6. DISENGAGING LEVER (President -
Pro16 - Pro18)
A lever for disengaging the variable transmission.
Enables the machine to be moved by hand without
the help of the engine. (Note that, on the Pro16-
Pro18, the lever is on the left-hand side.) There are
two positions:
1. Lever moved back - transmis-
sion engaged for normal opera-
tion.
2. Lever moved forward - trans-
mission disengaged. The ma-
chine can be moved by hand.
To avoid damage to the transmission, do not tow the
machine for...

56
ENGLISHGB
2. Drive position (without symbol).
3. Start position - the electric starter motor
is activated when the key is turned to the
spring-loaded start position. Once the en-
gine has started, allow the key to return to
the drive position.
A spare key is enclosed in the plastic bag that also
includes this instructions for use. Keep this key
in a safe place.
14. CRUISE CONTROL (Pro16 -
Pro18)
A switch for activating the cruise control. The
function of the cruise control allows the drive...

57
ENGLISHGB
5. Grass and leaf transport
Using dump cart 13-1979 (Standard) or
13-1988 (Maxi).
6. Fertiliser spreading
Using fertiliser spreader 13-1987. Can also be
used for spreading grass seed.
7. Sand spreading
Using sand spreader 13-1975. Can also be used
for spreading salt. Snow chains 13-1956 and
wheel weights 13-1982 are recommended.
8. Weeding on gravel paths
Using front mounted hoe 13-1944 and rear
mounted rake 13-1969.
9. Lawn edge trimming
Using edge trimmer 13-1972.
10.Moss scarification...

58
ENGLISHGB
lever (only US and Canada)
In order to start the machine the following are nec-
essary:
- gear lever in neutral (only Classic)
- brake pedal depressed
- driver sitting on seat
- power take-off engagement lever at lowest
setting (i.e. power take-off disengaged)
Always check the operation of the safe-
ty system before using the machine!
Check in the following way:
- start the engine, sit on the seat, select a gear,
lift your weight off the seat - the engine must
stop (applies to Classic)
-...

59
ENGLISHGB
“FULL”).
Be careful when driving on slopes. No
sudden starting or stopping when mov-
ing up or down a slope. Never drive
across a slope. Move from the top and
down, and from down to the top.
The machine, equipped with original
accessories, must not be driven on
slopes greater than 10° in any direction.
Reduce the speed on slopes and when
moving the machine in sharp bend-like
patterns to prevent the machine from
turning over or you losing control over
the machine.
NOTE! Before...

60
ENGLISHGB
Check the oil every time when topping up. The
level should come up to the “FULL” mark.
CHANGING THE TRANSMISSION
OIL (President - Pro16 - Pro18)
Change the oil the first time after 50 hours of oper-
ation, and then after every 250 hours or operation
or once a season.
Use a good grade of SAE 20W-50 oil (service
grade SE, SF or SG).
Total amount of oil:
President - 1.6 litres
Pro16, Pro18 - 3.3 litres
NOTE that the design of the transmission per-
mits only about 80% of the total amount...

61
ENGLISHGB
25 hours running (fig 17 - 18).
All plastic bearings should be lubricated twice
each season.
Apply universal grease to the steering chain a cou-
ple of times each season. If the steering chain is re-
ally dirty, dismantle it, wash it, and then grease it
once more.
Apply a coating of engine oil to the tension arm
joints twice each season.
Apply a few drops of engine oil on both ends of the
throttle control cable a couple of times a season.
Classic:
The transmission is filled with oil...

62
ENGLISHGB
ADJUSTING POWER TAKE - OFF
CABLE (not Pro18)
If the v-belt between the engine belt pulley and
centre belt pulley slips when the power take-off is
engaged, the power take-off cable can be tensioned
by means of the two cable adjusters K (fig 23).
REPLACING THE V - BELTS
You can replace the v-belts while the machine is
standing on its wheels.
Remark: To illustrate how to replace v-belts the
machines are shown here from below and on there
sides (figs 24 - 26).
Always use genuine belts....

63
ENGLISHGB
er side.
5. Tighten the pedal stop locking nut.
The forward movement of the drive
pedal must not be restricted by the end
position of the transmission, otherwise
serious damage may arise.
6. Then adjust the pedal stop under the rear part of
the drive pedal. The backward movement of the
drive pedal should be about half the forward move-
ment.
STEERING CABLES (Classic -
President)
After the machine has been in operation for a few
hours the steering cables should be adjusted.
Put the...

64
ENGLISHGB
EC - DECLARATION OF
CONFORMITY
Model: Park
Type: P401
Art. no.: 13-1258, 13-1358, 13-1458, 13-1818,
13-1442, 13-1443, 13-1446, 13-1448
Serial no.: See machine
Manufact.: STIGA AB, P.O. Box 1006,
S-573 28 Tranås, Sweden
Product: Lawn mower with combustion engine
This product complies with the following:
- Electromagnetic Compatibility Directive 89/336/EEC
- Machine Directives 89/392/EEC, 91/386/EEC and
93/44/EEC with particular reference to Annex 1 in
the Directive concerning essential...
