b.Pull out the exit tray ( A) and the exit extension trays ( B, C ).
Notice
•Do not forcefully pull out the exit stopper, the exit tray, or the exit extension trays. Doing so
may damage them.
4. Plug in the power cord and connect the USB cable.
5. Press the power button to turn ON the unit’s power.
• The LED (Green) will flash and then turn on.
• If the hardware wizard appears, follow the on-screen instructions to complete installation.
Operating Manual21
Installation2
1
3

Viewing Operating Manual and Help InstalledIf the manuals and software that were included on the Software / Manual CD -ROM have been installed on your
computer, you can use the following procedure to view the Operating Manual and the software’s help.
To view the Operating Manual 1.Select [All Programs]  ® [Panasonic]  ® [Scanner Manuals].
2. Select the manual.
• The manual will open.
Note
•In Windows 8, select the [Panasonic Document Scanner] section on the Apps screen.
To view the help
Note •We...

Preparing Documents
Notice•Make sure to remove paper clips and staples from documents before scanning. Failing to do so can
damage the unit, document, or both.
• It is recommended to confirm that documents and cards are suitable for scanning (paper size,
thickness, type, etc.) before scanning them.
• Before feeding, ensure that the document is not creased or folded. If the document is creased or folded,
a paper jam or damage to the document may occur.
• When scanning important documents, confirm that the...

Paper capacity for the feed tray:Paper length (L)Combined thicknessNumber ofsheetsPaper weight
54 mm  £ L  £ 297 mm
(2.1 in.  £ L  £ 11.7 in.)10 mm
(0.4 in.)
13064 g/m² (17 lb.)
High-quality woodfree paper10075 g/m² (20 lb.)
High-quality woodfree paper10080 g/m² (21 lb.)
High-quality woodfree paper
297 mm < L  £ 356 mm
(11.7 in. < L  £ 14 in.)8 mm
(0.31 in.)
8064 g/m² (17 lb.)
High-quality woodfree paper8075 g/m² (20 lb.)
High-quality woodfree paper8080 g/m² (21 lb.)
High-quality woodfree paper...

Compatible Card TypesThe compatible card types for this unit are as follows.
ISO format card:Size:85.6  ´ 54 mm (3.4  ´ 2.1 in.)Thickness:0.76 mm (0.03 in.)
• Embossed cards are also compatible. When scanning embossed cards, it is recommended to place them
in landscape orientation with the side to be scanned facing up.
• A maximum of 3 cards can be loaded on the feed tray. When loading, ensure that the embossed portions
of cards do not stick together.
• Use the landscape orientation when scanning an...

Compatible Bound Documents (Manual Scanning Only)Bound documents can be scanned by setting the manual feed selector to manual scanning  (Manual). You can
use an optional carrier sheet (KV-SS076) to scan passports using manual scanning.
Passport size:
The passport sizes compatible with this unit are as follows.Width:140 mm (5.5 in.) or lessLength:190 mm (7.5 in.) or lessThickness:2.6 mm (0.1 in.) or less
Scanning passports
1. Set the manual feed selector to manual scanning (Manual).
26Operating Manual...

2.Put the passport in a carrier sheet.
• Open the passport ( A) to the page you want to scan, and then put the thinner part (the opened half
with less pages) in the carrier sheet ( B) first, as shown in the illustration.
• The corner of the thinner part of the passport should be inserted into the corner of the carrier sheet.
3.Place the carrier sheet ( A) on the feed tray with the surface to be scanned facing down.
• Adjust the document guides ( B) to the size of the carrier sheet to be scanned....

4.Insert the carrier sheet ( A) until it stops as shown in the illustration.
Note
•When manual scanning (Manual) is selected, make sure to insert the documents until they come
into contact with the paper feed roller.
5. Start scanning.
Note
•If the rollers are dirty, the scanned image will be stretched or distorted. In such cases, clean the
rollers.
• If vertical streaks appear on the scanned image, clean the scanning glasses and the carrier sheet.
Vertical streaks that appear may be caused by scratches...

Incompatible DocumentsThe following types of documents may not scan properly:
• Torn or frayed documents
• Curled, wrinkled or folded documents
• Carbon paper
• Perforated or punched paper
• Non-rectangular or irregularly shaped paper
• Coated paper
• Bound or glued documents
• Chemical paper such as carbonless copy paper
If papers like this are scanned, the rollers will need to be cleaned frequently and the lifetime of the rollers
may be shortened.
• Paper with wood content
• Photographs
Photographs may...

Notes about Documents for Scanning•Depending on the paper type, scanning results may be poor when you scan incompatible documents, or
even documents that should be compatible.
If scanned images are skewed, paper jams occur, or double feeding occurs, try scanning again after doing
the following:
– Clean the inside of the scanner (page 51)
– Reduce the number of sheets of paper loaded on the feed tray.
– Change the orientation of documents placed in portrait orientation to landscape orientation, or vice...
