Switching the Background Color of Scanned ImagesUsing the software, you can switch the background color of scanned images between white and black.
For details, refer to the Image Capture Plus, TWAIN, or ISIS help.Operating Manual31
Operation

Continuous Scanning (Auto) and Manual Scanning
(Manual) You can select either continuous scanning (Auto) or manual scanning (Manual) by using the manual feed
selector. Bound documents can be scanned by setting the manual feed selector to manual scanning  (Manual).
Continuous scanning (Auto)
This setting is for feeding documents one page at a time automatically.
Manual scanning (Manual)
This setting is for feeding bound and other documents manually without separating them.
Notice
•When scanning important...

Mixed Batch Card GuideNo adjustment to the document guide is required when using the mixed batch card guide. The mixed batch
card guide prevents a card from skewing when scanning paper documents and a card simultaneously.
Installing the mixed batch card guide The mixed batch card guide is stored inside the feed tray. Install the mixed batch card guide as shown in the
following illustration.
1. Remove the feed tray ( A) from the unit.
• Remove the left side of the feed tray ( B) first as shown in the...

3.Attach the feed tray ( A) to the unit.
4. Attach the mixed batch card guide ( A) to the unit.
34Operating Manual
Operation1 1

Removing the mixed batch card guideRemove the mixed batch card guide as shown in the following illustration.
1. Remove the mixed batch card guide ( A) from the unit.
2. Remove the feed tray ( A) from the unit.
• Remove the left side of the feed tray ( B) first as shown in the illustration.
Operating Manual35
Operation1 1
2

3.Attach the mixed batch card guide ( B) to the feed tray ( A).
4. Attach the feed tray ( A) to the unit.
36Operating Manual
Operation1
2 1

Using the Mixed Batch Card GuideSet paper documents on the feed tray, and a card on the mixed batch card guide respectively.
• The card set on the mixed batch card guide is fed after completing the paper document scanning.
• The mixed batch card guide is suitable for the following card type.
ISO format card:Size:85.6  ´ 54 mm (3.4  ´ 2.1 in.)Thickness:0.76 mm (0.03 in.)Embossed card is also available.
• Set the card in landscape orientation.
• A maximum of 3 cards can be set in the mixed batch card...

Scanning Documents1.Adjust the document guides ( A) slightly larger than the actual size of the documents.38Operating Manual
Operation1

2.Fan the documents.
• Documents that have been stapled together or stacked together (as in a file folder) will need to be
separated.
Fan the stack of documents to separate all the edges.
Hold both ends and bend the documents as shown in the illustration.
To flatten the documents, hold firmly and pull them apart as shown in the illustration.
Repeat these steps as necessary.
3. Carefully align the documents.
• The documents feed better when the leading edges are aligned slantwise as shown in the...

4.Place the documents on the feed tray with the side to be scanned facing down.
• Set the leading edge of documents as shown in the illustration ( A).
• Insert the documents slowly until they stop.
Note
•The height of the documents should not exceed the limit mark (
) on the document guide.
Exceeding the limit mark may cause a paper jam or skewing.
5. Adjust the document guides ( A) to the size of the documents to be scanned.
40Operating Manual
Operation1  1
