to reset
to counter to 0.
• For details, refer to the help for User Utility.
Operating Manual59Care and Maintenance

Cleaning the Sensors and Scanning Glass
CAUTION•The scanning glass may be very hot after scanning a lot of documents.
Clean the scanning glass after the temperature has cooled.
1. Set the power switch of the scanner to "
" (OFF).
2. Pull the ADF door release ( A) towards you, and open the ADF door ( B).
60Operating ManualCare and Maintenance 12
