Stiga PARK 4WD PRO 25 PRO 20 PRO 16 PRO SVAN Instructions Manual

61
DEUTSCHDE
Übersetzung der Originalbetriebsanleitung
5.14 SICHERUNGENWenn einer der unten aufgeführten Fehler auftritt,
ist die entsprechende Sicherung auszuwechseln.
Siehe Abb. 19.
6 PATENT- UND MUSTER-
SCHUTZ
Dieses Gerät oder Teile von ihm unterliegen fol-
gendem Patent- und Musterschutz:
SE9901091-0, SE9901730-3, SE9401745-6,
US595 7497, FR772384, DE69520215.4,
GB772384, SE0301072-5, SE04/000239 (PCT),
SE0401554-1.
GGP behält sich das Recht vor, ohne vorherige An-
kündigung Änderungen am...

62
ENGLISHEN
Original instructions for use
1 GENERAL
This symbol indicates WARNING. Seri-
ous personal injury and/or damage to
property may result if the instructions
are not followed carefully.
You must read these instructions for use
and the accompanying pamphlet
“SAFETY INSTRUCTIONS” careful-
ly, before starting up the machine.
1.1 SYMBOLSThe following symbols appear on the machine.
They are there to remind you of the care and atten-
tion required during use and maintenance.
This is what the...

63
ENGLISHEN
Original instructions for use
2.4.2 Implement lifter, hydraulic (5:M)(Pro20, Pro23, Pro Svan)
The hydraulic implement lifter only works when
the engine is running and the clutch pedal and
parking brake pedal are not depressed. The imple-
ment lifter is controlled using the lever (5:M).
The lever has the following four positions:
Floating position. Move the lever to its
front position, where it locks. The imple-
ment is now lowered to its floating posi-
tion.
In the floating position,...

64
ENGLISHEN
Original instructions for use
2.4.9 Ignition lock/headlight (4,5:I)
The ignition lock is used for starting and stopping
the engine. The ignition lock is also the switch for
the headlight. Do not leave the machine with the key
in position 2 or 3. There is a fire risk,
fuel can run into the engine through the
carburettor, and there is a risk of the
battery being discharged and damaged.
Four positions: 1. Stop position  – the engine is short-
circuited. The key can be removed.
2....

65
ENGLISHEN
Original instructions for use
2.4.17 Engine casing (7:U)In order to access the fuel cock, battery
and engine, the machine has an engine
casing that can be opened. The engine cas-
ing is locked with a rubber strap.
The engine casing is opened as follows:
1. Undo the rubber strap (7:V) at the front edge of  the casing.
2. Carefully lift the engine casing back.
Close in the reverse order.
The machine may not be operated un-
less the engine casing is closed and
locked. Risk of burns and...

66
ENGLISHEN
Original instructions for use
Environmental petrol can be used, i.e. alkylate pet-
rol. This type of petrol has a composition that is
less harmful for people and nature.Petrol is highly inflammable. Always
store fuel in containers that are made
especially for this purpose.
Only fill or top up with petrol outdoors,
and never smoke when filling or top-
ping up. Fill up with fuel before starting
the engine. Never remove the filler cap
or fill with petrol while the engine is
running or...

67
ENGLISHEN
Original instructions for use
4.4 START1.  Open the fuel cock. See 12.
2.  Check that the spark plug cable(s) is/are in-stalled on the spark plug(s).
3.  Check to make sure that the power take-off is  disengaged.
4.  Do not keep your foot on the drive pedal (3:F).
5. Put the throttle control at full throttle.  Starting cold engine – pull the choke control out
fully.
Starting warm engine – the choke control
should be pressed in.
6.  Depress the clutch-brake pedal (3:B) fully.
7.  Turn...

68
ENGLISHEN
Original instructions for use
5 MAINTENANCE
5.1 SERVICE PROGRAMMEIn order to keep the machine in good condition as
regards reliability and operational safety as well as
from an environmental perspective, STIGA’s Serv-
ice programme should be followed.
The contents of this programme can be found in
the attached service log.
Basic service
 must always be carried out by an au-
thorised workshop.
First service and intermediate service
 should be
carried out by an authorised workshop, but can...

69
ENGLISHEN
Original instructions for use
Oil quantity:
8. After filling up the oil, start the engine and idle  for 30 seconds.
9. Check to see if there is any oil leakage.
10.Stop the engine. Wait for 30 seconds and then  check the oil level in accordance with 4.2.
5.4.3 Oil filter
First drain the engine oil and install the oil drain-
age plug as described above. Then replace the oil
filter as follows:
1. Clean the area around the filter and dismantle  the filter.
2. Moisten the new filter’s gasket...

70
ENGLISHEN
Original instructions for use
10.If the machine has a hydraulic implement lifter, raise and lower the lifter 3-4 times.
11.Adjust the oil level in the reservoir.
5.7 BELT TRANSMISSIONSAfter 5 hours of operation, check that all the belts
are intact and undamaged.
5.8 STEERINGThe steering must be checked/adjusted after 5
hours of operation and thereafter after 100 hours of
operation.
5.8.1 Checks
Briefly turn the steering wheel back and forth.
There must be no mechanical clearance in the...
