DLP™ based Projector   Commercial Use
Models No.PT-D9510U
PT-D9610U
Read these instructions completely before operating this unit.
TQBJ0084
Operating Instructions
®

Dear Panasonic Customer:
This instruction booklet provides all the necessary operating information that you might require. We hope it will
help you to get the most performance out of your new product, and that you will be pleased with your Panasonic
DLP
TMbased projector.
The serial number of your product may be found on its back. You should note it in the space provided below and
retain this booklet in case service is required.
Model number:     PT-D9510U / PT-D9610U Serial number:...

3
Product Outline
This is a high-luminance DLPTM based projector which is powered by a single-phase, 3-wire type 200 V – 240 V
power supply. It utilizes three RGB DMDTMchips and a high-output xenon lamp. By fitting a projection lens and
input module (sold separately) in accordance with the setting-up location and the type of input signal, it can project
images onto screens from 100 inches (2.5 m) to 600 inches (15 m) in size.
By installing an input module (sold separately), the unit can handle various...

Features
4
By attaching different projection lenses (sold separately) that match the requirements of the setting-up location,
images of any size between 100 inches (2.5 m) and 600 inches (15 m) with an aspect ratio of 4:3(PT-D9510U),
5:4(PT-D9610U) can be projected, depending on the projection distance.  When using the fixed focus lens, the
available picture size is 100 to 180(PT-D9510U), 100 to 200(PT-D9610U) inches diagonal.
The flexibility in installation format (ceiling/floor/rear), keystone...

5
IMPORTANT SAFETY NOTICE
WARNING: To prevent damage which may result in fire or shock hazard, do not expose this appliance to rain
or moisture.
Power Supply: This DLPTMbased Projector is designed to operate on 200 V — 240 V, 50 Hz / 60 Hz AC only.
CAUTION:  This equipment is equipped with a three-pin grounding-type power plug.
Do not remove the grounding pin on the power plug.
This plug will only fit a grounding-type power outlet. This is a safety feature.
If you are unable to insert the plug into the...

Precautions with regard to safety
6
Read these operating instructions thoroughly and check all necessary safety precautions
when setting up the projector in order to avoid accidents.
WARNING
Setting-up
Installation should only be carried out by a qualified technician.
• In order to maintain full safety and precision during installation, such work should only be carried out by a
qualified technician.
At least three people are needed to set up the projector.
• This projector is manufactured with high...

7
When using the projector
Do not look into the lens while the projector is being used.
• Strong light is emitted from the projector‘s lens. If you look directly into this light, it can hurt and damage your
eyes.
Do not place the projector on top of surfaces which are sloped or unstable.
• The projector may fall down or tip over.
Do not place any objects on top of the projector.
• If water spills onto the projector or foreign objects get inside it, a short-circuit may occur which could result in fire
or...

8
Precautions on handling
CAUTION
Setting-up
The following points should always be observed when setting up this projector.
A dedicated power supply must be used.
• Ask the place of purchase to carry out any electrical work which may be required to provide a 14 A, 200 V - 240 V
AC (single phase) power supply for the projector alone to use.
Avoid setting up in places which are subject to vibration or shocks.
• If the projector is set up in a location with strong vibration, such as near a motor, or if it...

9
Notes on use
In order to get the best picture quality
• If outside light or light from indoor lamps is shining onto the screen, the images projected will not have good
contrast. Draw curtains or blinds over any windows, turn off any fluorescent lights near the screen and cover any
highly-reflective floor and wall surfaces with carpet or wallpaper to prevent reflection.
Do not touch the surface of the projection lens with your bare hands.
• Do not touch your hands against the surface of the lens. If the...

10
Name and function of each part
〈
Projector〉
POWER button
This button is used to turn the projector
power supply on and off.
•This button is enabled while the MAIN
POWER switch is ON.
SYSTEM SELECTOR button
This button is used to select RGB, RGB
REALITY, or YP
BPR(YCbCr) signal or switch
between video and digital-serial signal formats.
Arrow buttons
These buttons are used to select and
adjust items in the on-screen menus.
LENS button
This button is used to select the mode
for adjusting the lens....
