NEC Neax 2400 Ipx Office Data Specification

NDA-24298 CHAPTER 4
Page 137
Issue 1
ASYD : Assignment of System Data
1200
b0LP08 #0 is mounted on PBI40 Module for IPX-UMG system
b1LP08 #1 is mounted on PBI40 Module for IPX-UMG system
0
b2Not used
0b3
b4LP10 #0 is mounted on PBI44 Module for IPX-UMG system
b5LP10 #1 is mounted on PBI44 Module for IPX-UMG system
0
b6Not used
0b7
201
b0LP12 #0 is mounted on PBI48 Module for IPX-UMG system
b1LP12 #1 is mounted on PBI48 Module for IPX-UMG system
0
b2Not used
0b3
b4LP14 #0 is mounted on PBI4C Module for...

CHAPTER 4 NDA-24298
Page 138
Issue 1
ASYD : Assignment of System Data
1205
b0LP28 #0 is mounted on PBI68 Module for IPX-UMG system
b1LP28 #1 is mounted on PBI68 Module for IPX-UMG system
0
b2Not used
0b3
b4LP30 #0 is mounted on PBI6C Module for IPX-UMG system
b5LP30 #1 is mounted on PBI6C Module for IPX-UMG system
0
b6Not used
0b7
206 00Not used
207
b0IP00 System #0
0/1 = Not mounted/Mounted
b1IP00 System #1
0/1 = Not mounted/Mounted
b2IP01 System #0
0/1 = Not mounted/Mounted
b3IP01 System #1
0/1 = Not...

NDA-24298 CHAPTER 4
Page 139
Issue 1
ASYD : Assignment of System Data
1210 00
Not used
213 00
Not used
214 00
b0
Not used
b1
b2
b3
b4
b5Node Suppression - Centralized Billing CCIS
0/1 = Out/In Service
b6Not usedb7
215 00Not used
219 00Not used
220
b0Protocol of ISDN Terminal (BRI station)
0:Japan (INS64)
1:U.S.A. (5ESS)
2:Australia (TPH 1962)
3:Not used
4:Not used
5:N-ISDN1
6-15:Not used
b1
b2
b3
b4Rate Adaption (RA) for ISDN Terminal
0: RA designated by ADA2 command
1: V.110/X.30
2: Not used
3: Not...

CHAPTER 4 NDA-24298
Page 140
Issue 1
ASYD : Assignment of System Data
1229 000
b0
Disable Attendant Console Loop keys when that console is in
Night Mode (Nite Key engaged)
0/1 = No/Yes
0
b1Not used
b2
With the key pad pressed by the Attendant while talking with the
incoming call, DTMF (PB) signal is sent out to the incoming call.
0/1 = Not Required/Required
b3Day/Night Change Message Automatic Output.
0/1 = Out/In Service
0
b4
Not usedb5
b6
b7
230b0~b6Not used
b7Receive/Send timing for ISDN/CCIS...

NDA-24298 CHAPTER 4
Page 141
Issue 1
ASYD : Assignment of System Data
1234
b0Connection acknowledge polarity reversal signal
0/1 = Not Required/Required (Multi-Frequency)
0
b1
Not used
b2
b3
b4
b5
b6
b7
235 00Not used
236 00
Not used
2370
b0-b6Not used
b7When a call terminated to vacant number by Direct Inward Dialing
0/1 = Send Busy Tone/Reorder Tone
238 00
Not used
239 00
Not used
SYSTEM
DATA
TYPE
(SYS)SYSTEM
DATA
INDEX
(INDEX)
0 - 511DATA
(DATA)
00 - FF
(Hex)BIT
CORRESPONDING
DATA
SYSTEM DATA...

CHAPTER 4 NDA-24298
Page 142
Issue 1
ASYD : Assignment of System Data
1 2400
b0
Not used 0b1
0b2
0b3
b4
This bit defines the meaning of the “Station Information” in the
office that has VMS/Host Computer within the CCIS No. 7
Network.
0 = Station Information = Office Code + Station Number
1 = Station Information = Station Number
Note:Station Information corresponds to Mail Box in VMS
Office Code indicates the self office code assigned by
ARNP.
Example:
Pattern 1STAMail Box Number
1000
2000
3000
In case...

NDA-24298 CHAPTER 4
Page 143
Issue 1
ASYD : Assignment of System Data
1241
b0Data Port Chime Control by SCF
0/1 = To be controlled/Not to be controlled
b1The number of digits displayed in Name Display Service
0/1 = 8 digits/16 digits
b2OAI Call Event Process
0/1 = No/Yes
b3Detail Information on SCG error
0/1 = No/Yes
b4MF ANI on SMDR
0/1 = No/Yes
b5Privacy Release for single line
0/1 = No/Yes
b6When the length of Caller ID exceeds the limit:
0/1 = Only the former/latter part of data appears on the LCD...

CHAPTER 4 NDA-24298
Page 144
Issue 1
ASYD : Assignment of System Data
1244
b0
Answer by Radio Paging answer code.
0/1 = Out/In Service
Note:This bit is valid when SYS-1, INDEX 73, Bit 4 is 1 (=
Station Number is Automatically sent).
0
b1 Not used
b2MCI-CCIS output packet change when the last digit is “*.”
0/1 = -/route number and trunk number are output
0
b3 , b4Not used
b5
Timing of providing the announcement for Delay Announcement
-Attendant
0 = immediately after the call termination
1 = after the...

NDA-24298 CHAPTER 4
Page 145
Issue 1
ASYD : Assignment of System Data
1246
b0
While engaging in a two-party call with a station/trunk, the
Attendant places the call on hold by pressing either the ANSWER
key or the Incoming Call Identification (ICI) key and answers the
next call.
0/1 = Not Available/Available
b1
While engaging in a three-way call with station/trunks, the
Attendant exits from the call by depressing either ANSWER key
or ICI key and answers an incoming call terminated next.
0/1 = Not...

CHAPTER 4 NDA-24298
Page 146
Issue 1
ASYD : Assignment of System Data
Note 1:When this data has been set as specified below, the alarm message output value becomes 80% and the alarm message
output clear message output value becomes 50% regardless of the data.
When the data of INDEX 249 is smaller than or equal to the data of INDEX 250
When these data values are not valid. 12480
b0 ~ b3Not used
b4Call Forward Don’t Answer After Attendant Camp-On
0/1 = No/Yes
b5Not used
b6
When the destination station...
