5.7 RiemenübertragungÜberprüfen Sie nach 5 Betriebsstunden, ob sämtli-
che Riemen intakt und unbeschädigt sind.
5.8 LenkungDie Lenkung ist nach 5 Betriebsstunden zu kon-
trollieren/nachzustellen. Anschließend ist dies alle
100 Betriebsstunden zu wiederholen.
5.8.1 Kontrolle
Drehen Sie das Rad mit kurzem ruckartigen Zie-
hen nach vorn und hinten. Es darf kein mechani-
sches Spiel an den Lenkketten vorliegen.
5.8.2 Einstellung
Justieren Sie die Lenkketten bei Bedarf wie folgt:
1. Stellen Sie...

62
DEUTSCHDE
Überprüfen Sie, ob der Benzinschlauch
nicht an den Ölpumpe gedrückt wird
bzw. damit in Berührung kommt. Die
Ölpumpe wird während des Betriebs
sehr heiß. Es besteht Brandgefahr.
1. Positionieren Sie den Benzintank auf den Kon-
solen. Achten Sie darauf, dass der Benzin-
schlauch den Ölpumpe nicht berührt.
2. Montieren Sie die Klammern und ziehen Sie die
Flügelmuttern an (16:B).
5.9.4 Reinigung
Oxidierte Batteriepole müssen gereinigt werden.
Verwenden Sie dazu eine Stahlbürste und...

63
DEUTSCHDE
5.11 ZündkerzeDie Zündkerze(n) ist (sind) alle 200 Betriebsstun-
den auszutauschen (d.h. bei jedem zweiten Grund-
service).
Verwenden Sie den beiliegenden Zündkerzen-
schlüssel.
Bevor Sie die Zündkerze lösen, reinigen Sie deren
Befestigung.
Zündkerze
:
Pro16, Pro20, Pro25: Champion RC12YC oder
gleichwertig.
Pro Svan
: NGK BPR5ES oder
DENSO W16EPR-U
Elektrodenabstand
: 0,75 mm.
5.12 LufteinlassSiehe 9-11:W. Der Motor ist luftgekühlt. Verstop-
fungen im Kühlsystem schaden dem Motor. Der...

64
ENGLISHEN
1 GENERAL
This symbol indicates WARNING. Seri-
ous personal injury and/or damage to
property may result if the instructions
are not followed carefully.
You must read these instructions for use
and the accompanying pamphlet
“SAFETY INSTRUCTIONS” careful-
ly, before starting up the machine.
1.1 SYMBOLSThe following symbols appear on the machine.
They are there to remind you of the care and atten-
tion required during use and maintenance.
This is what the symbols mean:
Warning!
Read the...

65
ENGLISHEN
•Lifting. Press the rear part of the switch until
the implement is in its highest position (trans-
port position). Then release the switch and the
height is locked in transport position.
•Locking in transport position. The switch has
reverted to neutral position after lifting. The im-
plement is locked in transport position.
NOTE! The hydraulic implement lifter must be
in floating position in order for the power take-
off to be engaged.
NOTE! The power take-off cannot be engaged
when...

66
ENGLISHEN
Do not leave the machine with the key
in position 2 or 3. There is a fire risk,
fuel can run into the engine through the
carburettor, and there is a risk of the
battery being discharged and damaged.
Four positions:
1. Stop position – the engine is short-cir-
cuited. The key can be removed.
2. Operating position – headlight activat-
ed.
3. Operating position – headlight not acti-
vated.
4. Start position – the electric start motor
is activated when the key is turned to the
spring-loaded...

67
ENGLISHEN
The engine casing is opened as follows:
1. Undo the rubber strap (7:V) at the front edge of
the casing.
2. Carefully lift the engine casing back.
Close in the reverse order.
The machine may not be operated un-
less the engine casing is closed and
locked. Risk of burns and crushing in-
juries.
3 AREAS OF USE
The machine may only be used for the following
tasks using the genuine STIGA accessories stated.
The maximum vertical load on the towing hitch
must not exceed 100 N.
The maximum...

68
ENGLISHEN
The oil level must never exceed the “FULL” mark.
This results in the engine overheating. If the oil
level exceeds the “FULL” mark, the oil must be
drained until the correct level is achieved.
4.3 Safety checksCheck that the results of the safety checks below
are achieved when testing the machine in question.
The safety checks must always be car-
ried out every time before use.
If any of the results below is not
achieved, the machine must not be
used! Take the machine to a service...

69
ENGLISHEN
Be careful when driving on slopes. No
sudden starting or stopping when driv-
ing up or down a slope. Never drive
across a slope. Move from the top down
or from the bottom to the top.
The machine may not be driven on
slopes greater than 10º in any direction.
Reduce the speed on slopes and when
making sharp turns in order to retain
control and reduce the risk of tipping
over.
Do not turn the steering wheel to full
lock when driving in top gear and at full
throttle. The machine can...

70
ENGLISHEN
5.4.1 Change intervals
The table below states hours of operation and cal-
endar months. Carry out the relevant action at
whichever occurs first.
Change the oil more frequently if the engine has to
operate in demanding conditions or if the ambient
temperature is high.
5.4.2 Engine Oil
Use synthetic oil according to the table below.
Use oil without any additives.
Do not fill with too much oil. This can cause the
engine to overheat.
Change oil when the engine is warm.The engine oil may be...
