Sony Vpl Es3 Projector User Manual

21Effective Tools for Your Presentation
Convenient Functions
2Enter the password.
Enter the password that was set.
If you call the customer service center because
you have forgotten the password, you will need
to be able to verify the projector’s serial
number and your identity.  (This process may
differ in other countries/regions.)  Once your
identity has been confirmed, we will provide
you with the password.
Effective Tools for
Your Presentation
To enlarge the image (Digital Zoom
function)
You...

22Effective Tools for Your Presentation
Use the arrow key (v/V/b/B) to scroll
the enlarged image.
To return the image to its original size
Press the D ZOOM – key.
Just pressing the RESET key returns the
image back to its original size immediately.
To freeze the image projected
(Freeze function)
Press the FREEZE key. “Freeze” appears
when the key is pressed. This function works
when a signal from a computer is input.
To restore the original screen, press the
FREEZE key again.

23Using a MENU
Adjustments and Settings Using a Menu
BAdjustments and Settings Using a Menu
Using a MENU
The projector is equipped with an on-screen
menu for making various adjustments and
settings.
Display items
Input signal indicator
Shows the selected input channel.   is
displayed when no signal is input. You can
hide this indicator using “Status” on the
MENU SETTING menu.
Input signal setting indicator
For Input-A: Shows “Auto.”
For Video/S-Video input: Shows “Auto” or
the “Color System”...

24Using a MENU
To clear the menu
Press the MENU key.
The menu disappears automatically if a key
is not pressed for one minute.
To reset items that have been
adjusted
Select the item that you want to reset, and
then press the RESET key on the Remote
Commander.
“Complete!” appears on the screen and the
setting of the item that you have selected is
factory preset values.
Storage of the settings
The settings are automatically stored in the
projector memory except the settings for
items (“Dot...

25The PICTURE SETTING Menu
Adjustments and Settings Using a Menu
The PICTURE SETTING Menu
The PICTURE SETTING menu is used for adjusting the picture or volume.
Items that can be adjusted or set depend on the kind of input signals. For details, see “Input
signals and adjustable/setting items” on page 33.
Picture Mode  Standard
Adjust Picture...
Volume: 30
PICTURE SETTINGInput APICTURE SETTING
Contrast: 80
Brightness: 50
Gamma Mode:  Graphics
Color Temp.:
High
ADJUST PICTURE...

26The INPUT SETTING Menu
The INPUT SETTING Menu
The INPUT SETTING menu is used to adjust the input signal.
Items that can be adjusted or set depend on  the kind of input signals. For details, see “Input
signals and adjustable/setting items” on page 33.
When the video signal is input
When the signal is input from a computer
Setting items Functions Initial setting
Wide Mode Sets the aspect ratio of the picture.
Off: When a picture with a ratio of 4:3 is input.
On: When a picture with a ratio of 16:9...

27The INPUT SETTING Menu
Adjustments and Settings Using a Menu
Note that if the projector is used for profit or for public viewing, modifying the original picture by
switching to the wide mode may constitute an infringement of the rights of authors or producers,
which are legally protected.
This projector has 40 types of preset data for
input signals (the preset memory). When a
preset signal is input, the projector
automatically detects the signal type and
recalls the data for the signal from the...

28The SET SETTING Menu
The SET SETTING Menu
The SET SETTING menu is used for changing the settings of the projector.
Setting items Functions Initial setting
Smart APA The APA (Auto Pixel Alignment) automatically
adjusts “Dot Phase,” “H Size” and “Shift” on the
INPUT SETTING menu for the input signal from a
computer.
On: When a signal is input from a computer, the
APA functions automatically so that the picture can
be seen clearly.  Once the specified input signal has
been adjusted by the “Smart...

29The SET SETTING Menu
Adjustments and Settings Using a Menu
 Press the APA key when the full image is displayed on the screen. If the projected image includes
a black portion around it, the APA function will not work properly and some parts of the image
may not be displayed on the screen.
 You can cancel the adjustment by pressing the APA key again while “Adjusting” appears on the
screen.
 The picture may not be adjusted properly depending on the type of input signal.
 Adjust the “Dot Phase,” “H...

30The MENU SETTING Menu
The MENU SETTING Menu
The MENU SETTING menu is used for changing the menu displays.
Setting items Functions Initial setting
Status (on-screen
display)Sets up the on-screen display.
When set to “Off,” turns off the on-screen displays
except for the menus, a message when the power is
turned off, and warning messages.On
Language Selects the language used in the menu and on-screen
displays. The languages available are: English,
Nederlands, Français, Italiano, Deutsch, Español,...
