Panasonic Document Scanner Kv S1057c_s1027c_sl1066_sl1056_sl1055_sl1036_sl1035 Operating Manual

Repacking InstructionsIt is highly recommended that you keep the original carton and  ALL packing materials. If you need to transport
or ship the scanner, please follow these instructions.
Note
•Improper repacking of the scanner may result in a service charge to repair the scanner.
• Please use the original carton and all of the original packing materials.
• The scanner should be handled in the correct (horizontal) position.
Required Materials
• Original scanner carton and packing materials
• Shipping...

SpecificationsScanningItemKV-S1057CKV-SL1066KV-S1027CKV-SL1056KV-SL1055KV-SL1036KV-SL1035Scanning faceDuplexScanning methodColor CIS (600 dpi)Scanning size216 mm (8.5 in.)Scanningspeed*1A4 / LetterSimplexBinary / color(200 dpi, 300 dpi)65pages/min.45pages/min.40pages/min.35pages/min.30pages/min.A4 / LetterDuplexBinary / color(200 dpi, 300 dpi)130images/min.90images/min.80images/min.70images/min.60images/min.Scanning resolution100 – 600 dpi (1 dpi step)1,200 dpi (Interpolated)Optical: 300 dpi / 600 dpi...

GeneralItemKV-S1057CKV-SL1066KV-S1027CKV-SL1056KV-SL1055KV-SL1036KV-SL1035External dimensions(Width ´ Depth ´ Height)300 ´ 272 ´ 238 mm (11.8 ´ 10.7 ´ 9.4 in.)Weight4 kg (8.8 lb.)Power requirement*1AC100 – 125 V, 50/60 Hz, 0.8 AAC220 – 240 V, 50/60 Hz, 0.5 APowerconsumption(For AC100 – 125 V models)Scanning40 W or less35 W or less35 W or less35 W or less35 W or lessReady8 W or less8 W or less8 W or less8 W or less8 W or lessSleep3.0 W or less (For KV-S1057C and KV-S1027C)2.9 W or less (For KV-SL1066,...

Index
Numerics
7-segment LED    2, 15, 44
A
AC inlet    13
Accessories    11
ADF door    12
ADF door release    12
B
Background color switch function    2, 3, 31
C
Cleaning Mode    59
Control sheet    5, 46
Conveyor    53
Cursor button    14, 43
D
Document guides    12
Double feed detection    30
Double feed detection function    2, 3
Double feed detectors    54
Double feed prevention roller module    60
Double Feed Skip (DFS) function    2, 3, 14
E
Error messages    69
Exit extension tray 1    12
Exit...

PNQX6995ZA  DD0914HS0
© Panasonic System Networks Co., Ltd. 2014
