NEC Neax 2400 Ipx Office Data Specification

NDA-24298 CHAPTER 4
Page 177
Issue 1
ASYDL : Assignment of System Data into Local DM (LDM)
1531SDT card accommodation
0/1 = Not accommodated/Accommodated
b1
→ MG1, b3 → MG3, b5 → MG5, b7 → MG7
Note 1:The SDT card can be mounted in the odd MG
only.
532Fusion Point Code (FPC) of the Center Node (CN) for
the Centralized Management Report-Fusion
533 00 Not used
534
b0
Stop Network Data Memory Broadcasting to LCNs
from NCN
0/1 = No/Yes
Note:This bit stops the automatic broadcasting of
Network Data Memory...

CHAPTER 4 NDA-24298
Page 178
Issue 1
ASYDL : Assignment of System Data into Local DM (LDM)
1576
b0Fusion Centralized SMDR Service (Polling Method)
0/1 = No/Yes
b1
SMDR for Fusion Network station-to-station calls
0/1 = All Station Calls/Fusion Station Calls only
Note:Data valid only when ASYDL Index 512 is set.
Valid for IPX Version 2 software or higher.
b2
SMDR Interface Type
0/1 = RS232C/LANI
b3
Output the System Message related to connection
down when the system changeover occurs on LAN
Interface for...

NDA-24298 CHAPTER 4
Page 179
Issue 1
ASYDL : Assignment of System Data into Local DM (LDM)
1580
b0
Centralized Billing-Fusion output text format of
SMDR C
0/1 = IMS (ICS) format/IPX format
b1 ~ b3Not used
b40/1 = SMDR C Apparatus with LAN interface is not
used/used. Note
b5 ~ b7Not used
581
b0
Centralized Billing-Fusion output text format of
SMDR D
0/1 = ICS format/IPX format
b1 ~ b3Not used
b40/1 = SMDR D Apparatus with LAN interface is
not used/used. Note
b5 ~ b7Not used
582
b0 ~ b3
The number of...

CHAPTER 4 NDA-24298
Page 180
Issue 1
ASYDL : Assignment of System Data into Local DM (LDM)
1584
b0 ~ b7
Designate the Polling cycle within the Self Node (for IPX-
UMG system only) by the number of calls intended for Poll-
ing of the system. Assign this data to default value “0” or “8”
in case the number of calls is within 675,000 calls per a day.
Actual setting is measured declining 30% of calls in the fol-
lowing values on the list:
585b0 ~ b7
Designate the Polling cycle between the Nodes (for Center...

NDA-24298 CHAPTER 4
Page 181
Issue 1
ASYDL : Assignment of System Data into Local DM (LDM)
1608 The Fusion Point Code (FPC) of the polling destination.
FPCs range from 1 to 253 as shown in the table below. Assign data “1 (Polling
destination of Centralized Billing-Fusion)” for the corresponding FPC node.
Note:This data should be assigned at the Center node for the Centralized
Billing-Fusion. 609
610
611
612
613
614
615
616
617
618
619
620
621
622
623
624
625
626
627
628
629
630
631
632
633
634
635
636...

CHAPTER 4 NDA-24298
Page 182
Issue 1
ASYDL : Assignment of System Data into Local DM (LDM)
1640
b0Fusion Point Code (FPC) of the node providing ATT-
CON.
Assign FPC of a terminating node for operator calls
from other nodes and Ring Down (IC) calls from
PSTN.
FPC: 1-253 (01 Hex-FD Hex)
Note:This data is necessary at all nodes. Assign
the self FPC at the terminating node.b1
b2
b3
b4
b5
b6
b7
641
b0
Designation of output numbers for SMDR ICS
format.
0/1 = Physical (station) number/Telephone number...

NDA-24298 CHAPTER 4
Page 183
Issue 1
ASYDL : Assignment of System Data into Local DM (LDM)
1642 Speech Path Memory of TONE ROM source selection for Voice Prompt
Service.
0/1 = TONE ROM/Speech Path Memory 643
644
645
646 Speech Path Memory of MUSIC ROM source selections for Voice Prompt
Service.
0/1 = MUSIC ROM/Speech Path Memory 647
648
649
650~671 Not used
672
b0
Telephone number display location on Dterm
Note:See the example on the next page.
b1
Not used
b2
b3
b4
b5
b6
b7
673 - 703 Not used
SYSTEM...

CHAPTER 4 NDA-24298
Page 184
Issue 1
ASYDL : Assignment of System Data into Local DM (LDM)
Example:
When a call terminates on a Dterm from Telephone number 123456789, the Dterm displays as follows
depending on the data settings.
23456789
11:20           AM           WED           16           APR           1997
 MIC             DND                                                             >>>
123456789
MIC            DND                                                             >>> ASYDL...

NDA-24298 CHAPTER 4
Page 185
Issue 1
ASYDL : Assignment of System Data into Local DM (LDM)
SYSTEM
DATA
TYPE
(SYS)SYSTEM
DATA
INDEX
(INDEX)
512 - 1535DATA
(DATA)
00 - FF
(Hex)BIT
CORRESPONDING
DATA
SYSTEM DATA CONTENTS
DATA
0/1BIT
1704 Fusion Point Code (FPC) of the node to which ATT-CON transfers the Day/
Night changeover information.
FPCs range from 1 to 253 as shown in the table below. Assign data “1 (D/N
changeover information is transferred)” for the corresponding node.
Note:This data is necessary...

CHAPTER 4 NDA-24298
Page 186
Issue 1
ASYDL : Assignment of System Data into Local DM (LDM)
1800
b0
ALGNL/ALGSL command tenant User Group Number
(UGN) table development of Local Data Memory
(LDM)
0/1 = Separate/Common
b1
ASPAL command tenant table development of Local
Data Memory (LDM)
0/1 = Separate/Common
b2
ANPDL command tenant data table development of
Local Data Memory (LDM)
0/1 = Separate/Common
b3
APCNL command tenant data table development of
Local Data Memory (LDM)
0/1 = Separate/Common
b4...
