Page 11
11 Name and function of each remote control part 〈 Remote control unit〉 STD (standard) button This button is used to reset all of the projector adjustment values (BRIGHT, CONTRAST, COLOR, TINT and SHARPNESS) to the default levels which were set at the time of shipment from the factory. It is pressed after the respective adjustment mode screen has been displayed. SYSTEM SELECTOR button This button is used to select RGB, RGB REALITY, or YP BPR(YCbCr) signal or switch between video and digital-serial signal...
Page 12
12 Name and function of each remote control part (continued) 〈 Remote control unit〉 Transmitter This emits the infrared signals which are used to control the projector when the remote control unit is being used as a wireless unit. Wired remote control terminal This terminal is used to connect the accessory cable when the remote control unit is being used as a wired unit. MENU button This button is used to make the MENU screen and the respective adjustment screens appear on the projection screen, and to...
Page 13
13 Before using the remote control unit Inserting the batteries •Insert the AA batteries supplied with the remote control unit, making sure that the polarities are correct. •The batteries also need to be inserted when the remote control unit is connected to the projector using the remote control cable. Attaching the strap A strap is provided with the remote control unit. You can use this strap to hang the remote control unit around your neck for easy carrying. Attach the strap...
Page 14
14 1 3 0 +& $ 5 0 3 #3*()5$0/5345 108&3*/165 */165 45% 3(# -&/4 /&951*$ .65&*%4&-&$50/4$3&&/ *%-- 14 4 :4 5& 34&-&$503 */165 &/ 5 &3. & / 6 Accessory remote control cable To REMOTE IN2 IN terminal To remote control cable terminal [Projector] [Remote control unit] The remote control unit can be connected to the projector using the accessory remote control cable. This cable should be connected to the REMOTE IN2 IN terminal at the front of the projector and to...
Page 15
15 Turning the power ON and OFF Always be sure to follow the procedure given below to turn the projector power on and off. 〈 Turning the power on 〉〈 Turning the power off 〉 • The projector will continue to draw approximately 13 W of power when it is in standby mode, even after the cooling fan has stopped. •The lamp cooling fan will continue to operate for approximately five minutes after the power is turned off. At the same time, the self-diagnosis display “FC” will blink. Do not disconnect the power...
Page 16
16 The figure below shows on-screen displays for any desired setting, starting with the MAIN MENU, and ending with its sub-menu. Normal screen -&/4 -&/40$64
Page 17
17 The projection lenses and input modules which are available for use with this projector need to be purchased separately and must be installed to the projector before the projector can be used. • Obtain the required projection lenses and input modules beforehand in accordance with the projection distance and the system used. • When installing an optional input module, refer to page 28 for details. Install a projection lens (sold separately) which is appropriate for the projector setting-up...
Page 18
18 Setting up the projector Installing to the floor (Including the direct rear-mounting) 1. Installing drawing of the screen and the projector (unit : mm / inches) L : Projection distance between the screen and the center of the front foot of the projector. A: Distance between the center of the lens and the top of the setting table (including the height of a foot of the projector) , 288 mm – 313 mm (11.5- 12.5) (The height of each foot is adjustable.) C: Distance between the bottom of the foot and the...
Page 19
Installing to the ceiling (Including direct rear-projection) 19 • Using the projector by installing to the ceiling requires an optional ceiling mount bracket (ET-PKD95). For the projection distance (L), refer to the chapter Projection distance for each projection lens (sold separately) on pages 20 - 24. For the procedures to install the ceiling mount bracket on the projector and mount the suspension bolts on the ceiling surface, refer to the installation instructions supplied with ET-PKD95. L:...
